Sonos Five Manual de usuario
Five
Guides
Five
Overview The high-fidelity speaker for superior
sound—
Versatile design with smart orientation sensing. Pair two
speakers horizontally and Five automatically separates
the left and right channels for impressive stereo sound.
When paired vertically, each smartly adjusts to mono for
more detailed stereo separation and an even wider
soundstage.
Touch controls on the speaker let you adjust volume, play
and pause, or skip through songs.
Use the line-in port to connect your turntable or another
device—simple control with the Sonos app or Apple
AirPlay 2.
Pair two Fives for left-right stereo sound or use two Fives
as rear surrounds for your home theater.
Control your Sonos system with the Sonos app (for
Android and iOS).
See Setup when you’re ready to add Five to your Sonos
system.
Controls and lights
Button Control Description
Volume control Touch and hold to quickly
change the volume.
Note: You can also use
the Sonos app to adjust
volume.
Play/Pause
Next/Previous song
Note: You can’t skip
forward or go back when
listening to a radio station.
Volume up (right)
Volume down (left)
Press once to play or
pause audio.
Press and hold to add
the audio that's playing
in another room.
Swipe right to skip to
the next song.
Swipe left to go to the
previous song.
Connector panel
1Ethernet port Use an Ethernet cable if you want to
connect to a router, computer, or
network-attached storage (NAS)
device (optional).
2Stereo audio in (3.5mm / 1/8") Use to connect an external audio
device, like a turntable or CD player.
3Join button Press to connect to your Sonos
system during setup.
4AC power (mains) input Use only the supplied power cord
(using a third-party power cord will
void your warranty).
Note: Insert the power cord firmly
until it is flush with the bottom of the
speaker.
Select a location
You can put your speaker just about anywhere. For maximum performance, here's a few
guidelines:
Set up stereo pair
Pair two Sonos speakers in the same room for a wider, stereo experience. One speaker
serves as the left channel and one serves as the right channel.
Note: The Sonos speakers in a stereo pair must be the same type.
1. Place the speakers 8 to 10 feet apart. Your favorite listening position should be 8 to 12
feet from the paired speakers—less distance increases bass, more distance improves
stereo imaging.
2. Go to > System.
3. Select one of the speakers you want to use in the stereo pair, then choose Set Up Stereo
Pair to get started. Learn more
Five is a substantial and powerful speaker and should be placed on a flat surface that is
robust and durable enough to properly support it. Make sure Five’s rubber feet sit
completely on the flat surface.
Allow at least 2" perimeter all around Five, including its power cord.
For a single Five speaker, we recommend positioning the speaker horizontally to enable
stereo sound.
Place Five across the room from where you’ll be listening (at or close to your ear height
for best results).
For stereo pair placement information, see Set up stereo pair.
Five is humidity resistant so you can use it in the bathroom; however it is not water
resistant, so don’t position it near water or leave it outside during a rain storm.
Set up surrounds
It’s easy to turn two Sonos speakers (same model), or a Sonos Amp and your favorite non-
Sonos speakers, into separate right and left channels for your home theater.
1. Place each surround speaker about 10ft from your favorite listening position, angling them
toward the seating area.
2. Go to > System.
3. Select a room with a soundbar and choose Add Surrounds to get started.
Note: If you group the rooms or create a stereo pair instead, you won't have surround sound.
Learn more
Surround audio settings
During setup, surround sound is optimized for your room. These settings are adjustable:
Surrounds Turn surround sound On or Off.
TV Level Adjust surround volume for TV audio.
Music Level Adjust surround volume for music.
Music Playback
Ambient (subtle) or Full (louder, full
range). Doesn't apply to Dolby Atmos
Music playback.
Line-in
Connect an audio device, like a CD player or a turntable with a built-in phono preamp, to the
line-in port on a Sonos product (Amp, Port or Five).
Learn more
Specifications
Feature Description
AUDIO
Amplifier
Six Class-D digital amplifiers perfectly
tuned to match the six dedicated speaker
drivers and the acoustic architecture.
Tweeter Three tweeters create the crispest and
clearest high-frequency response.
Mid-woofer
Three mid-woofers ensure you’ll hear the
faithful playback of mid-range vocal
frequencies plus deep, rich bass—without
distortion, even at high volumes.
NETWORKING*
Wireless connectivity
Connects to WiFi network with any
802.11a/b/g/n 2.4 or 5GHz broadcast-
capable router.
Bluetooth Low Energy (BLE) Temporarily connects to your mobile
device for first-time set up.
Ethernet port
One 10/100Mbps Ethernet port. You can
plug a Sonos product directly into your
router if your WiFi is unstable.
Feature Description
GENERAL
Power supply Auto-switching 100 - 240V ~ 50-60Hz
2.3A AC universal input.
Audio line-in
Auto-detecting 3.5mm audio line-in
connection. Use an auxiliary cable to
connect an audio device.
Dimensions (W x H x D)
14.33 x 8.03 x 6.06in. (364 x 203 x
154mm)
Weight
14lb / 6.36kg
Threaded mount None
Operating temperature 32°F to 104°F (0°C to 40°C)
Storage temperature -4 to 158 F (-20 to 70 C)
Product finish White matte or black matte exposure,
graphite grille
° ° ° °
