StarTech.com IES81000POE Manual de usuario

Manual Revision: 10/23/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IES81000POE

8 Port Unmanaged Gigabit Ethernet PoE+

PSE Switch - 30W per Port

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

LED Indicators.........................................................................................2

Installation .............................................................................................3

Wall-Mounting ........................................................................................................................................... 3

Hardware Installation .............................................................................................................................. 3

Specications..........................................................................................4

Technical Support ..................................................................................5

Warranty Information............................................................................5

Instruction Manual

Product Diagram

Front View

Rear View

Instruction Manual

Introduction

Packaging Contents

• 1 x Gigabit Ethernet PoE Switch

• 4 x Mounting Screws

• 2 x Wallmount Brackets

• 1 x Set, Rubber Feet

• 1 x Universal Power Adapter

• 3 x Power Cords (NA /UK /EU)

• 1 x Instruction Manual

LED Indicators

LED Function

Power (1) Solid - power is on and normal

ACT (Per Port, 8 total) On – Port is connected

O – No connection

10/100M (Per Port, 8 total) On – Connected at 100Mbps

O - Connected at 10Mbps

1000M (Per Port, 8 total) On – Connected at 1000Mbps

PoE (Per Port, 8 total)

On - Power over Ethernet function is enabled

O - PoE function is disabled, behaving as a regular

LAN port

Instruction Manual

Installation

Wall-Mounting

1. Attach the wall mount brackets to the switch (one per side) using the screws

provided.

2. Depending on the mounting surface, use the appropriate hardware to mount to the

wall surface.

Hardware Installation

1. Plug one end of the power adapter into an open electrical outlet and the other into

the DC connector on the rear panel of the Network Switch. The Power LED on the

front of the Switch should now be lit.

2. Connect a network cable to port 1 on the front panel of the switch, and connect the

other end of the cable into the RJ-45 port on your upstream switch or router. The

connection speed should auto-detect and the appropriate LEDs will illuminate to

show activity.

3. Connect your PoE or non-PoE devices to the remaining ports on the switch (e.g.

computer, IP Phone, IP Camera, etc.). The switch will auto-detect connection speed

and whether PoE is required, and the appropriate LEDs will illuminate and show

activity.

Instruction Manual

Specications

Number of Ports 8

Compatible Networks 10/100/1000 Mbps

Industry Standards

IEEE 802.3at/af Power Over Ethernet, IEEE

802.3 10BASE-T, IEEE 802.3u 100BASE-TX,

IEEE 802.3ab 1000BASE-TX, IEEE 802.3x

Flow Control

PoE Output 52V DC, 30W (per-port)

Connectors 8 x RJ-45 Female

Maximum Data Transfer Rate 2 Gbps (Full-Duplex)

Switching Architecture Store-and-Forward

Buer Size 128 KB

Full Duplex Yes

Auto MDIX Yes

Flow Control Half-duplex back-pressure and IEEE802.3x

full-duplex

Power Consumption 120W Max

Power Adapter 52V DC, 2.5A

Enclosure Material Steel

Operating Temperature 0°C to 55°C (32°F to 131°F)

Storage Temperature -20°C to 90°C (-4°F to 194°F)

Humidity 10~90% RH (Non-Condensing)

Dimensions 188 x 119 x 38 mm

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
