1-1

Introduction and Description

This EVM provides a platform for testing the THS4271 in 8-pin LLP (DRB)

package in a noninverting, unity gain mode. It contains the high-speed op amp,

a number of passive components, and various features and footprints that

enable the user to experiment, test, and verify various operational amplifier

circuit implementations.

The THS4271 unity gain EVM was developed to reduce peaking caused by

lead inductance in the feedback path, which proved to be excessive in a more

general layout. This EVM is designed to minimize peaking in the unity gain

configuration. Each pad and trace on a PCB has an inductance associated

with it, when in conjunction with the inductance associated with the package

may cause peaking in the frequency response, hence, cause the device to be-

come unstable.

Minimizing the inductance in the feedback path is critical for reducing the peak-

ing of the frequency response in unity gain. The recommended maximum in-

ductance allowed in the feedback path is 4 nH. This can be calculated by using

the following equation:

L(nH) +Kȏƪln 2ȏ

W)T)0.223W)T

ȏ)0.5ƫ

Where:

W = Width of trace

ȏ+Length of the trace

T = Thickness of the trace

K = 5.08 nH/inch

K = 0.2 nH/mm for Getek 4.2 epoxy polyphenylene oxide resin.

Dimensions are in inches unless otherwise specified.

Chapter 1

Evaluation Schematic

1-2

1.1 Evaluation Schematic

As delivered, the EVM has a fully functional example circuit—just add power

supplies, a signal source, and monitoring instrument. See Figure 1–1 for a

complete schematic diagram. EVM features include:

-Wide operating supply voltage range: single supply 4.5 V to dual supply

±7.5 V operation (see the device data sheet). Single supply operation is

obtained by connecting both J6 (GND) and J7 (VS-) to ground.

-Nominal 50-Ωinput impedance (R4). Termination can be configured

according to the application requirement.

-50-Ωimpedance traces on Vin+, and the Vin- to Vout connection (see

Figure 4-1—the vias provide the impedance)

-Convenient GND test point (TP1).

-453-Ω series matching resistor (R6)—produces a 500-Ωload in

combination with resistor R7. 500 Ωis the standard data sheet load

impedance.

-Power supply ripple rejection capacitors (C1 and C2).

-Decoupling capacitors (C3, C4, C5, C6).

-Power PADtheatsinking capability.

-A good example of high-speed amplifier PCB design and layout.

Figure 1-1.Schematic of the THS4271EVM-UG Unity Gain

GND

Vs-

+C2

FB1

Vs+

Vin+

FB2

Vs-

Vs+

100 pF

THS4271

TP1

Vout

Vs-

Vs+

C6C5

100 pF

49.9 W

453 W

49.9 W

0.1 mF22 mF22 mF0.1 mF

2-1

Using the EVM

Figure 2-1 shows how to connect power supplies, signal source and monitor-

ing instrument. It is recommended that the user connect the EVM as shown

to avoid damage to the EVM or the op amp installed on the board.

Figure 2-1.Test Equipment Connections

Chapter 2

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Amplificador de Texas Instruments

Texas Instruments

Texas Instruments TPA102 MSOP Manual de usuario

Texas Instruments

Texas Instruments THS4130 Manual de usuario

Texas Instruments

Texas Instruments PurePath TAS5766M Manual de usuario

Texas Instruments

Texas Instruments AFE5801 Manual de usuario

Texas Instruments

Texas Instruments TPA3200D1 Manual de usuario

Texas Instruments

Texas Instruments TPA032D04 Manual de usuario

Texas Instruments

Texas Instruments TA5704EVM Manual de usuario

Texas Instruments

Texas Instruments TLV4110 Manual de usuario

Texas Instruments

Texas Instruments TPA2000D1 Manual de usuario

Texas Instruments

Texas Instruments TPA3005D2EVM Manual de usuario

Texas Instruments

Texas Instruments TPA3120D2 Manual de usuario

Texas Instruments

Texas Instruments TPA2008D2 Manual de usuario

Texas Instruments

Texas Instruments TPA3106D1 Manual de usuario

Texas Instruments

Texas Instruments TPA6102A2 Manual de usuario

Texas Instruments

Texas Instruments CLC520 Manual de usuario

Texas Instruments

Texas Instruments THS4031 Manual de usuario

Texas Instruments

Texas Instruments TPA0243 Manual de usuario

Texas Instruments

Texas Instruments Boomer LM49360 Manual de usuario

Texas Instruments

Texas Instruments TPA6010A4 Manual de usuario

Texas Instruments

Texas Instruments LM3886 Overture Manual de usuario

Texas Instruments

Texas Instruments LM833 Instrucciones de funcionamiento y mantenimiento

Texas Instruments

Texas Instruments TAS5102EVM Manual de usuario

Texas Instruments

Texas Instruments THS3001 Manual de usuario

Texas Instruments

Texas Instruments TPA3120D2 Manual de usuario

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
