StarTech.com SV431DLU3A Manual de usuario

Manual Revision: 11/12/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SV231DLU3A / SV431DLU3A

2/4 Port SuperSpeed USB 3.0 Dual-Link DVI

KVM Switch with Audio and Cables

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View - SV231DLU3A ...................................................................................................................... 1

Rear View ..................................................................................................................................................... 1

Front View - SV431DLU3A ...................................................................................................................... 2

Rear View ..................................................................................................................................................... 2

Introduction............................................................................................3

Packaging Contents ................................................................................................................................. 3

System Requirements.............................................................................................................................. 3

Installation ..............................................................................................4

Hardware Installation .............................................................................................................................. 4

Driver Installation...................................................................................................................................... 4

Operation ................................................................................................5

Front Panel................................................................................................................................................... 5

Hotkey Control........................................................................................................................................... 5

Specications..........................................................................................8

Technical Support ..................................................................................9

Warranty Information............................................................................9

Instruction Manual

Product Diagram

Front View - SV231DLU3A

PC1

connectors

USB Keyboard/

Mouse

Connectors

Console DVI-I

Connector

(output)

DC Power

Connector

USB 3.0 HUB

connectors

3.5mm Audio

Speaker/Mic

Rear View

USB Hub

Selection LED

Port Selection

Button / LED

Instruction Manual

Front View - SV431DLU3A

Rear View

USB Hub

Selection LED

Port Selection

Button / LED

PC1

connectors

USB Keyboard/

Mouse

Connectors

Console DVI-I

Connector

(output)

DC Power

Connector USB 3.0 HUB

connectors

3.5mm Audio

Speaker/Mic

Instruction Manual

Introduction

Packaging Contents

SV231DLU3A

• 1 x 2 Port USB 3.0 KVM Switch

• 2 x DVI-D M/M Cables

• 2 x USB 3.0 A-B Cables

• 2 x 3.5mm Audio/Mic Cables

• 1 x Universal Power Adapter (NA/ UK/ EU)

• 1 x Instruction Manual

SV431DLU3A

• 1 x 4 Port USB 3.0 KVM Switch

• 4 x DVI-D M/M Cables

• 4 x USB 3.0 A-B Cables

• 4 x 3.5mm Audio/Mic Cables

• 1 x Universal Power Adapter (NA/ UK/ EU)

• 1 x Instruction Manual

System Requirements

• One DVI display device (i.e. monitor, projector, TV, etc.)

• A DVI output for each computer

• USB enabled computer system with available USB port

• Standard 104-key keyboard

• Standard 3-button mouse

Instruction Manual

Installation

Hardware Installation

1. Connect a DVI monitor into the Console’s DVI connector; plug a USB keyboard and a

USB mouse into the dedicated USB keyboard and mouse ports on the KVM switch. If

using audio, also connect speakers with 3.5mm mini-jack plugs.

2. Use a male-to-male DVI-D video cable to connect the DVI connector on the

computer’s video card, to the DVI ports for one of the KVM’s PC ports (i.e. PC1).

3. Use a USB type A-B Cable to connect the KVM’s USB port (type B, square connector)

for the PC port used in Step 2, and the USB port on the computer (type A, at

connector). If using audio, connect 3.5mm mini-jack cables from the PC port to the

sound card.

4. Repeat Steps 2 and 3 for each PC port on the KVM switch, or each computer you

wish to use on the KVM.

OPTIONAL: Connect any other USB peripherals you wish to share between the

connected computers/devices to the extra USB Hub port on the Console side.

5. Connect the external power adapter from a wall outlet to the power connector on

the rear panel of the KVM switch.

6. Power up the rst computer/device and wait for it to fully boot and test keyboard/

mouse functionality.

7. Once operation has been successfully conrmed, switch to the next port and power

up that computer/device and conrm.

8. Once completed for all computers/devices connected to the KVM switch, you

should be able to switch between ports freely.

Driver Installation

No driver installation is required for the KVM switch, as the keyboard/mouse use USB

drivers that are already installed on any operating system that fully supports USB.

Instruction Manual

Operation

Front Panel

The front-panel Smart Touch button allows you a direct control over KVM switching

operation. Simply press the button to switch to the respective PC port. For more

operation about Smart Touch button, please refer to “Quick Reference Sheet”.

Hotkey Control

A Hotkey command is a short keyboard sequence for selecting a computer, activating

computer scan, etc. A hotkey sequence starts with two left <ScrLk> keystrokes

(successively within 2 seconds) followed by one or two more keystrokes. A built-in

tone generator creates a high-pitch beep for correct hotkey command; otherwise, one

low-pitch beep is generated for errors and the bad key sequence will not be forwarded

to the selected computer.

Please refer to the “Quick Reference Sheet” for available commands

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Select PC Port

(Jointly select

PC port/ hub

port control/

audio&mic,

if binding is

enabled)

ScrLk + ScrLk +

(1~2/1~4)

Touch the

corresponding

button to select

the active PC port.

Select the PC port

Select Hub Port

Control (Jointly

select PC and

hub port control,

if binding is

enabled)

ScrLk + ScrLk +

F1~F2/F1~F4

Touch the button

to toggle the

specic PC+USB

hub port control.

(It works only if

PC port/ hub port

control binding is

enabled.)

Move Hub Port

(1~2 / 1~4)

Instruction Manual

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Select Audio&Mic

Port (Jointly

select PC port

and audio&mic,

if binding is

enabled)

ScrLk + ScrLk +

F5~F6/F5~F8 -- Move audio&mic

port

Bind PC and Hub

Port Control

Switching

ScrLk + ScrLk + Z -- Bind PC Port with

Device Hub Port

Unbind PC and

Hub Port Control

Switching

ScrLk + ScrLk + X --

Unbind PC Port

with Device Hub

Port

Bind PC and

Audio&Mic

Switching

ScrLk + ScrLk + Q -- Bind PC Port with

audio&mic Port

Unbind PC and

Audio&Mic

Switching

ScrLk + ScrLk + W --

Unbind PC port

with audio&mic

Port

Previous PC port

(Jointly select PC/

hub port control,

if binding is

enabled)

ScrLk + ScrLk + Up

Arrow -- Next lower PC Port

Next PC port

(Jointly select PC/

hub port control,

if binding is

enabled)

ScrLk + ScrLk +

Down Arrow -- Next higher PC

Port

Instruction Manual

Quick Reference Sheet

Command Hotkeys

Front-Panel

Smart Touch

Button

Description

Previous active PC

port

ScrLk + ScrLk +

[Backspace] -- Previous active

PC Port

Beeper ScrLk + ScrLk + B -- Toggle Beeper

On/O

Dene Hotkey

Preceding

Sequence

ScrLk + ScrLk +

H+ [ScrLk/CapsLk/

Esc/F12/ NumLk/

left Ctrl/ right Ctrl]

Press and hold

down last button

(Button 2/

Button 4) till two

beeps. Release

the button, and

press desired

hotkey preceding

sequence.

Select Hotkey

Header [ScrLk/

CapsLk/ Esc/ F12/

NumLk/ left Ctrl/

right Ctrl]

Autoscan ScrLk + ScrLk + S -- Start Autoscan

Autoscan with

Programmable

Delay Time

ScrLk + ScrLk + S

+ (1~6)

1 10s ; 2 20s ;

3 30s ;

4 40s ; 5 50s ;

6 60s

Autoscan duration

adjust to (10~60

seconds)

Stop Autoscan [Any key] Touch any button Stop Autoscan

during scan mode

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cambiar de StarTech.com

StarTech.com

StarTech.com DS254 Manual del sistema

StarTech.com

StarTech.com HB30C3AGEPD Manual de usuario

StarTech.com

StarTech.com VS721MULTI Manual de usuario

StarTech.com

StarTech.com ST4200MINI Manual de usuario

StarTech.com

StarTech.com VS410RVGAA Manual de usuario

StarTech.com

StarTech.com STARVIEW SV831SUN Manual de usuario

StarTech.com

StarTech.com SV231USBA Manual de usuario

StarTech.com

StarTech.com ST122VGA Manual del sistema

StarTech.com

StarTech.com SV831DUSBA Manual de usuario

StarTech.com

StarTech.com ST3300GU3B Manual de usuario

StarTech.com

StarTech.com C2-H46-UC2-PD-KVM Manual de usuario

StarTech.com

StarTech.com 8STMSTMDP124DP Manual de usuario

StarTech.com

StarTech.com StarView SV1631D Manual de usuario

StarTech.com

StarTech.com DS52000 Manual de usuario

StarTech.com

StarTech.com STARVIEW SV1631DUSB Manual de usuario

StarTech.com

StarTech.com SV831DUSBAU Manual de usuario

StarTech.com

StarTech.com ST4300USBM Manual de usuario

StarTech.com

StarTech.com 8STMSTCDP123DP Manual de usuario

StarTech.com

StarTech.com 8ST35BAYUSB3S4 Manual de usuario

StarTech.com

StarTech.com SV231MDPU2 Manual de usuario

StarTech.com

StarTech.com VS421HD4KA Manual de usuario

StarTech.com

StarTech.com VS410RVGAA Manual de usuario

StarTech.com

StarTech.com DisplayPort SV231QDPU34K Manual de usuario

StarTech.com

StarTech.com ES3116 Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
