StarTech.com PCI1394MP Manual de usuario

PCI FireWire Card

PCI1394MP Instruction Manual

Actual product may vary from photo

3 Port IEEE-1394 FireWire PCI Card

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Verifying Your Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com PCI FireWire card. This card allows you to

instantly connect your video camera, image scanner, digital still camera, or any other

IEEE-1394 FireWire device to your PC and is perfect for experienced users who are

looking for a no-nonsense way to add FireWire to their computers.

Features

•Compatible with most digital video camcorders including Sony, Canon, Panasonic,

JVC, Samsung, and others

•Supports hard disk drives, DVD drives, CD-R/RW drives, printers, and more

•Data transfer rates up to 400 Mbits/sec.

•Allows the connection of internal FireWire peripherals

•Backed by StarTech.com’s lifetime warranty

Before You Begin

To ensure a quick and easy PCI FireWire card installation, please read through this

section carefully before attempting to install the card.

System Requirements

•An IBM-PC compatible computer

•One available PCI slot

•One of the following operating systems: Windows 98SE/ME/2000/XP

•ACD-ROM or other optical drive (for driver installation)

WARNING! PCI cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer case or

touching your PCI card. StarTech.com recommends that you wear an anti-static strap

when installing any computer component. If an anti-static strap is unavailable, discharge

yourself of any static electricity build-up by touching a large grounded metal surface

(such as the computer case) for several seconds. Also be careful to handle the PCI card

by its edges and not the gold connectors.

Contents

This package should contain:

•1x PCI FireWire card

• 1 x Instruction Manual

Instruction Manual

Installation

This section will guide you through the installation of your PCI FireWire card. Please

read through the instructions carefully and complete each step in the order listed.

Installing the Card

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system (see your computer’s user manual for details, if

necessary) and gently turn your computer onto its side.

3. Locate an empty PCI slot (usually white in color) and remove the metal plate that

covers the rear bracket. You may need a Phillips screwdriver to perform this step.

Retain this screw! You will need it to secure the card later.

4. Gently insert the PCI card into the empty slot, making sure it is firmly seated.

5. Secure the card in place using the screw you removed in Step 3.

6. Put the computer case back on.

Installing the Drivers

Once you have connected your FireWire card, the next time you turn on your computer

Windows will automatically detect that you have installed new hardware. Follow the

instructions below to install the required software drivers.

Windows 98SE

1. Windows should automatically detect the new hardware. At the Add New Hardware

Wizard window, click Next.

Instruction Manual

PCI

Slots

2. Select Search for the best driver for your devices (Recommended) and click

Next.

3. Insert the Windows 98SE CD-ROM into your computer’s optical drive and check the

CD-ROM option. Click Next.

4. Choose The Updated Driver (Recommended) and click Next.

5. Click Next again. If prompted for the Windows CD again, type x:\win98 and click

OK (where “x:” is letter assigned to your CD-ROM or other optical drive).

6. Click Next, then Finish to complete the driver installation. Select Yes to restart your

computer (if prompted).

Windows ME

1. Windows should automatically detect the new hardware. At the Add New Hardware

Wizard window, click Next.

2. Select Search for the best driver for your devices (Recommended) and click

Next.

3. Insert your Windows ME CD into your computer’s optical drive. Select CD-ROM

drivers and click Next.

4. Click Finish.

5. Remove the CD and select Yes to restart your computer (if prompted).

Windows 2000

Windows 2000 will automatically locate and install the required drivers.

Windows XP

Windows XP will automatically locate and install the required drivers.

Verifying Your Installation

Windows 98SE/ME

1. Go to Start >Settings >Control Panel.

2. Double click System.

3. Click the Hardware tab.

4. If the card does not appear with a red xor yellow exclamation point (!) next to it,

Windows has not detected a problem with the installation and the card should

function normally.

Windows 2000/XP

1. Go to Start >Settings >Control Panel.

2. Double click System.

3. Click the Hardware tab and choose Device Manager.

Instruction Manual

4. If the card does not appear with a red xor yellow exclamation point (!) next to it,

Windows has not detected a problem with the installation and the card should

function normally.

Specifications

Accessory Products from StarTech.com

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

6 ft. IEEE-1394 FireWire Cable 4-6 pin M/M

1394_46_6

10 ft. IEEE-1394 Firewire Cable 4-6 pin M/M

1394_46_10

15 ft. IEEE-1394 Firewire Cable 4-6 pin M/M

1394_46_15

6 ft. IEEE-1394 FireWire Cable 6-pin to 6-pin

1394_6

10 ft. IEEE-1394 Firewire Cable 6-6 pin M/M

1394_10

15 ft. IEEE-1394 Firewire Cable 6-6 pin M/M

1394_15

IEEE-1394 Firewire 4-6 pin Adapter M/F

FIRE46MF

Mutant Mods 6 ft. Blue - Green Lava Lamp LED IEEE-1394 FireWire Cable, 6-6 pin

1394_6FLBG

Mutant Mods 6 ft. Red - Yellow Lava Lamp LED IEEE-1394 FireWire Cable, 6-6 pin

1394_6FLRY

Instruction Manual

Form Factor/Interface Full-sized PCI, ver. 2.1 compliant

Standards Supported IEEE-1394/IEEE-1394A (FireWire 400)

Maximum Data Transfer Rate 400 Mbits/sec.

Connectors 4 x 6-pin FireWire female (1 internal, 3 external)

OS Support Windows 98SE/ME/2000/XP

Fully plug and play compliant

Regulatory & Other Certifications FCC Class B, CE, UL, Microsoft WHQL

Mutant Mods 6 ft. Blue LED IEEE-1394 FireWire Cable, 6-6 pin

1394_6LEDBL

Mutant Mods 6 ft. Red LED IEEE-1394 FireWire Cable, 6-6 pin

1394_6LEDRD

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Revised: 18 August 2004 (Rev. B)

About StarTech.com

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Otros manuales para PCI1394MP

Tabla de contenidos

Otros manuales de Tarjeta PCI de StarTech.com

StarTech.com

StarTech.com PEXUSB312C2 Manual de usuario

StarTech.com

StarTech.com 10P6G-PCIE-SATA-CARD Manual de usuario

StarTech.com

StarTech.com PCI1PM Manual de usuario

StarTech.com

StarTech.com PEX1S1PMINI Manual de usuario

StarTech.com

StarTech.com PCI1394_2 Manual de usuario

StarTech.com

StarTech.com 8P6G-PCIE-SATA-CARD Manual de usuario

StarTech.com

StarTech.com PEXSAT34RH Manual de usuario

StarTech.com

StarTech.com PEX2S953 Manual de usuario

StarTech.com

StarTech.com PEXESATA2 Manual de usuario

StarTech.com

StarTech.com PEXMSATA343 Manual de usuario

StarTech.com

StarTech.com PEXUSB3S24 Manual de usuario

StarTech.com

StarTech.com PCI312PUSB/LP Manual de usuario

StarTech.com

StarTech.com PEXUSB311AC3 Manual de usuario

StarTech.com

StarTech.com PCISCSIU2W Manual de usuario

StarTech.com

StarTech.com PCI4S9503V Manual de usuario

StarTech.com

StarTech.com PEX1394B3 Manual de usuario

StarTech.com

StarTech.com PCI1S950DV Manual de usuario

StarTech.com

StarTech.com PEX1PCI1 Manual de usuario

StarTech.com

StarTech.com PEXHDCAP2 Manual de usuario

StarTech.com

StarTech.com ST100SLP Manual

StarTech.com

StarTech.com PCISATA2 Manual de usuario

StarTech.com

StarTech.com QUAD-M2-PCIE-CARD-B Manual de usuario

StarTech.com

StarTech.com PCISCSI2U Manual de usuario

StarTech.com

StarTech.com PCISCSI2 Manual de usuario

Manuales populares de Tarjeta PCI de otras marcas

ERMA

ERMA SSI 1417 Manual de usuario

SIIG

SIIG CyberSerial Dual PCI Instrucciones de montaje

Moxa Technologies

Moxa Technologies CP-102E Manual de usuario

I-Bus

I-Bus IBC2602 Manual de usuario

Exsys

Exsys EX-60102 Manual de usuario

Chelsio Communications

Chelsio Communications T5 Series Manual de usuario

Conrad Electronic

Conrad Electronic 97 46 71 Manual de usuario

Micro Innovations

Micro Innovations USB650A Manual de usuario

KTI Networks

KTI Networks KF-310 Manual de usuario

Asus

Asus SpaceLink WL230 Manual de usuario

SIIG

SIIG SC2475 Manual de usuario

TRENDnet

TRENDnet TEW-703PI Manual de usuario

Belkin

Belkin F5D7000F Manual de usuario

Pericom

Pericom PI7C7100 Manual de usuario

ADLINK Technology

ADLINK Technology cPCI-3548 Manual de usuario

Digium

Digium TE200 Series Manual de usuario

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manual de usuario

Western Digital

Western Digital FireWire PCI Adapter Manual de usuario
