Star Micronics DP8340 Series Instrucciones de funcionamiento

DP8340 Series

1st Edition

Issued Date: June 11, 2008

Star Micronics America, Inc.

Repair Manual

!The confidential information of Star Micronics

America, Inc. or its associated company is

recorded in this book.

!So a user has to treat the information concerned

as private information.

!A user must not use this confidential information

except for the purpose of the product repairs.

!Star cannot take any responsibility about the

repair result influenced of this manual.

!Star cannot take any responsibility about the

trouble which caused by 3rd party’s parts or

consumables.

Star Micronics America, Inc.

About This Manual

Rev. #

Date of Issue

Note

1.0

06/11/2007

Release 1st Edition

Star Micronics America, Inc.

Change Record

Please confirm before repair

1. Repair Mechanism

1-1 Removing Printer Cover Unit

(1) Remove Printer Cover Unit-----------------------------------------------1

1-2 Removing Upper Case Unit

(1) Remove Upper Case Unit-------------------------------------------------2

1-3 Removing Control Board Unit

(1) Remove Control Board Unit----------------------------------------------4

1-4 Removing Mechanism Chassis Unit

(1) Remove Mechanism Chassis Unit-------------------------------------5

1-5 Removing Print Head

(1) Remove Print Head--------------------------------------------------------6

1-6 Removing Ribbon Base Unit

(1) Remove Ribbon Base Unit ----------------------------------------------7

1-7 Removing Main Control Board

(1) Remove Main Control Board--------------------------------------------8

2. Notice of the repair operation----------------------------------------------------------9

3. Parts List-------------------------------------------------------------------------------------10

Star Micronics America, Inc.

Table of Contents

Star Micronics America, Inc.

1-1 Removing Printer Cover Unit

1

Please confirm before repair

Turn off the Power Switch Aand disconnect the Power Cable from the outlet.

1. Repair Mechanism

(1) Remove Printer Cover Unit

1-1) Starting from back side gently pull toward front as shown below.

1-2) Turn printer over and pull cover front to back to loosen that pull forward as shown below

(1) Remove Upper Case Unit (You must remove lower case first)

1-1) Remove screws (2) from bottom of printer as shown below.

Star Micronics America, Inc.

1-2 Removing Upper Case Unit

2

3

Star Micronics America, Inc.

1-3) Disconnect Control Panel Unit (part # 87200310)

(1) Remove Control Board Unit

1-3 Removing Control Board Unit

4

Star Micronics America, Inc.

1-1) Remove screws (2) and remove from Upper Case.

1-2) Control Panel Unit shown below

(1) Remove Mechanism Chassis Unit

Star Micronics America, Inc.

5

1-4 Removing Mechanism Chassis Unit

1-1) Remove screws (4) and flat washers identified by red arrow

1-2) Disconnect frame wires located circled area

1-3) Disconnect the two (2) connectors on Terminal board and gently lift Mechanism.

1-5 Removing Mechanism Chassis Unit

6

(1) Remove Print Head. Part# 89180021

7

4

Star Micronics America, Inc.

6

1-1) Remove Cover Unit as outlined in section 1.1

1-2) Remove Upper Case as outlined in section 1.2

1-3) Disconnect Print Head cable Aas shown below

1-4) Remove Print Head screws as shown below B

1-5) Remove Print Head

1-5 Removing Motor Unit
