Sonos Roam Manual de usuario

Roam

Guides

Roam

Overview The ultra portable smart speaker for

listening at home and on the go—

Enjoy up to 10 hours of continuous playback on a single

charge. When it’s time to recharge:

Connect the included cable to a USB power source

(7.5W minimum; 10W recommended).

Place on a compatible Qi wireless charger.

Place Sonos Roam on its custom wireless charger

(sold separately).

Lightweight, durable, waterproof design is ideal for the

beach, pool parties, and more.

Stream content over WiFi or Bluetooth®.

Compatible with all your other Sonos speakers for multi-

room listening.

Freedom of control using the Sonos app, the speaker

buttons, or your voice.

See Setup when you're ready to add Sonos Roam to

your system.

Controls and lights

Volume control

Press and hold to quickly

change the volume.

Note: You can also use

the Sonos app and voice

control to adjust volume.

Playback control

Sound Swap

Note: You can’t skip

forward or go back when

listening to a radio station.

Volume up (+)

Volume down (-)

Press once to play or

pause audio.

Press and hold to

group with other

speakers. Continue

holding the button

down to move the

sound to and from your

nearest Sonos

speaker.

Double press for next

track.

Triple press for

previous track.

Microphone

Press to turn the

microphone on or off:

Note: If you set up a voice

service and the

microphone is off, you can

still use voice commands.

Just press and hold —

no need to start with a

wake word. When you

release the microphone

button, voice control turns

off again.

When the microphone

light is on, voice

control and

microphone-dependent

features like auto

Trueplay are available.

When the light is off,

voice control and

microphone-dependent

features like auto

Trueplay are

unavailable.

Status light

Displays the product's

connection to WiFi or

Bluetooth, indicates when

the volume is muted, and

signals errors:

Solid white—on

Blinking blue—

Bluetooth pairing mode

Solid blue—

connected to a device

using Bluetooth

Flashing orange—if

the product gets too

hot, the status light

flashes orange and the

product chirps 3 times.

Move the product to a

cooler location, away

from direct sunlight.

Learn more

Battery light

Indicates the battery

status:

Battery Saver: To save

battery life, you can set

Sonos Roam to power off

automatically instead of

going to sleep. Go to >

System, and choose

Sonos Roam. It won't

appear in the Sonos app

until it’s powered back on.

Note: Sonos Roam’s

remaining battery life is

always visible in the

Sonos app.

Blinking orange

indicates low battery.

Solid orange when it

starts charging. The

light may stay on for

several minutes

depending on how low

the battery is. The

battery will continue to

charge when the light

turns off. Learn more

Connector panel

1Power/Bluetooth button Power on/sleep/wake: Short press

(less than 1 second)

When you put Roam to sleep, you’ll

hear a quick tone and the status light

will turn off. Press again to wake. If

you put Roam to sleep, it will stay

asleep for 10 minutes before

powering off.

Bluetooth: To pair with a device,

press and hold until you hear the

second tone and the status light

blinks blue, then select Roam from

your device’s Bluetooth pairing list.

To pair with a different device, wait

until Roam connects to the current

device, then press and hold again to

restart the pairing process.

Power off: Long press (about 5

seconds)

Press and hold until you hear the third

tone. The status light blinks blue, then

turns off.

2USB-C port Use the included cable to connect a

compatible 7.5W minimum (10W

recommended) USB-A power source.

(Sonos 10W USB Power Adapter

sold separately.)

Select location

You can use your Sonos Roam just about anywhere. Here are a few things to keep in mind:

Bluetooth pairing

1. Turn on Bluetooth in your device settings.

2. Press and hold the power button for 2 seconds until you hear two chimes, then release.

The status light blinks blue when the speaker is ready to pair.

3. Choose Sonos Roam from the list of available devices. Your mobile device will

automatically connect next time.

You can place the speaker next to a wall or on a shelf—for best performance, leave at

least 1" (2.5 cm) space around the back of the speaker.

The speaker’s durable design includes silicone end caps to protect from drops or bumps.

Avoid placing the speaker in direct sunlight.

You can place it horizontally or vertically. When vertical, the speaker takes up barely any

room. Position it horizontally for added stability on uneven surfaces.

When the microphone is on, the speaker tunes itself with automatic Trueplay for

amazing sound no matter where you are and what you’re listening to.

Charging

USB-C to USB-A

Use the included cable to

connect a compatible

7.5W minimum (10W

recommended) USB-A

power source. (Sonos

10W USB Power Adapter

sold separately.)

Note: Battery life is visible

in the Sonos app.

Sonos Wireless Charger

(sold separately)

Place the speaker on the

smooth, magnetized side

of the charger for easy

recharging—no extra

wires or cables needed.

Qi charger

Place the speaker on a

compatible Qi-certified

wireless charger.
