Star Micronics TUP592 Manual de usuario

After the success of the industry-leading TUP900 wide format open

frame printer, Star Micronics is proud to introduce the new TUP500

kiosk printer. With a more compact footprint and support for smaller

paper widths, the TUP500 is a welcomed addition to Star Micronics’

kiosk printer line to provide solutions to an even greater range of

applications. The TUP500 features an industry leading print speed of

up to 222200mmmm//ssand higher reliability at an MCBF of 60

Million Lines.

The innovative llooooppiinngg pprreesseenntteerrprevents paper jams by

printing the receipt in full before providing it to the user. The

presenter also uses Star Micronics’ ddooccuummeenntt ccaappttuurree tteecchhnnoollooggyyto

retract receipts left by the user, resulting in increased document security

and a cleaner operation area. A brand new innovative bbeezzeell ((ssnnoouutt))

ooppttiioonncan be directly attached to the presenter to capture the user’s

attention with programable 2-color (red+green) ffllaasshhiinngg LLEEDD

lights.

The TUP500 features adjustable print widths of 45mm – 82.5mm

documents. With the addition of the optional Large Paper Roll

Accessory, it supports up to a 10” paper roll for many hours of

unattended operation.

The TUP500 kiosk printer is ideal for a wide range of applications

including public information kiosks, gaming, lottery, web kiosks,

and much more!

Visit www.starmicronics.com to learn more.

TTee UUllttiimmaattee HHiigg--SSppeeeedd

CCoommppaacctt KKiioosskk PPrriinntteerr SSoolluuttiioonn

TTUUPP550000

Parts Breakdown

Available

Looping Presenter with

Document Presenter

Document Capture Optional Flashing LED

Bezel

•Modular Design for Easy Integration

•Ad ustable Paper Width from 45mm - 82.5mm

•High Speed: Up to 220mm/sec

•High Performance Presenter Model (TUP592)

•Available Without Presenter (TUP542)

Features

Te Ultimate Modular Kiosk Printer Solution

Hardware

High Speed Printing (Up to 220mm/s)

Adjustable Print Width (45-82.5mm)

Looping Presenter Virtually Eliminates Paper Jams

Large Paper Roll Support (Up to 6” by default; up to 10” with op-

tional holder)

Modular Design for Easy ntegration

Reliable Guillotine Cutter

Semi-Automatic Paper Loading

Swappable Communication nterfaces

2D Barcode Support

No Presenter Version Available

Software

Logo Utility (Store Logos, Coupons, and Graphics)

Memory Switch Configuration Setup Utility

Two Color Printing Mode

Double Resolution Mode

Low Peak Current Mode

Star O SDK

Connectivity

Note: Connections in bboollddare supported;

grayed-out connection types may be

supported by special request.

9-Pin Serial

25-Pin Serial

Parallel

USB

Powered USB

Et ernet

WiFi

Dual 9-Pin Serial/USB

Virtual Serial Port to USB

Virtual Serial Port to Et ernet

Virtual TCP/ P Port

Drivers

Windows®XP

Vista (32 bit / 64 bit)

Windows 7 (32 bit / 64 bit)

Server 2008 (32 bit / 64 bit)

XP Embedded

POS for .NET

OPOS™

JavaPOS™

USB Vendor Class

Linux™CUPS

MAC OS X CUPS

W at's Included

Paper Shaft

1 nch Paper Core Adapter

2 nch Paper Core Adapter

Shaft Weight

nterface Mounting Screws (Attached on PCB Chassis)

Paper Core Adapter Screws

Optional Accessories

External Power Supply (PS60A)

Swappable nterface Cards

Large Paper Roll Holder (RHU-T500) with 3 nch Paper Core Adapter

Near End Paper Sensor (NEU-T500)

Presenter (PR521-24-A)

Mechanism Only (TMP-542-24-A)

Flashing LED Bezel

Tec nical Specifications

Print Method : Direct Thermal

Print Speed : Up to 220mm/s

Paper Width : 45 – 82.5mm (adjustable)

Paper Thickness : 0.06 – 0.15mm

Paper Diameter : Max 150mm (Max 254mm with Large Paper Roll Holder)

Emulation : Star Line Mode, Star Page Mode, ESC/POS™

Power : DC24V

Resolution: 203 dpi

MCBF: 60 Million Lines

Cutter: 1 Million Cuts

Presenter: 1 Million Receipts

Dimensions: W=160mm, H=179mm, D=235mm (Without Paper)

Warranty For US and Canada: 3-Year Limited Warranty

For Furt er Information Sales: 1-800-782-7636 x107

Technical Support: 1-800-782-7636 x105

Web: http://www.starmicronics.com

TUP500 Specifications

2/22/10
