Theben TR 635 top2 Manual de usuario
309563 03
GB
TR 635 top2
0 6 12 18 24
MENU OK
TR 635 top2
Connection of
different external
wires is permitted
Installation and
operating instructions
Digital time switch
with weekly program
TR
TR 635 top2 6350100
TR 636 top2 6360100
DGB F
I E NL
2
Contents
Basic advice 3
Screen and keys 4
Operating instructions 4
Overview of menu selection 5
Connection/installation 6
Initial start-up 8
Reset 8
Menu item PROGRAM
Set switching time 9
Change/request switching time 11
Delete switching time 11
Pulse programming 12
Cycle programming 13
Menu item MANUAL
Manual and permanent switching 14
Menu item OPTIONS
PIN code setting 14
OBELISK top2 memory card 15
Service address/Hotline 15
Technical data 16
3
Basic safety instructions
• The device is intended for wall and front panel installation
• Corresponds to type 1 BSTU in accordance with IEC/EN 60730-2-7
• Power reserve (10 years) is reduced if memory card is inserted (in battery operation)
Designated use
• The time switch can be used for lighting, bell systems, ventilation etc.
• Only use in enclosed dry spaces
• Do not use on safety devices, e.g. escape route doors, fire safety equipment etc.
Disposal
Dispose of device separately in an environmentally sound manner
Danger of death through electric shock or fire!
Installation should only be carried out by a qualified electrician!
WARNING
GB
E S C
O K
C1
C2 C3 C4
4
Screen display and keys Operating instructions
MENU
– Activate screen
– Open menu
– Cancel menu
– ESC
(leave menu)
YES
Confirmation
PressOK
NO
Alter/
change
Press
OK
– Store
selection
– Confirm
selection
Selection options
are displayed
Date display
Date display
Channel status
ON = On
OFF = Off
Days of the week from
1 to 7
Display of active keys with
relevant function
Programmed
switch times
bbbb
1. Read text line
Flashing text/symbol
represents query
bbbb
2. Make a decision
Overview of menu selection
19 05 11
ON
9:4046
PROGRAM
NEW
VIEW
CHANGE
DELETE
END
MENU
TIME/DATE MANUAL OPTIONS END
TIME
DATE
SUMMER--
WINTER
DAY OF THE
WEEK
DATE
FORMAT
TIME
FORMAT
END
PERMANENT
ON
PERMANENT
OF
MANUAL ON
TIMER
OPERATING
HOURS
HOLIDAY
RANDOM
END
LCD-ILLU-
MINATION
LANGUAGE
PIN
FACTORY-
SETTINGS
INFO
END
5
GB
6
Connection
Warning, danger of death through
electric shock!
Must be installed by qualified
electrician!
Disconnect power source.
Cover or shield any adjacent live
components.
Ensure device cannot be switched on!
Check power supply is disconnected.
Earth and bypass.
TR 635 top2
TR 636 top2
WARNING
C1
1 2 3
N
L
L
5 6
C1
1 2 3 4 5 6
N
L
L
C2
7 8
Installation
Distributor installation (wall)
– for installation on DIN top
hat rails (in accordance with
EN 60715) with accessories
(9070071)
Front panel installation
– for installation in front frame
and transparent cover (in
accordance with DIN 43700)
7
907 0 071
GB
Initial start-up
Set date, time and summer/
winter time rule
Press required key and display follows
on screen (see figure).
DEUTSCH
RETAIN
PROGRAMS
DELETE
PROGRAMS
FORME
DATE
SU-WI GB/
IRL/P
SU-WI FIN/
GR/TR
SU-WI CDN
SU-WI USA
SU-WI IRAN
SU-WI FREE
RULE
SO-WI FIX
DATE
NO SO-WI
ok
or 19 05 11
ON
9:4046
YEAR
MONTH
DAY
FORM TIME
HOUR
MINUTE
SU--WI
EUROPE
8
RESET
Press the 4 buttons simultaneously.
You can choose between RETAIN
PROGRAMS and DELETE PROGRAMS.
9
PROGRAM
Program switching time
Example: Switch on sports hall lighting from Mon–Fri, 7:30 to 12:00 hrs
Press MENU. PROGRAM is displayed.
Confirm by pressing OK. NEW is displayed.
Confirm by pressing OK. SWITCHING TIME is displayed.
Confirm by pressing OK. Select ON (for switch-on times).
Confirm by pressing OK. The display shows HOUR.
Use the + or – keys to enter hour, minute, (07:30) and confirm by pressing OK.
MONDAY is displayed.
Confirm by pressing OK. COPY is displayed.
Confirm by pressing OK. ADD TUESDAY is displayed.
Confirm by pressing OK and also confirm the days Wed, Thurs, Fri by pressing OK.
Continue with to SAVE is displayed. Confirm by pressing OK.
Repeat all steps for the switch-off time however instead of selecting ON with select OFF and
enter 12:00 for hour and minute.
GB
MENU
ON 7.30
PROGRAM
NEW
SWITCH TIME
ON
PULSE
TUESDAY WEDNESDAY
CYCLE END
HOUR
MINUTE
MONDAY
COPY
ADD
TUESDAY
SAVE
SAVE
...
84 memory locations are available.
