StarTech.com PEX1000MMSC2 Manual de usuario

Manual Revision: 04/27/2022

User Manual

For the latest information and specications visit

www.startech.com/PEX1000MMSC2

PCI Express Gigabit Ethernet Multi Mode

SC Fiber Network Card

SKU#: PEX1000MMSC2

Actual product may vary from photos

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada. CAN ICES-3 (B)/NMB-3(B).

This device complies with Industry Canada licence-exempt RSS standard(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any

interference, including interference that may cause undesired operation of the

device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables

aux appareils radio exempts de licence. L’exploitation est autorisée aux deux

conditions suivantes:

(1) L’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil

doit accepter tout brouillage radioélectrique subi, même si le brouillage est

susceptible d’en compromettre le fonctionnement.

For the State of California

WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related

in any way to StarTech.com. Where they occur these references are for

illustrative purposes only and do not represent an endorsement of a product

or service by StarTech.com, or an endorsement of the product(s) to which this

manual applies by the third-party company in question. Regardless of any

direct acknowledgement elsewhere in the body of this document, StarTech.

com hereby acknowledges that all trademarks, registered trademarks, service

marks, and other protected names and/or symbols contained in this manual

and related documents are the property of their respective holders.Safety

Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に

従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

Warning Statements

Make sure to assemble this product according to the

instructions. Failure to do so might result in personal injury or

property damage.

Never use this product if parts are missing or damaged.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Warning Statements ..............................................................................3

Product Information ..............................................................................5

Packaging Contents ................................................................................................................................. 5

System Requirements.............................................................................................................................. 5

Product Diagram ....................................................................................6

Card................................................................................................................................................................ 6

Jumper.......................................................................................................................................................... 6

Installation ..............................................................................................7

Hardware Installation .............................................................................................................................. 7

Driver Installation...................................................................................................................................... 8

Software Utility ......................................................................................9

Connecting to a Network......................................................................10

Network Conguration ........................................................................................................................... 10

Card to Card Direct Conguration ...................................................................................................... 11

LEDs..........................................................................................................12

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Packaging Contents

• Port PCI Express Gigabit Fiber Network Card x 1

• Low Prole Bracket x 1

• Instruction Manual x 1

System Requirements

• Computer with an available PCI Express Slot (x1, x4, x8, or

x16)

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Card

Jumper

Fiber Optic SC

Female

Activity LED

Link LED

JP2 Jumper

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Installation

Hardware Installation

WARNING! PCI Express cards, like all computer equipment,

can be severely damaged by static electricity. Be sure that

you are properly grounded before opening your computer

case or touching your PCI Express card. StarTech.com recom-

mends that you wear an anti-static strap when installing any

computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touch-

ing a large grounded metal surface (such as the computer

case) for several seconds. Also be careful to handle the PCI

Express card by its edges and not the gold connectors.

1. Turn your computer o and any peripherals connected to

the computer (i.e. Printers, external hard drives, etc.). Unplug

the power cable from the rear of the power supply on the

back of the computer and disconnect all peripheral devices.

2. Remove the cover from the computer case. See

documentation for your computer system for details.

3. Locate an open PCI Express slot and remove the metal

cover plate on the rear of the computer case (Refer to

documentation for your computer system for details).

Note: This card will work in PCI Express slots of additional

lanes (i.e.x4, x8, or x16 slots).

4. Gently insert the card into the open PCI Express slot and

fasten the bracket to the rear of the case.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Note: If installing the card into a small form factor/low

prole system, replacing the pre-installed full prole bracket

with the included low prole installation bracket may be

necessary.

5. Place the cover back onto the computer case.

6. Insert the power cable into the socket on the power supply

and reconnect all other connectors removed in Step 1.

Driver Installation

Note: The card may auto-install using native drivers;

however, it is recommended to use the latest drivers version

provided on StarTech.com’s website.

1. Navigate to www.startech.com/PEX1000MMSC2

2. Click the Drivers & Downloads tab.

3. Under Driver(s), download the Driver corresponding to the

Operating System.

4. Extract the contents of the Driver Package.

5. Open the corresponding folder that matches the Operating

System Version.

6. For Windows and macOS systems, Execute the Installer

to nish installing the driver. For Linux systems, follow the

instructions on the accompanying README.txt le to nish

installing the driver.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Software Utility

For Windows systems, the PCI Express Fiber Gigabit Ethernet

Adapter also includes an optional monitoring and maintenance

software utility that provides access to conguration settings,

testing, and reporting statistics.

To download the software, follow the instructions from the

Driver Installation section.

To install the software, follow these steps:

1. Navigate to the extracted Windows Drivers Folder from

the Driver Installation section.

2. Open the Diagnostic Tools folder.

3. Open the corresponding folder that matches the Operating

System Version.

4. Execute the setup.exe to nish the installation.

Ethernet Diagnostic Utility screen

Otros manuales para PEX1000MMSC2

Tabla de contenidos

Otros manuales de Tarjeta PCI de StarTech.com

StarTech.com

StarTech.com PEX10GSFP4I Manual de usuario

StarTech.com

StarTech.com PEX100SFP Manual del sistema

StarTech.com

StarTech.com PEX8S1050LP Manual de usuario

StarTech.com

StarTech.com PCIESATA2I Manual de usuario

StarTech.com

StarTech.com PEX1000MMSC Manual del sistema

StarTech.com

StarTech.com PEXUSB312A2 Manual de usuario

StarTech.com

StarTech.com PCI1P2 Manual de usuario

StarTech.com

StarTech.com PCI1394B_3 Manual de usuario

StarTech.com

StarTech.com PCI1394_2 Manual de usuario

StarTech.com

StarTech.com PCI100MMST Manual de usuario

StarTech.com

StarTech.com USB2HDCAPM Manual de usuario

StarTech.com

StarTech.com PEX2EC35 Manual de usuario

StarTech.com

StarTech.com PEXUSB311AC2 Manual de usuario

StarTech.com

StarTech.com PEX2S553B Manual de usuario

StarTech.com

StarTech.com PEX1000SFP2 Manual de usuario

StarTech.com

StarTech.com 8STPEXUSB3S44V Manual de usuario

StarTech.com

StarTech.com PEXSAT34RH Manual de usuario

StarTech.com

StarTech.com PEX4S950 Manual de usuario

StarTech.com

StarTech.com PCI1394 2LP Manual

StarTech.com

StarTech.com PEX2S650 Manual de usuario

StarTech.com

StarTech.com PCISOUND5CH Manual de usuario

StarTech.com

StarTech.com PEX1394A2DV Manual de usuario

StarTech.com

StarTech.com PCISCSIUW Manual de usuario

StarTech.com

StarTech.com PCI2S650PW Manual de usuario

Manuales populares de Tarjeta PCI de otras marcas

ERMA

ERMA SSI 1417 Manual de usuario

SIIG

SIIG CyberSerial Dual PCI Instrucciones de montaje

Moxa Technologies

Moxa Technologies CP-102E Manual de usuario

I-Bus

I-Bus IBC2602 Manual de usuario

Exsys

Exsys EX-60102 Manual de usuario

Chelsio Communications

Chelsio Communications T5 Series Manual de usuario

Conrad Electronic

Conrad Electronic 97 46 71 Manual de usuario

Micro Innovations

Micro Innovations USB650A Manual de usuario

KTI Networks

KTI Networks KF-310 Manual de usuario

Asus

Asus SpaceLink WL230 Manual de usuario

SIIG

SIIG SC2475 Manual de usuario

TRENDnet

TRENDnet TEW-703PI Manual de usuario

Belkin

Belkin F5D7000F Manual de usuario

Pericom

Pericom PI7C7100 Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3548 Manual de usuario

Digium

Digium TE200 Series Manual de usuario

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manual de usuario

Western Digital

Western Digital FireWire PCI Adapter Manual de usuario
