Sonos SUB Manual de usuario

Sub

Guides

Sub

Overview Sonos Sub takes your audio

experience to the next level—

Instantly adds a dimension of deep bass impact to your

audio listening experience.

Allows placement anywhere because it’s wireless and

compact—position it vertically or horizontally on any floor

surface.

The top of the acoustic slot doubles as a handle so you

can lift it.

Sub (Gen. 3) is compatible with the Sonos S2 app (for

Android and iOS). Earlier Sub models are compatible

with either S1 or S2.

Sonos Sub is designed for use with most Sonos

speakers, except Sonos Roam, Roam SL, Connect, Port,

and Move. Make sure you set up at least one speaker

before adding Sub.

See Setup when you’re ready to add a Sub to your

Sonos system.

Controls and buttons

1Acoustic slot You can use the acoustic slot as a

handle to lift Sub.

2Status light Displays the product's connection to

WiFi, indicates when the volume is

muted, and signals errors. Learn

If the light is distracting, you can turn

it off in your room’s settings.

3Join button Press to connect during setup.

4Ethernet port Use an Ethernet cable if you want to

connect to a router (optional).

5AC power (mains) input Use only the supplied power cord to

connect to a power outlet (using a

third party power cord will void your

warranty). Be sure to use the proper

power adapter for your country. Push

the power cord firmly into Sub until it

is flush with the surface.

Select a location

Choose a location—Sub is designed to provide optimal sound wherever you place it.

Use the acoustic slot as a handle to lift Sub out of the box. You should always bend your

knees when lifting heavy objects to avoid undue stress on your back.

Make sure at least one side of the slot is free from obstruction. If you place it vertically

against a wall, don’t block the front opening.

If you place Sub horizontally on the floor, don’t put anything on top of it. Leave at least 1"

clearance along the top of Sub if placing under furniture.

Sub is designed to sit on the floor. You can place it in a corner, against the wall, behind,

under, or next to any piece of furniture on any kind of floor surface.

Position Sub either vertically or horizontally. If you’re going to use it horizontally, you can

attach permanent felt feet. See Attach feet (optional) for more information.

Connect the cables

1Attach the power cord and plug in

Sub. Be sure to push the power cord

firmly into Sub until it is flush with the

surface.

2Download the Sonos app from the

app store if you don't already have it.

You’ll use it to set up and control your

Sonos system. See Setup for more

information.

Note: Make sure you set up at least

one compatible speaker before

adding Sub.

Note: After Sub is paired with a Sonos speaker, you won’t see it displayed separately in your

system. Any changes you make to the speaker it's paired with, like volume, mute, or music

selection, will also affect Sub.

Attach feet (optional)

If you’re placing Sub horizontally on a floor, you can attach permanent felt feet (purchased

separately) to protect your floor. If you’re putting it on a rug or using it vertically, no need to

adhere the felt feet.

Note: The felt feet are not removable—a strong adhesive will keep them permanently

attached to Sub.

1. Lay Sub down so the Sonos logo is facing down. Make sure you adhere the felt feet to the

side that doesn’t have the Sonos logo.

2. Place the enclosed guide on one corner of the unit and fold the flaps over the edge.

3. Peel the backing off one of the feet.

4. Press the felt foot (sticky side down) onto the unit inside the circular portion of the guide.

5. Attach the other 3 felt feet the same way.

Product settings

To adjust Sub's settings, go to > System and select your Sub.

Sub Toggle On or Off to turn the sound from

Sub on and off.

Sub level

Use the slider to increase or decrease

volume. (You can use this setting to match

the subwoofer level to the level of your

main speakers.)

Phase control

Choose 0° or 180° to set the phase

control for your Sonos Sub or third-party

subwoofer (flip if you don't hear enough

bass in your usual listening position).

When a room with a Sonos Sub is tuned

using Trueplay, phase control is set and

can't be changed unless you disable

Trueplay.

Reset Resets all Sub audio settings to their

default values (0).

Change speaker pairing

You can easily change the Sonos speaker your sub is paired with.

If you’re moving it to a new room, wait for the status light to stop flashing after you plug the

sub back in.

1. Go to > System and choose the speaker your sub is paired with. It appears as

[speaker name (+Sub)] in your list of rooms.

2. Tap Remove Sub.

You can pair the sub with a different Sonos product or choose not to use it right now. It will

appear as "unused" in your list of products until you pair it with another Sonos speaker.

Connect a second Sub

You can easily connect a second Sub to your Sonos system.

Note: At least one Sub must be a Sub (Gen 3). If the button on the side is round instead of

square, it's a Sub (Gen 3). You cannot pair a Sub Mini with a Sub.

1. Go to > System and choose the speaker Sub is paired with. It appears as room

(+Sub) in your list of rooms.

2. Tap Connect Second Sub to get started.

Specifications

Feature Description

AUDIO

Amplifier Two Class-D digital amplifiers.

Speakers

Two force-canceling speakers positioned

face-to-face for deeper, richer sound and

zero cabinet buzz or rattle.

Dual acoustic ports Tuned to enhance Sub performance.

Frequency response Plays down to 25 Hz.

All digital sound

All filter settings, active equalization, and

time alignment are done digitally through

state-of-the-art DSP (Digital Signal

Processing) circuitry for zero-loss audio

quality and energy.

Automatic equalization

The system automatically adjusts audio

settings across all connected

components.

NETWORKING

Feature Description

Ethernet port

One 10/100 Mbps Ethernet port. You can

plug a Sonos product directly into your

router if your WiFi is unstable

Wireless connectivity

Using Sonos S2: Connects to WiFi

network with any 802.11a/b/g/n 2.4 or 5

GHz broadcast-capable router.

Using Sonos S1: Connects to WiFi

network with any 802.11b/g 2.4 GHz

broadcast-capable router. 802.11n only

network configurations are not supported

—you can either change the router

settings to 802.11b/g/n or connect a

Sonos product to your router.

GENERAL

Power supply Auto-switching 100 - 240V ~ 50-60 Hz 2 A

AC universal input

Dimensions (H x W x D) 15.3 x 6.2 x 15.8 in. (389 x 158 x 402 mm)

Weight Sub (Gen 3): 29 lb (13 kg)

Sub (Gen 2): 36 lb (16 kg)

Operating temperature 32 to 104 F (0 to 40 C)

Storage temperature -4 to 158 F (-20 to 70 C)

° ° °

° ° ° °
