Silver Cross Sleepover Manual de usuario

SLEEPOVER

IMPORTANT: KEEP THESE INSTRUCTIONS

FOR FUTURE REFERENCE

These instructions are important.

Please read these instructions carefully

before you use this pushchair and keep

them for future reference. Also ensure

that anyone else unfamiliar with this

pushchair reads the instructions carefully

so they understand how the product

works. This Sleepover 3-in-1 pushchair is

a high quality Silver Cross product that

meets current safety standards; regular

care and light maintenance will ensure its

long service. This pushchair is intended to

accommodate children from birth to 15kg

in weight. Remember, the safety of your

child is your responsibility.

WARNING: NEVER LEAVE YOUR

CHILD UNATTENDED.

Contents

Your Sleepover 3-in-1 includes the following

components, please check that you have

all the items before proceeding:

1.1 Carrycot body

1.2 Seat Unit (including harness)

1.3 Hood

1.4 Apron

1.5 Carrycot Liner

1.6 Carrycot Mattress

1.7 Footmu

1.8 Bumper Bar

1.9 Rosette

1.10 Bag

1.11 Raincover

1.1

1.2

1.3

1.4

1.5

1.6 1.7

1.9

1.10 1.11

1.8

Using your Sleepover from Birth

with the Carrycot.

2.1 First erect the carrycot body.

Lay the carrycot outer down with

frame upper most. Using the 2

webbing loops that are attached to

the metal bars, pull the top metal

bars into the locators on the internal

base of the carrycot.

A small groove in the locator holds

the frame in place.

2.2 Attach the carrycot liner to the

carrycot outer using the elasticated

top edge. Ensure the holes on the top

are located over the hood attachment

points.

Place the mattress into the base of

the carrycot.

2.3 Attach your hood to the carrycot by

inserting the clips into the slots on

the top edge of the carrycot. Fasten

the press studs on the hood to the

press studs on the carrycot - two at

the back and one at each side.

2.4 Fit the carrycot apron by tting it

around the carrycot and slide the

apron clips over the attachment

points, located on the inside of the

hood frame.

2.1

2.3

2.2

2.4

Attaching the Carrycot to your

chassis.

3.1 Before attaching the carrycot to the

chassis, lower the hood to the lowest

position.

3.2 There are two zip pockets on either

sides of the carrycot body. Remove

the handles from the pockets.

3.3 Lift the carrycot using the two handles

in one hand and position the carrycot

so the four locking catches on the

base are directly over the top of the

support bars on your chassis.

Using the other hand, press

downwards on each side of the

carrycot, listening for the two clicks.

Pull upwards with the handles to

ensure the carrycot is locked in place.

3.4 When the carrycot is attached, zip the

handles back into the side pockets.

The hood can now be raised.

WARNING: WHEN

ATTACHING, DETACHING

AND HAND CARRYING THE

SLEEPOVER CARRYCOT,

THE HOOD MUST BE IN THE

LOWEST POSITION.

WARNING: DO NOT LEAVE

FLEXIBLE CARRYING

HANDLES INSIDE THE

CARRYCOT.

3.1

3.2

3.3

3.4

‘CLICK’

Detaching the Carrycot from

your chassis.

4.1 Before detaching the carrycot from

the chassis, lower the hood to the

lowest position.

4.2 Remove the handles from the side

pockets of the carrycot.

When standing behind the chassis

handle, slide the RIGHT HAND SIDE

release lever away from you until it

clicks into place.

4.1

4.2

WARNING: THIS BUTTON

IS NOW UNLOCKED.

IT WILL RELOCK

AUTOMATICALLY ONLY

WHEN THE CARRYCOT IS

REMOVED AND

REATTACHED TO THE

CHASSIS.

Then while holding both handles

securely in one hand, slide the

LEFT HAND SIDE release

lever away from you and hold

whilst lifting.

4.3

WARNING: THE HANDLES

MUST BE STORED IN THE

ZIP POCKETS EXCEPT WHEN

ATTACHING OR DETACHING

THE CARRYCOT

WARNING: WHEN USING

THE CARRYCOT WITHOUT

THE CHASSIS. ONLYUSE ON

AFIRM, HORIZONTAL LEVEL

AND DRYSURFACE.

WARNING: BOTH

HANDLES MUST BE HELD

SECURELYTOGETHER

WHEN ATTACHING AND

DETACHING THE SLEEPOVER

CARRYCOT FROM THE

CHASSIS. YOU MUST NOT

LET GO OF THE HANDLES

UNTIL THE CARRYCOT IS

EITHER SECURELY FASTENED

TO THE CHASSIS OR SAT

ON AFIRM, LEVEL AND DRY

SURFACE.

4.3 Lift the carrycot upwards from the

chassis using the handles. The

LEFT HAND SIDE release lever

can be released when the carrycot

is clear of the chassis.

Operating the Hood on the

Carrycot.

5.1 The Sleepover hood is multi

positional. Simply hold the front bar

and gently lift and lower.

5.2 To remove the hood, rstly, undo the

4 press studs from the Sleepover hood

- two at the back and one at each

side. Locate the hood release buttons

at the each side of the carrycot, just

underneath each hood attachment

point. Press the button to release the

clip and lift the hood upwards. Failure

to press the release button may result

in damage to your product.

5.3 Your Sleepover hood has a ventilation

panel underneath the rear panel and

a pop-out sun visor.

To use the ventilation panel, simply

lift up the panel at the back of the

hood to expose the ventilation mesh.

The pop-out sun visor can be pulled

out from underneath the hood and

pushed back when not needed.

5.1

5.2

5.3

Carrycot Ventilation

6.1 Your Sleepover carrycot body has

ventilation holes in the base.

There is a lever on the underside of

the carrycot at the hood end.

The ventilation can be opened and

closed by moving the lever left or

right.

Carrycot rocking feature

7.1 The Sleepover carrycot base has a

gentle rocking feature.

7.2 The rocking feature is prevented or

allowed by lowering or raising the

four feet on the carrycot base.

6.1

7.1

7.2

8.1 Using your Sleepover from 6

Months as a Pushchair.

Attaching the seat unit to the

chassis.

8.1 The Sleepover seat unit can be used in

forward facing and rearward facing

mode.

8.2 Position the seat unit so the four

locking catches on the base are

directly over the top of the support

bars on your chassis. Push the seat

unit downwards so that all four locks

‘click’ and engage. Give the seat unit

a gentle lift to check that all four

points are securely fastened.

WARNING: ALWAYS PICK

YOUR SLEEPOVER SEAT

UNIT UP BY THE HANDLES

SITUATED BELOW THE SIDE

ARMS, NEVER BY THE HOOD

OR BUMPER BAR.

Detaching the seat unit from the

chassis.

9.1 Place your hands in the elasticated

side pockets of the Sleepover seat

unit.

9.2 Gently grip the inner release catch,

and slide the release handle towards

the foot end of the Sleepover seat

unit. Squeeze to release the locking

catches. The seat unit will now lift

clear of the chassis.

9.2
