StarTech.com PCIIDE2 Manual de usuario

IDE ATA/133 Controller

PCIIDE2 Instruction Manual

Actual product may vary from photo

2 Port PCI ATA-133 IDE Adapter Card

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Windows 98/98SE/ME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Windows 2000/XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Windows NT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com ATA/133 IDE controller card. This product is

perfect for adding additional hard drives and other IDE/ATAPI compliant devices to a

computer that does not have any available IDE connections, replacing a failed onboard

IDE controller, or upgrading a computer to take advantage of ATA/133 speeds.

Features

• Two independent DMA/ATA channels

• Compliant with PCI Specification rev. 2.2, PCI ATA Controller Specification rev 1.0

• Supports up to four DMA/ATA devices

• 256 Bytes buffer

Before You Begin

WARNING! PCI cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your PCI card. StarTech.com recommends that you wear an anti-static strap

when installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds. Also be careful to handle the PCI card

by its edges and not the gold connectors.

System Requirements

• A Pentium-based computer with an available PCI slot

• Windows (98SE, ME, NT, 2000, XP) Linux

Contents

This package should contain:

• 1 x PCI ATA/133 IDE PCI Controller Card

• 1 x 40-pin, 80-wire IDE Data Cable

• 1 x Driver CD

• 1 x Installation Guide

Instruction Manual

IInnssttaallllaattiioonn

This section will guide you through the installation of your card. Please read through the

instructions carefully and complete each step in the order listed.

If you are using Windows 98, 98SE, or ME, please follow the software installation

instructions on the next page before installing the card. Other users can install the card

now before completing the software installation.

Installing the Card

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system (see your computer's user manual for details, if

necessary) and gently turn your computer onto its side.

3. Locate an empty PCI slot (usually white in color) and remove the metal plate that

covers the rear bracket. You may need a Phillips screwdriver to perform this step.

Retain the screw! You will need it to secure the card later.

4. Gently insert the card into the empty slot, making sure it is firmly seated.

5. Secure the card in place using the screw you removed in Step 3.

6. Install the devices you wish to use with the card into the case following the

instructions provided in their documentation.

7. Use the 80-wire IDE cable (provided) to attach the devices you are using to the

controller. Be sure to observe master/slave settings, and that the red stripe on the

cable faces pin 1 on the connectors for both the card and the device. If you are

attaching more than two devices to the controller, you will need to purchase an

additional IDE cable.

NOTE:The primary master device on the card must be a hard disk.

6. Put the computer case back on.

Instruction Manual

PCI

Slots

Software Installation

Windows 98/98SE/ME

1. Power on the host computer, and ensure that Windows is fully booted (desktop is

visible)

Instruction Manual

2. Windows will detect that ITE IT8212 ATA PCI

Controller has been connected, and will launch

the Add New Hardware Wizard. Select Specify

the location of the driver (Advanced) and click

2. Insert the Driver CD into the CD-ROM/DVD-ROM drive, then select Search for the

best driver for your device (Recommended) and type D:\WIN98_ME in the field

designating the file location. Press Next to continue setup.

3. Once Windows notifies you that the driver

for ITE IT8212 ATA PCI Controller has

been found, press Next to continue

setup.

4. Once the driver installation has

completed, click Finish to continue:

5. You will be asked to restart your computer. Please do so, to allow the driver

installation to take effect.

Windows 2000/XP

Please note: Installation steps for Windows 2000 and Windows XP will very similar if not

identical. The following instructions are based on Windows 2000, but apply to Windows

XP installation as well:

1. Power on the host computer, and ensure that Windows is fully booted (desktop is

visible)

Instruction Manual

6. Once the computer has rebooted, you may

want to verify that installation has successfully

completed. To do so, right-click on My

Computer and select Manage.

On the left side of the window that opens,

click on Device Manager. Click on the [+]

sign next to SCSI Controllers, where you

should notice ITE IT8212 ATA PCI

Controller listed, indicating that installation

was successful.

2. Windows will detect that ITE IT8212 ATA PCI Controller has been connected, and

will launch the Add New Hardware Wizard. Select Search for a suitable driver for

my device (recommended), and click Next to continue setup.

3. Insert the Driver CD into the CD-ROM/DVD-

ROM drive, and select Install from a list or

specific location. In the dialog and click

Next to continue setup:

Instruction Manual

5. When Windows indicates that the correct driver has been located, click on Next to

continue setup.

6. When you are notified that the Found New

Hardware Wizard has finished installing the

drivers for ITEIT8212 ATA PCI, click Finish to

continue, and restart the computer for the

installation to take effect:

7. Once the computer has rebooted, you may

want to verify that installation has successfully

completed. To do so, right-click on My

Computer and select Manage.

On the left side of the window that opens,

click on Device Manager. Click on the [+]

sign next to SCSI and RAID Controllers,

where you should notice ITE IT8212 ATA PCI

Controller listed, indicating that installation

was successful.

If there is a ?or !symbol next to the ITE

IT8212 ATA PCI Controller, it indicates that

the driver has not installed correctly. If this is

the case, please remove the device and

reinstall.

4. In the dialog box provided, type D:\WIN2K_XP

to indicate the proper file location. Click on

Next to continue setup.

Windows NT

1. Power on the host computer, and ensure that Windows is fully booted (desktop is

visible)

2. Click on the Start button, select Settings, and choose Control Panel.

Instruction Manual

3. In the Control Panel, double-click on the

SCSI Adapters icon.

4. From the SCSI Adapters window, choose the

Drivers tab, and press Add to continue.

4. From the Install Drivers window, click on Have Disk. Insert the Driver CD, and type

D:\WINNT (CDROM) in the field designating the file location. Press OK to continue

setup.

5. Select ITE IT8212 ATA PCI Controller and

click OK to continue.

6. When you are instructed to reboot the computer, please do so, for the driver

installation to take effect.

TTrroouubblleesshhoooottiinngg

Q: When the computer is powered on, no video appears on the screen or the floppy drive

light stays on and the drive doesn’t work.

A: The cable may be plugged in backwards. Make sure the cable is plugged in correctly.

This is done by examining the cable to confirm the red stripe is aligned with Pin 1 on

both ends.

Q: When I boot up my computer, I receive an “HDD Controller failure” message.

A: 1)First, make sure the port is enabled.

2)If the port is enabled, check that all cables are connected properly, including

the power cable.

3)Verify that no equivalent drive controller is active in the BIOS.

Instruction Manual

7. Once the computer has rebooted, you may want to verify that installation has

successfully completed. To do so, revisit the Control Panel, and open the SCSI

Adapters window. If ITE IT8212 ATA PCI Controller is displayed in the Devices

panel as shown below, the driver has been installed successfully:

Otros manuales para PCIIDE2

Tabla de contenidos

Otros manuales de Tarjeta PCI de StarTech.com

StarTech.com

StarTech.com PEXUSB311A1C Manual de usuario

StarTech.com

StarTech.com PEXUSB3S23 Manual del sistema

StarTech.com

StarTech.com PCI220USB Manual de usuario

StarTech.com

StarTech.com PCI330USB2 Manual de usuario

StarTech.com

StarTech.com PEXHDCAP Manual de usuario

StarTech.com

StarTech.com PEXESATA2 Manual de usuario

StarTech.com

StarTech.com PEXUSB311AC2 Manual de usuario

StarTech.com

StarTech.com PEX16S952LP Manual de usuario

StarTech.com

StarTech.com PCI1S550 Manual

StarTech.com

StarTech.com PCIESATA2I Manual de usuario

StarTech.com

StarTech.com PEX100SFP Manual del sistema

StarTech.com

StarTech.com PEX1394B3 Manual de usuario

StarTech.com

StarTech.com P021GI-NETWORK-CARD Manual de usuario

StarTech.com

StarTech.com PEX1000SFP2 Manual de usuario

StarTech.com

StarTech.com PEXUSB311AC3 Manual de usuario

StarTech.com

StarTech.com 21050-PC-SERIAL-CARD Manual de usuario

StarTech.com

StarTech.com PCISAT2F3U4 Manual de usuario

StarTech.com

StarTech.com PEX1000MMSC Manual de usuario

StarTech.com

StarTech.com PEX4RISER Manual de usuario

StarTech.com

StarTech.com PEX2S952PW Manual de usuario

StarTech.com

StarTech.com PEXUSB400 Manual de usuario

StarTech.com

StarTech.com PEX8S950LP Manual de usuario

StarTech.com

StarTech.com PEXUSB3S7 Manual de usuario

StarTech.com

StarTech.com PEX1394A2DV Manual de usuario

Manuales populares de Tarjeta PCI de otras marcas

ERMA

ERMA SSI 1417 Manual de usuario

SIIG

SIIG CyberSerial Dual PCI Instrucciones de montaje

Moxa Technologies

Moxa Technologies CP-102E Manual de usuario

I-Bus

I-Bus IBC2602 Manual de usuario

Exsys

Exsys EX-60102 Manual de usuario

Chelsio Communications

Chelsio Communications T5 Series Manual de usuario

Conrad Electronic

Conrad Electronic 97 46 71 Manual de usuario

Micro Innovations

Micro Innovations USB650A Manual de usuario

KTI Networks

KTI Networks KF-310 Manual de usuario

Asus

Asus SpaceLink WL230 Manual de usuario

SIIG

SIIG SC2475 Manual de usuario

TRENDnet

TRENDnet TEW-703PI Manual de usuario

Belkin

Belkin F5D7000F Manual de usuario

Pericom

Pericom PI7C7100 Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3548 Manual de usuario

Digium

Digium TE200 Series Manual de usuario

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manual de usuario

Western Digital

Western Digital FireWire PCI Adapter Manual de usuario
