Targus wireless bluetooth notebook mouse Manual de usuario
Visit our Website at www.targus.com
Features and specifications are subject to change
without notice.
©2006 Targus Group International, Inc. and Targus, Inc.
AMB01US / 410-0007-001A
USER GUIDE
wireless
bluetooth
notebook
mouse
2
Table of Contents
Introduction ...........................................3
Installing the Software...........................4
Using the Bluetooth Mouse...................5
Initial Configuration ...............................7
Accessing the Bluetooth Configuration
Panel.....................................................7
Pairing Devices ...................................10
Basic Operations.................................13
To Pair with another device.................15
Start or Stop Bluetooth........................16
Mouse Power Management ................16
Operating Hints ...................................16
Specifications .....................................17
Troubleshooting ..................................18
Technical Support ...............................19
Product Registration............................20
Warranty..............................................20
AMB01US-10.book Page 2 Sunday, October 30, 2005 11:29 PM
3
TARGUS WIRELESS
BLUETOOTH
NOTEBOOK MOUSE
Introduction
Congratulations on your purchase of the Targus
Bluetooth Mouse. The Bluetooth software included offers
service to other Bluetooth devices from your computer,
such as: PIM Synchronization, PIM Item Transfers, File
Transfers, Network Access, Dial-up Networking and
Bluetooth Serial Port.
This user guide describes how to connect the mouse
adapter to your computer, install default software drivers
and set up the radio link.
In addition to this user guide this package contains:
• Targus Wireless Bluetooth Notebook Mouse
• Bluetooth USB Adapter
• USB Extension cable
• CD-ROM
• 2 AAA batteries
• Carrying Pouch
AMB01US-10.book Page 3 Sunday, October 30, 2005 11:29 PM
4
Targus Wireless Bluetooth Notebook Mouse
System Requirements
Hardware
• PC with a Pentium®processor or equivalent
•USBinterface
Operating System
• Windows®2000 or XP
Installing the Software
CAUTION: DONOT PLUG IN THE USB ADAPTER
UNTIL PROMPTED BY THE SOFTWARE.
1 Insert the software CD-ROM into your computer’s
CD-ROM drive.
The
InstallShield Wizard
screen appears.
If setup does not begin automatically, click Start, Run,
then enter D:\Setup.exe (where D: is the path of your
disc drive) and then click OK.
2 Click Next.
3The
License Agreement
screen appears.
4 Click
I accept the terms in the License Agreement
.
5 Click Next.
Follow the on-screen instructions.
The following screen will appear to prompt you to plug in
the USB adapter:
AMB01US-10.book Page 4 Sunday, October 30, 2005 11:29 PM
5
Targus Wireless Bluetooth Notebook Mouse
6 Plug the USB adapter into an available USB slot on
your computer.
7 Click OK.
The new hardware will be found and the installation
will finish.
8 You will be prompted to Restart your computer to
complete the installation.
NOTE: FOR ACOMPLETE USER GUIDE, PLEASE REFER TO THE MANUAL
LOCATED ON THE CD-ROM INCLUDED IN THIS PACKAGE.
Using the Bluetooth Mouse
Installing the Batteries
1 Remove the battery cover from the top of the mouse
by pressing the release latch at the bottom of the
mouse.
AMB01US-10.book Page 5 Sunday, October 30, 2005 11:29 PM
6
Targus Wireless Bluetooth Notebook Mouse
Top of Mouse Bottom of mouse
2 Insert the supplied batteries, making sure that the
positive (+) and negative (-) ends of each battery
match the polarity indicators inside the battery
housing.
WARNINGS: WHEN REPLACING THE BATTERIES, YOU MAY USE ALKALINE OR
OTHER HEAVY-DUTY NIMH BATTERIES. NEVER USE AN ALKALINE WITH A
NIMH BATTERY IN ADEVICE.
AVOID MIXING NEW AND USED BATTERIES IN ADEVICE.
3 Snap the battery cover back into position.
4 Turn on the mouse by sliding the on/off switch on the
bottom of the mouse to the “on” position.
Battery cover
On/Off switch
Release latch
AMB01US-10.book Page 6 Sunday, October 30, 2005 11:29 PM
7
Targus Wireless Bluetooth Notebook Mouse
Initial Configuration
Before you can begin using Bluetooth on your computer
and with other Bluetooth devices, you must perform
some initial setup.
NOTE: FOR ACOMPLETE USER GUIDE WITH DETAILED INSTRUCTIONS ON
CONFIGURING BLUETOOTH DEVICES, PLEASE REFER TO THE MANUAL LOCATED
ON THE CD-ROM INCLUDED IN THIS PACKAGE.
Accessing the Bluetooth
Configuration Panel
The Bluetooth Configuration Panel provides access to
settings for Bluetooth services, client applications,
hardware, security, discovery, accessibility, default paths,
event notification and other Bluetooth related items.
Open the configuration panel one of two ways:
Optical sensor
On/Off switch
Pairing
button
On
Off
AMB01US-10.book Page 7 Sunday, October 30, 2005 11:29 PM
8
Targus Wireless Bluetooth Notebook Mouse
• From the Windows Control Panel, select Bluetooth
Configuration; or
• In the Windows System Tray, right-click the Bluetooth
icon, and select Advanced Configuration from the
shortcut menu.
The following screen will appear:
The Configuration Wizard will take you through the initial
setup of your computer and configure a basic Bluetooth
environment.
You can select the locations you want the Bluetooth icon
to appear.
AMB01US-10.book Page 8 Sunday, October 30, 2005 11:29 PM
9
Targus Wireless Bluetooth Notebook Mouse
Next you will need to select a name for your computer
and indicate what type it is:
AMB01US-10.book Page 9 Sunday, October 30, 2005 11:29 PM
10
Targus Wireless Bluetooth Notebook Mouse
To configure the Bluetooth services that your computer
will offer to other Bluetooth devices, click Next.
Follow on-screen instructions to complete your settings.
NOTE: FOR ACOMPLETE USER GUIDE WITH DETAILED INSTRUCTIONS ON
CONFIGURING BLUETOOTH DEVICES, PLEASE REFER TO THE MANUAL LOCATED
ON THE CD-ROM INCLUDED IN THIS PACKAGE.
Pairing Devices
Pairing allows you to avoid entering access information
each time a connection is attempted. Paired devices
share a unique link key, which they exchange each time
they connect.
AMB01US-10.book Page 10 Sunday, October 30, 2005 11:29 PM
