Unmanaged Switch SMC108DT

EZ SwitchTM 10/100 8-port Fast Ethernet Switch

www.smc.com

SMC’s EZ Switch™ 10/100 is compact, internal-powered

8-port standalone, unmanaged switch with LEDs located

on the top of the unit for easy network diagnosis while

wall mounted. The 10BASE-T/100BASE-TX ports deliver

dedicated 10/100Mbps links to each attached LAN

segment – all with conventional cabling and adapters.

SMC’s EZ Switch™ 10/100 offers a simple, cost-effective

strategy for integrating Fast Ethernet into your Ethernet

network. Designed for easy integration with any SOHO

network, SMC EZ Switch 10/100 contains added features

like Store-and-Forward, Flow Control, “At-a-Glance

LEDs”, and internal power supply to ensure data delivery

and network integrity. Powerful enough to run your

network’s backbone, yet so easy they can be used in

place of your desktop hubs, the EZ Switch™ 10/100s

brings the power of switching to you.

FEATURES

Auto-negotiation of half or full duplex, and auto-sensing of

transmission speed, on all ports

Auto configuration for MDI/MDI-X cable connections

ANSI/IEEE802.3u compliant

Internal power supply

Light and compact in size

Half and full-duplex flow control prevents packets from

being dropped under heavy loading

Standards-based technology ensures interoperability

between various IEEE-based products

Store-and-forward architecture prevents propagation of

bad packets

Intuitive status indicators located on the top of the unit

allows for simple switch and network diagnostics

Can be conveniently mounted on the wall or positioned

on the desktop

BENEFITS

OVERVIEW

TECHNICAL SPECIFICATIONS SMC108DT

PORTS

• 8 10/100 Mbps RJ-45 auto MDI/MDI-X

LED

• Power – One

• Link/Act (10/100Mbps) – one per port

• 10/100 (10/100Mbps) – one per port

• FDX/COL (full duplex/collision) – one per port

MAXIMUM CURRENT

• 0.5A@110VAC

• 0.22@240VAC

POWER CONSUMPTION

•4Watt

DIMENSIONS

• 6.45 x 3.94 x 1.02 in

• 16.4cm x 10cm x 2.6 cm

WEIGHT

• 0.95 lbs

HUMIDITY

• 10% to 90%

TEMPERATURE

• Operating: 0°C to 45° / 32F° to 113°F

• Storage: -40°C to 70°C / -40°F to 158°F

WARRANTY

• Limited Lifetime

MAC ADDRESS TABLE

• 2K entries per system

MEMORY BUFFER

• 0.75Mbits

POWER REQUIREMENTS

• AC 100~240V 50/60Hz

HEAT DISSIPATION

• 45 BTU/hr maximum

SAFETY

• CSA + NRTL

STANDARDS

• IEEE802.3

• IEEE802.3u

• IEEE802.3x

CERTIFICATION

• CE Mark

IMMUNITY

• IEC 1000-4-2,3,4,6

EMI

• FCC Class B

North America

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

24/7 Technical Support

Europe/ Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despí

Barcelona, Spain

Check www.smc.com for your local

country contact information

www.smc.com

Contact
