Stratasys F3300 Instrucciones de funcionamiento

Part No. 413183-0001_REV_A

F3300®

3D Printer

Site Preparation Guide

Page ii

This documentation contains proprietary information of Stratasys Ltd. This information is supplied solely to

assist authorized users of this Stratasys 3D printing system. No part of this document may be used for other

purposes, and it may not be disclosed to other parties. The specifications on which this document is based

are subject to change without notice. No part of this book may be reproduced in any form or by any means,

nor stored in a database or retrieval system, without prior permission in writing from Stratasys Ltd.

If this document is distributed as a PDF file, you may print it for internal use.

Part No. 413183-0001_REV_A

Liability

Stratasys shall not be liable for errors contained herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this material. Stratasys makes no warranty of any kind

with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness

for a particular purpose. It is the responsibility of the system owner/material buyer to determine that Stratasys

material is safe, lawful, and technically suitable for the intended application as well as identify the proper

disposal (or recycling) method consistent with local environmental regulations. Except as provided in

Stratasys' standard conditions of sale, Stratasys shall not be responsible for any loss resulting from any use of

its products described herein.

Trademarks

Stratasys, GrabCAD, Insight, and FDM are trademarks of Stratasys and/or subsidiaries or affiliates and may

be registered in certain jurisdictions. All other product names and trademarks cited in this book are the

property of their respective owners.

Page iii

Contents

Revision Log ................................................................................................. iv

Safety............................................................................................................ iv

Safe Environment................................................................................................................ iv

About the F3300 Printer................................................................................. 1

Components ........................................................................................................................ 1

Highlights............................................................................................................................. 1

How to Use This Guide........................................................................................................ 1

Site Preparation Tasks................................................................................... 2

Selecting the Installation Site .............................................................................................. 2

Physical Specifications and Space Requirements .............................................................. 2

Environmental Requirements .............................................................................................. 5

Electrical Requirements ...................................................................................................... 6

Compressed Air Requirements ........................................................................................... 7

LAN Requirements .............................................................................................................. 9

Workstation Requirements .................................................................................................. 9

Preparing for Installation.............................................................................. 10

Inspect Crate for Damage ................................................................................................. 10

Required Tools and Equipment ......................................................................................... 10

Moving the Crated Printer ................................................................................................. 10

Unpacking the Printer......................................................................................................... 11

Electrical Service Connection ...................................................................... 22

Site Preparation Checklist ........................................................................... 24

Electrical Installation Requirements .................................................................................. 24

Environmental Requirements ............................................................................................ 24

Required Installation Tasks................................................................................................ 24

Site Preparation Guide Revision Log

Page iv

Revision Log

The following table lists the main changes in each revision of this document.

Safety

The following basic safety tips are given to ensure safe installation, operation, and

maintenance of Stratasys equipment and are not to be considered as comprehensive on

matters of safety. Although the F3300 printers are designed to be safe and reliable, access to

areas of the printer are potentially dangerous.

Safe Environment

• Connect equipment to a grounded facility power source. Do not defeat or bypass the

ground lead.

• Know the location of equipment branch circuit interrupters or circuit breakers and how to

turn them on and off in case of emergency.

• Know the location of fire extinguishers and how to use them. Use only ABC type

extinguishers on electrical fires.

• Know local procedures for first aid and emergency assistance at the customer facility.

• Use adequate lighting at the equipment.

• Maintain the recommended range of temperature and humidity in equipment area.

• Do not use this product in an environment containing volatile or flammable compounds.

Translations of this guide are updated periodically. If you are consuming a translated version, please

check the English version for the latest revision and list of updates.

Revision Date Description of Changes

A November 2023 First release of this document.

Site Preparation Guide About the F3300 Printer

Page 1

About the F3300 Printer

The Stratasys F3300 3D printer is the first product in a new F3000 series platform. The F3300

is a multi-extruder Fused Deposition Modeling (FDM) printer designed for the smart

manufacturing floor. It incorporates the latest in innovative technology to provide leading FDM

performance in throughput, part quality and reliability. It can produce jigs, fixtures and

production parts that exceed expectations in build time, cost and quality. It will also allow users

to achieve results in ROI with traceability, data analytics and future expansion possibilities. The

Stratasys F3300 printer provides advanced 3D printing for intelligent industrial performance.

Components

• The F3300 printer

• Welcome kit (containing documentation on how to download your user guide and common

tools for maintaining the printer)

• GrabCAD Print and/or Insight software package

• A computer workstation for preparing build files (not sold by Stratasys)

Highlights

• Maximum build area of 600 x 600 x 800 mm (23.6 x 23.6 x 31.5 inch)

• Integrated tool changer with capacity for four extruders

• Four heated material bays

• Automatic calibration

• Large touchscreen graphical user interface

• Two internal cameras for remote monitoring

How to Use This Guide

This guide provides information for selecting an appropriate location for the F3300 printer. This

guide also provides instructions for unpacking and preliminary set-up. Information of special

importance is presented in one of three formats:

A Warning: indicates a procedure that may cause injury to an operator if the

procedure is not followed.

A Warning: will precede the paragraph of instruction to which it relates.

A Caution: indicates a procedure that may cause damage to equipment if the

procedure is not followed.

A Caution: will precede the paragraph of instruction to which it relates.

A NOTE is used to highlight a specific point or to provide an operational tip. While

useful, a NOTE does not indicate a procedure that can cause injury or damage if it is

not followed.

A NOTE will follow the paragraph of instruction to which it relates.

Site Preparation Guide Site Preparation Tasks

Page 2

Site Preparation Tasks

Selecting the Installation Site

Decide where to install the printer based on the following:

1. Space Requirements

2. Environmental Requirements

3. Electrical Requirements

4. Compressed Air Requirements

5. LAN Requirements

Physical Specifications and Space Requirements

Dimensions and Weights

Make sure that the installation site floor space can accommodate the printer’s weight and

dimensions, plus required clearances. The installation location must be a flat level surface that

is stable and capable of holding 1452 kg (3200 lbs).

The F3300 printer does not have casters. Due to the size of the printer, a forklift

is required to move the crated system to an un-boxing location and to the final

selected installation site.

The F3300 printers are capable of generating vibrations depending mainly on

part build geometry and material characteristics. This consideration will need to

be taken into account if locating the printer near vibration sensitive equipment.

Warning:

Due to the physical size and weight of the F3300 printer, it is required to use a

forklift or pallet jack when moving the printer.

Description Weight Dimensions

Printer Crated 1724 kg (3800 lbs)

Width: 243.8 cm (96 in)

Depth: 203.2 cm (80 in)

Height: 254.5 cm (100.2 in)

Printer

Uncrated 1360 kg (3000 lbs)

Width: 203.2 cm (80 in)

Depth: 162.6 cm (64 in)

Height:

• Without light tower: 218.4 cm (86 in)

• With light tower: 236.2 cm (93 in)

Site Preparation Guide Site Preparation Tasks

Page 3

Figure 1: F3300 Printer Overall Dimensions

Figure 2: Printer Center of Mass

Site Preparation Guide Site Preparation Tasks

Page 4

Minimum Operational Clearances

Sufficient side clearances allow for proper air circulation and maintenance access, while the

recommended front and rear clearances also allows enough room to open doors to the oven

and electronics bay. The top hinged covers require additional overhead clearance to fully open.

Figure 3: Minimum Clearances

Side Clearance Minimum 36 inches (91.4 cm) on each side

Rear Clearance Minimum 36 inches (91.4 cm)

Front Clearance Minimum 50 inches (127 cm)

Overhead Clearance Minimum 20 inches (50.8 cm)

127 cm

[50 in]

Rear

91.4 cm

[36 in]

91.4 cm

[36 in]

Front

Overhead 50.8 cm

[20 in]

91.4 cm

[36 in]

Site Preparation Guide Site Preparation Tasks

Page 5

Environmental Requirements

• Printer shipping temperature shall be in the range of -40°C to 70°C (-40°F to 158°F). In

freezing temperatures, bring the printer indoors and leave crated until the it reaches room

temperature.

• Air quality conditions with excessive solid particulates (conductive or non-conductive) may

result in system damage.

• Air quality conditions in which airborne oils are allowed to accumulate on or within the

printer can damage the plastic components.

• System operating temperature shall be in the range of 15°C to 30°C (60°F to 86°F), with

relative humidity range of 20% to 80% non-condensing.

• System storage temperature shall be in the range of 0°C to 35°C (32°F to 95°F), with

relative humidity range of 20% to 90% non-condensing.

• Altitude shall not exceed 3000 m (9843 ft).

• Material storage shall be in the range of 13°C to 30°C (55°F to 86°F), with relative humidity

less than 70%.

• Noise emission (acoustic): <65dBA when idle and when building

Heat Output

TBD

Power Consumption

TBD

Site Preparation Guide Site Preparation Tasks

Page 6

Electrical Requirements

The facility power is required to meet the following power quality and nominal voltage

requirements:

• 50 Hz/ 60 Hz dedicated circuit (47 to 63 Hz)

• 3-phase, 5-wire wye (L-L-L-N-G), 208VAC, 30A circuit with frequency range (47-63Hz.)

• Input voltage tolerance is ±10% from nominal (187 to 229VAC)

• Peak operating current: 23A

• Dedicated circuit: 30 A

• Leakage (touch) current: <1.0mA (under all conditions)

• Site must include a disconnecting means that is readily accessible and within sight of the

printer during operation. Possible connection methods include cord and plug attachment or

direct wiring.

• The connection method and required disconnecting means shall be installed in accordance

with all applicable electrical codes and approved by the authority having jurisdiction.

• Site must be equipped with appropriate lockout tagout kit for equipment.

Operation of the system outside this range is not recommended and degradation of the system

performance and shortened component life expectancy will be experienced.

The system is to be operated on a 3-phase service meeting the recommendations for power

quality given in IEEE Standard 141-1993. Facilities who are unsure of their power quality

should contact their service provider.

Tabla de contenidos

Otros manuales de Impresora 3D de Stratasys

Stratasys

Stratasys K6 Series Manual de usuario

Stratasys

Stratasys H350 Manual de usuario

Stratasys

Stratasys J826 Manual de usuario

Stratasys

Stratasys Fortus 360mc Instrucciones de funcionamiento

Stratasys

Stratasys Objet260 Connex Manual de usuario

Stratasys

Stratasys Objet260 Connex Manual de usuario

Stratasys

Stratasys Fortus 250mc Manual de usuario

Stratasys

Stratasys Objet1000 Plus Manual de usuario

Stratasys

Stratasys Dimension BST 1200 Manual de usuario

Stratasys

Stratasys Origin One Manual de usuario

Stratasys

Stratasys FDM 2000 Manual de usuario

Stratasys

Stratasys Prodigy Plus Manual de usuario

Stratasys

Stratasys J850 Manual de usuario

Stratasys

Stratasys Finishing Touch Manual de usuario

Stratasys

Stratasys Objet30 Manual de usuario

Stratasys

Stratasys J850 Manual de usuario

Stratasys

Stratasys Objet30 Manual de usuario

Stratasys

Stratasys Origin One Manual de usuario

Stratasys

Stratasys Fortus 250mc Instrucciones de funcionamiento

Stratasys

Stratasys Fortus 450mc Manual de usuario

Stratasys

Stratasys Fortus 900mc Guía de referencia

Stratasys

Stratasys Fortus 900mc Instrucciones de funcionamiento

Stratasys

Stratasys Objet260 Connex Manual de usuario

Stratasys

Stratasys Fortus 360mc Manual de usuario

Manuales populares de Impresora 3D de otras marcas

Ultimaker

Ultimaker S5 Material Station Manual de usuario

EcubMaker

EcubMaker TOYDIY Manual de usuario

AnyCubic

AnyCubic Kossel Plus Manual de usuario

ReDeTec

ReDeTec ProtoCycler Manual de usuario

Kywoo3D

Kywoo3D Tycoon IDEX Manual de usuario

CraftBot

CraftBot PLUS PRO Manual de usuario

3DGence

3DGence INDUSTRY F340 Manual de usuario

HP Jet Fusion 4200 Instrucciones de funcionamiento

Rokit

Rokit AEP Series Manual de usuario

AnkerMake

AnkerMake M5 Manual de usuario

DIYElectronics

DIYElectronics PRUSA I3 Instrucciones de montaje

Ackuretta

Ackuretta FreeShape 120 Manual de usuario

LONGER

LONGER LK5Pro Manual de usuario

MakerBot

MakerBot Replicator Manual de usuario

ZYYX

ZYYX Pro II Manual de usuario

FLASHFORGE 3D PRINTER

FLASHFORGE 3D PRINTER Creator Guía del usuario

LONGER

LONGER LK4 Pro Manual de usuario

German RepRap

German RepRap X400 Pro V3 Manual de usuario
