User's GuideSLOU189A – March 2007 – Revised April 2007

TPA3120D2 Audio Power Amplifier EVM

Contents1 Introduction .......................................................................................... 22 Operation ............................................................................................ 33 TPA3120D2 EVM Schematic ..................................................................... 44 TPA3120D2 EVM PCB Layers ................................................................... 55 TPA3120D2 Evaluation Module Parts List ...................................................... 7

List of Figures

1 TPA3120D2 Audio Power Amplifier EVM ....................................................... 22 TPA3120D2 EVM Schematic ..................................................................... 43 Top Side Layout .................................................................................... 54 Bottom Side Layout ................................................................................ 6

List of Tables

1 TPA3120D2 EVM Specifications ................................................................. 22 Gain Settings ........................................................................................ 33 TPA3120D2 EVM Bill of Materials................................................................ 7

SLOU189A – March 2007 – Revised April 2007 TPA3120D2 Audio Power Amplifier EVM 1Submit Documentation Feedback

www.ti.com

1 Introduction

Introduction

The TPA3120D2 evaluation module consists of a single 25-W, class-D, stereo audio power amplifiercomplete with a small number of external components mounted on a circuit board that can be used todirectly drive speakers with an external analog audio source as the input.

Table 1. TPA3120D2 EVM Specifications

VALUE UNIT

Supply voltage range 10 to 30 VI

Supply current, maximum 2 AP

Continuous output power, P

: 4 Ω, V

= 27 V, THD+N = 10% 24 WZ

Minimum load impedance 3.2 Ω

Figure 1. TPA3120D2 Audio Power Amplifier EVM

TPA3120D2 Audio Power Amplifier EVM2 SLOU189A – March 2007 – Revised April 2007Submit Documentation Feedback

www.ti.com

2 Operation

2.1 Quick Start List for Stand-Alone Operation

2.1.1 Power Supply

2.1.2 Evaluation Module Preparations

Operation

Follow these steps to use the TPA3120D2EVM stand-alone or when connecting it into existing circuits orequipment. Connections to the EVM module can be made by inserting stripped wire, or using bananaplugs for the power supply and output connections. The inputs accept standard RCA plugs.

1. Ensure that all external power sources are set to OFF.2. Connect an external regulated power supply adjusted from 10 V to 30 V to the module VCC (J7) andGND (J8) banana jacks taking care to observe marked polarity.

Inputs and Outputs:1. Connect an audio source to the input jacks, J9 and J10.2. Connect a speaker across GND (J5) and +ROUT (J6). Connect another speaker across LOUT (J3)and GND (J4)3. Install both gain jumpers GAIN0 (J1) and GAIN1 (J2). This sets the gain of the amplifier to the lowestlevel, 20 dB.

Control Inputs:1. SHUTDOWN: This terminal is active LOW. A LOW on the device terminal (<0.8 V) shuts down theamplifier; a HIGH (>2 V) on the device terminal places the amplifier in the active state. Holding downswitch SW1 places the amplifier in the SHUTDOWN state. Releasing SW1 returns the amplifier to theactive state. This terminal is V

compliant.2. MUTE: This terminal is active HIGH. A HIGH (>2 V) on this terminal will immediately terminate audioplayback through the speakers; a LOW (<0.8 V) enables the device. The outputs remain switching withfifty percent duty cycle. SW2 on the EVM controls the state of the MUTE terminal. Holding down switchSW2 places the amplifier in the MUTE state. Releasing SW2 returns the amplifier to the active state.This terminal is V

compliant.3. GAIN0/GAIN1: Together, these terminals determine the gain of the amplifier. See Table 2 . Installing ajumper in J1 or J2 sets the respective terminal to GND. Removing the jumper sets the respectiveterminals to VCC. Removing jumpers increases the gain while installing jumpers decreases the gain.Logic levels are TTL compatible. These terminals are V

compliant.4. Power-off Depop Circuit: Additional circuitry to quiet power-off pop has been provided on the EVM.This circuit consists of shunt regulator D1, bipolar transistor Q4, and the surrounding components. Thiscircuit is activated by installing the jumper J11 which connects Vcc to the network. The depop circuithas two different modes of operation. When R13 is installed, this circuit slowly pulls down the voltageon the Bypass pin when power is removed resulting in a controlled reduction of the Class D outputduty cycle. If R17 is installed, the network reduces the pop by pulling down the shutdown pin atpower-off. This approach can be used if the power supply operates in such a way that there is asignificant time delay between removal of power and the point where Vcc falls below the chip UVLOlevel, which is approximately 8 volts.

Table 2. Gain Settings

GAIN0 (J1) GAIN1 (J2) Amplifier Gain (dB)

ON ON 20ON OFF 26OFF ON 32OFF OFF 36

SLOU189A – March 2007 – Revised April 2007 TPA3120D2 Audio Power Amplifier EVM 3Submit Documentation Feedback

www.ti.com

2.1.3 Power Up

3 TPA3120D2 EVM Schematic

RIGHT_OUT

LEFT_IN

RIGHT_IN

LEFT_OUT

VCC

C9 open

C16 open

Circuit inside dotted line is

for power down de-pop

improvement.

10K

-LOUT

TP4TP4

SW1

SHUTDOWN

SW1

SHUTDOWN

TPA3120

PVCCL

MUTE

LIN

RIN

BYPASS

AGND

PVCCR

VCLAMP

PVCCR

12 PGNDR 13

PGNDR 14

ROUT 15

BSR 16

GAIN1 17

GAIN0 18

AVCC 19

AVCC 20

BSL 21

LOUT 22

PGNDL 23

PGNDL 24

THERMAL

C14

0.1uF C14

0.1uF

TP5TP5

4.75K

22uH

VCC

R12

10K

R12

10K

1.0uF C6

1.0uF

Dl4148

10K

C18

0.01uF

C18

0.01uF

R17 open

TP12

RGND

TP12

RGND

SW2

MUTE

SW2

MUTE

TP3TP3

C12 0.22uFC12 0.22uF C9

1.0uF

R16

20K

R16

20K

4.75K

470uF

GND

TP2TP2

J10

RIN

J10

RIN

4.75K

LIN

R18

10K

R18

10K

C10

470uF

C10

470uF

1 2

J11J11

TP10

GND

TP10

GND

C16

1.0uF

C16

1.0uF

10K

C15 0.22uFC15 0.22uF

R13

150K

R13

150K

TP7

RIGHT_OUT

TP7

RIGHT_OUT

-ROUT

GAIN0

C17

470uF

C17

470uF

1 2

1.0uF

R15 open

+LOUT

TP11

LGND

TP11

LGND

TP1

LEFT_IN

TP1

LEFT_IN

C19

0.68uF

C19

0.68uF

10K

MMBT3904

470uF

+ROUT

R10

C11 open

10pF

C11 open

10pF

C21 open

10pF

C13

10uF C13

10uF

1.0uF

GAIN1

C7 0.1uFC7 0.1uF

C20

0.68uF

C20

0.68uF

TP6

LEFT_OUT

TP6

LEFT_OUT

R11

2.49K

R11

2.49K

10K

R19

10K

TLV431ACDBZR

C1 0.1uFC1 0.1uF

TP9

INPUT_GND

TP9

INPUT_GND

TP8

RIGHT_IN

TP8

RIGHT_IN

22uH

1.0uF C5

1.0uF

TPA3120D2 EVM Schematic

1. Verify correct voltage and input polarity, and turn the external power supplies ON.

The EVM should begin operation.1. Adjust the input signal.2. Adjust the control inputs to the desired settings.3. Adjust the amplifier gain by installing/removing the gain jumpers, J1 and J2.

Figure 2. TPA3120D2 EVM Schematic

TPA3120D2 Audio Power Amplifier EVM4 SLOU189A – March 2007 – Revised April 2007Submit Documentation Feedback

www.ti.com

4 TPA3120D2 EVM PCB Layers

TPA3120D2 EVM PCB Layers

The following illustrations depict the TPA3120D2 EVM PCB layers.

Figure 3. Top Side Layout

SLOU189A – March 2007 – Revised April 2007 TPA3120D2 Audio Power Amplifier EVM 5Submit Documentation Feedback

www.ti.com

TPA3120D2 EVM PCB Layers

Figure 4. Bottom Side Layout

TPA3120D2 Audio Power Amplifier EVM6 SLOU189A – March 2007 – Revised April 2007Submit Documentation Feedback

www.ti.com

5 TPA3120D2 Evaluation Module Parts List

TPA3120D2 Evaluation Module Parts List

Table 3. TPA3120D2 EVM Bill of MaterialsReference Description Size Qty Status Manufacturer Part

Number

Capacitor, ceramic, 0.1uF, +/-10%, X7R,C1, C7, C14 0603 3 TDK C1608X7R1H104KT50V

C2, C8, C10,

Capacitor, Electrolytic, 470uF, 35 V Radial 4 Nichicon UHE1V471MH06C17

C3, C4, C5, Capacitor, ceramic, 1.0uF, +/-10%, X7R,

0603 4 Taiyo Yuden EMK107BJ105KA-TRC6 16V

Capacitor, ceramic, 1.0uF, +/-10%, X7R,C9, C16 0805 2 open TDK C3216X7R1H105K50V

Capacitor, ceramic, 0.22uF, +/-10%, X7R,C12, C15 0603 2 TDK C1608X7R1C224KT16V

Capacitor, ceramic, 10uF, +80%/–20%,C13 1210 1 Murata GRM32DF51H106ZA01LY5V, 50V

C19, C20 Capacitor, metal poly, 0.68uF, 63V Radial 2 EPCOS, inc. B32529C684J

Inductor, 22uH, radial lead, ferriteL1-L2 Radial 2 Toko A7503AY-220Mmaterial, shielded

R1-R4 Resistor, chip, 10 kohm, 1/16 W, 5% 0603 4 Panasonic ERA-V15J103V

R6, R7 Resistor, chip, 4.7 kohm, 1/10 W, 5% 0603 2 Panasonic ERJ-3GEYJ472V

R9, R10 Resistor, chip, zero ohm, 1/10 W, 5% 0603 2 Panasonic ERJ-3GEY0R00V

J1-J2 Phono Jack, PC mount, switched 2 Switchcraft PJRAN1X1U03

Banana Jack w/knurled Thumbnut (nickelJ3-J8 6 Johnson 111-2223-001plate)

J9-J10 Header, 2 position, Male 2mm 2 Norcomp 2163-36-01-P2

JP9-JP10

SHUNT, 2MM 2mm 2 Specialty 2JM-G(shunts)

SWITCH, MOMENTARY, SMD, LOWSW1, SW2 2 Panasonic EVQ-PPBA25PROFILE

Standoffs, 5/8" length, 4-40 thread 4 Keystone 1808

Screws, 4-40, .375 4

24 pinU1 TPA3120D2PWP 1 TI TPA3120D2PWPTSSOP

The following parts comprise the power-off depop circuit which is enabled by installing J11.

Capacitor, ceramic, 10 pf, +/-10%, C0G,C11, C21 0603 2 open Murata GRM1885C2A100RA01D100V

Capacitor, ceramic, 0.01 uF, +/-10%, X7R,C18 0603 1 TDK C1608X7R1H103K50V

D1 Shunt Regulator, Adjustable SOT-23-3 1 Texas Instruments TLV431ACDBZR

D2 Rectifier, Silicon, 0.15 A, 75V mini MELF 1 Micro Commercial DL4148-TP

Q4 Transistor, NPN, AMP SOT-23 1 Fairchild Semiconductor MMBT3904

R8 Resistor, chip, 4.7 kohm, 1/10 W, 5% 0603 1 Panasonic ERJ-3GEYJ472V

R11 Resisitor, chip, 2.49 kohm, 1/10 W, 1% 0603 1 Vishay CRCW06032K49FKEA

R12, R18, R19 Resistor, chip, 10 kohm, 1/16 W, 5% 0603 3 Panasonic ERA-V15J103V

R13 Resistor, chip, 150 kohm, 1/10 W, 1% 0603 1 Vishay CRCW0603150KJNEA

R15 Resistor, chip, 1 Megohm, 1/10 W, 1% 0603 1 open Vishay CRCW06031M00FKEA

R16 Resistor, chip, 20 kohm, 1/10 W, 1% 0603 1 Vishay CRCW060320K0FKEA

R17 Resistor, chip, 10 ohm, 1/16 W, 1% 0603 1 open Vishay CRCW060310R0FKEA

J11 Header, 2 position, Male 2mm 1 open Norcomp 2163-36-01-P2
