How to Use This Manual

Read This First

Preface

Read This First

About This Manual

This manual is written to provide information about the evaluation module of

the fully differential amplifier under test. Additionally, this document provides

a good example of PCB design for high speed applications. The user should

keep in mind the following points.

Thedesign ofthe high-speedamplifier PCBis asensitive process.Therefore,

the user must approach the PCB design with care and awareness. It is

recommended that the user initially review the data sheet of the device under

test. It is also helpful to review the schematic and layout of the THS4121 EVM

to determine the design techniques used in the evaluation board. In addition,

it is recommended that the user review the application note Fully-Differential

Amplifiers (literature number SLOA054B) to gain more insight about

differential amplifiers. This application note reviews the differential amplifiers

and presents calculations for various filters.

How to Use This Manual

-Chapter 1—Introduction and Description

-Chapter 2—Using the THS4121 EVM

-Chapter 3—General High-Speed Amplifier Design Considerations

Trademarks

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Related Documentation From Texas Instruments

-THS4121 data sheet (literature number SLOS319A)

-Application report (literature number SLOA054B),

Fully-Differential Amplifiers

FCC Warning

Thisequipmentisintendedforuseinalaboratorytestenvironmentonly.Itgen-

erates,uses,and canradiate radio frequencyenergy andhasnot beentested

for compliance with the limits of computing devices pursuant to subpart J of

part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other en-

vironmentsmay cause interferencewith radio communications,in whichcase

the user at his own expense will be required to take whatever measures may

be required to correct this interference.

Trademarks

PowerPAD is a trademark of Texas Instruments.

Running Title—Attribute Reference

vii

Chapter Title—Attribute Reference

Contents

1 Introduction and Description 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Description 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Evaluation Module Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 THS4121 EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Schematic of the Populated Circuit (Default Configuration) 1-3. . . . . . . . . . . . . . . . . . . . . . .

1.5 THS4121 EVM Schematic 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.6 Additional Sample Schematics 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.7 THS4121 EVM Layout 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Using the THS4121 EVM 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Required Equipment 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Power Supply Setup 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Input and Output Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Testing the EVM Setup 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 Power Down Verification 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.6 Measuring the Frequency Response 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.7 Butterworth Filter 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.8 THS4121 EVM Bill of Materials 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 General High-Speed Amplifier Design Considerations 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference

viii

Figures

1–1 Schematic of the Populated Circuit on the EVM (Default Configuration) 1-3. . . . . . . . . . . . . .

1–2 Schematic 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–3 Fully-Differential In/Fully-Differential Out, Without Transformer 1-5. . . . . . . . . . . . . . . . . . . . . .

1–4 Fully-Differential In/Fully-Differential Out, Utilizing Transformer 1-5. . . . . . . . . . . . . . . . . . . . . .

1–5 VICR Level Shifter 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–6 Butterworth Filter With Multiple Feedback 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–7 Top Layer (Silkscreen) 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–8 Top (Layer 1) (Signals) 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–9 Internal Plane (Layer 2) (Ground Plane) 1-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–10 Internal Plane (Layer 3) (±Power Plane) 1-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–11 Bottom (Layer 4) (Ground and Signal) 1-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Power Supply Connection 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Signal Connections 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–3 Driver 1 Output Signal 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–4 Multiple Feedback Filter Circuit 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–5 Gain vs Phase 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

2–1 THS4121 EVM Bill of Materials 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction and Description

This document details the Texas Instruments THS4121 high-speed

operational amplifier evaluation module (EVM). It includes a list of EVM

features,abriefdescriptionofthemoduleillustratedwithaseriesofschematic

diagrams, EVM specifications, details on connecting and using the EVM, and

a discussion of high-speed amplifier design considerations.

The Texas Instruments THS4121 evaluation module (EVM) helps designers

evaluate the performance of the THS4121 operational amplifier. Also, this

EVM is a good example of high-speed PCB design.

ThisEVMenablestheusertoimplementvariouscircuitstoclarifytheavailable

configurations presented by the schematic of the EVM. In addition, the

schematic of the default circuit has been added to depict the components

mounted on the EVM when it is received by the customer. This configuration

correlates to the single input/differential output signal.

Othersamplecircuitsarepresentedtoshowhowtheusercanimplementother

circuit configurations such as differential input/differential output signal,

transformer utilization on the input and output terminals, VICR level shifter,

and Butterworth filter with multiple feedback. The user may be able to create

and implement circuit configurations in addition to those presented in this

document using the THS4121 EVM.

Topic Page

1.1 Description 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Evaluation Module Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 THS4121 EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Schematic of the Populated Circuit (Default Configuration) 1-3. . . . . . .

1.5 THS4121 EVM Schematic 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.6 Additional Sample Schematics 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.7 THS4121 EVM Layout 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Description

1-2 Introduction and Description

1.1 Description

ThisEVMismadeoftheTHS4121high-speedoperationalamplifier,anumber

of passive components, and various features and component footprints that

enable the user to experiment and verify various operational amplifier circuit

configurations. Initially, this board is populated for a single-ended

input/differential-output amplifier (see Figure 1-2 for populated circuits). The

outputs(VO+ andVO–) canbe tested differentiallyorsingleended. Gainisset

to one and can be changed by changing the ratios of the feedback and gain

resistors (see the device datasheet for recommended resistor values). Each

input is terminated with a 50-Ωresistor to provide correct line-impedance

matching.

This EVM is optimized to work with ±1.65 power supplies. If the user tests the

deviceinasinglesupplymode(VDD=3.3V),thenthepropergroundingshould

be applied. The VOCM voltage level would be set at the mid rail (1.65-V when

VDD = 3.3 V). In general, the mid rail is the optimal area of the operation for

amplifiers. Therefore, if the device is operating at VDD = 3.3 V, it is

recommended that a dc offset be added to the input signal to shift it to the mid

rail.Havingtheinputsignalcenteredatthemidrailreducesthepeakingeffect.

RPU resistors in this EVM work as input signal level shifters. Therefore, they

canbe used toshift theinput signal level.To calculatethe RPU valuesuse the

following equation.

V(p) = V(pullup), RPU = R pullup (see EVM schematic)

RPU +V(p)*VDD

Ă(VI*V(P)) 1

Rg)(VO*V(p)) 1

The above equation is a good estimation tool for RPU. The user should

considerthe component error contribution tothe system. As a result,the RPU

number generated by the above equation could be changed slightly to

compensate for the error to provide the optimal result.

HavingVOCMlevelat1.65VabovetheGNDcausesacurrentflowfromVOCM

to GND. Consideration should be given to this current flow which will increase

the IDD.

1.2 Evaluation Module Features

THS4121 high-speed operational amplifier EVM features include:

JSingle and differential input and output capability

JNominal 50-Ωinput and output termination resistors. They can be

configured according to the application requirement.

JVOCM direct input control (see schematic and the device data sheet)

JVOCM pin can be controlled via transformer center-tap (see

schematic)

JShutdown pin control, JU1 (if applicable to the device, see the device

data sheet)

JInput and output transformer footprints for changing single-ended

signals to differential signals

Tabla de contenidos

Otros manuales de Amplificador de Texas Instruments

Texas Instruments

Texas Instruments Burr-Brown OPA569 Manual de usuario

Texas Instruments

Texas Instruments TPA3008D2EVM Manual de usuario

Texas Instruments

Texas Instruments TPA3120D2 Manual de usuario

Texas Instruments

Texas Instruments LM3886 Overture Manual de usuario

Texas Instruments

Texas Instruments TPA2018D1YZFEVM Manual de usuario

Texas Instruments

Texas Instruments TAS5601 Manual de usuario

Texas Instruments

Texas Instruments TPA311 Manual de usuario

Texas Instruments

Texas Instruments LM833 Instrucciones de funcionamiento y mantenimiento

Texas Instruments

Texas Instruments TAS54 4C Series Guía

Texas Instruments

Texas Instruments TPA751 MSOP Manual de usuario

Texas Instruments

Texas Instruments THS3001 Manual de usuario

Texas Instruments

Texas Instruments TPA6139A2 EVM Manual de usuario

Texas Instruments

Texas Instruments LM1896 Manual de usuario

Texas Instruments

Texas Instruments TPA6010A4 Manual de usuario

Texas Instruments

Texas Instruments TA5704EVM Manual de usuario

Texas Instruments

Texas Instruments CLC520 Manual de usuario

Texas Instruments

Texas Instruments TPA3116D2 Manual de usuario

Texas Instruments

Texas Instruments QFN Layout Manual de instrucciones

Texas Instruments

Texas Instruments SLOU082 Manual de usuario

Texas Instruments

Texas Instruments TPA3003D2 Manual de usuario

Texas Instruments

Texas Instruments THS4141 Manual de usuario

Texas Instruments

Texas Instruments TAS5707 Manual de usuario

Texas Instruments

Texas Instruments THS4271EVM-UG Manual de usuario

Texas Instruments

Texas Instruments TPA0233 Manual de usuario

Manuales populares de Amplificador de otras marcas

ASTRO

ASTRO HVO V40 P Manual de usuario

Marantz

Marantz SUPERSCOPE BLA-545 Instrucciones de montaje

NAD

NAD CI980 Manual de usuario

Technics

Technics SE-CH770 Manual de usuario

Harman Kardon

Harman Kardon HK6300 Manual de usuario

NAD

NAD T975 Manual de usuario

McIntosh

McIntosh MA6850 Manual de usuario

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manual de usuario

Viatron

Viatron Autrix Manual de usuario

GME

GME GA9800 Manual de usuario

Atlas

Atlas CP700 Manual de usuario

Roland

Roland KC-1000 Manual de usuario

Pyle

Pyle PFMRA350BW Manual de usuario

Advantage

Advantage S-250 Manual de usuario

IRT Electronics

IRT Electronics DVA-3007 Manual de usuario

Dimavery

Dimavery BA-100 Series Manual de usuario

Sony

Sony XM-S400D Manual de usuario

Schertler

Schertler ROY X Manual de usuario
