SIIG USB 2.0+1394 DV Kit Manual de usuario
1
USB 2.0+1394 DV Kit
Quick Installation Guide
04-0288E
Introducing the USB 2.0+1394 DV Kit
The USB 2.0+1394 DV Kit is a complete DV editing kit --
acombocardwithUSB2.0andFireWire(1394a)interfaces,
deluxe DV editing software (full DV, AVI, QuickTime,
Windows Media, RealNetworks, and MPEG2 support)
and a 1394 6-pin/4-pin DV cable.
Features and Benefits
• Combo card design adds four USB 2.0 (480 Mbps)
and three 1394a (400 Mbps) ports into your system.
• Hot-swapping feature allows you to connect/
disconnectdeviceswithoutfirstturningyour system
off
USB 2.0 interface
• Adds three external and one internal USB 2.0 ports
• Compliant with USB specification rev. 2.0
• Supports high-speed (480 Mbps), full-speed (12
Mbps), and low-speed (1.5 Mbps) data transfer
modes for simultaneous operation of multiple USB
2.0/1.1 devices
Note: USB 1.1 devices are limited to USB 1.1 speeds
evenwhentheyareconnectedtoUSB2.0hostadapter
or USB 2.0 hubs.
FireWire (1394a) interface
• Adds two external and one internal FireWire ports
2
• IEEE1394-1995,P1394a(rev.1.1) and OHCIInterface
Specification 1.0 compliant
• Supports serial bus data transfer rates of 100, 200
and 400 Mbps
System Requirements
• Pentium or equivalent computer with an available
PCI slot
• Windows 98SE/ME
• Windows 2000 (with SP 3) or later
• Windows XP (with SP 1) or later
• Windows Server 2003
Recommended system for DV capturing editing:
• Pentium III or above
• 128 MB RAM and CD-ROM drive
• 4 GB of available hard disk space
• Windows 98SE or later
PackageContents
•USB 2.0+1394 adapter
• 1394 6-pin/4-pin DV cable
• Driver CD
• Ulead VideoStudio DV editing software (deluxe
version)
• This quick installation guide
3
Board Layout
Figure 1. Board Layout
Power Connector
(optional)
USB 2.0 Port
USB 2.0
Ports
1394 Ports 1394 Port
Note: This power connector (same as the one
used with your floppy disk drive) is designed
to provide additional power to the board when
needed. This connection is optional. We
recommend to connect this power connector
when the following conditions occur:
- All ports are used.
- Device(s) not being detected.
In case you need to connect this power
connector, power off your system first before
making this connection.
4
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer.
2. Unplugthepower cord and removeyourcomputer's
cover.
3. Remove the slot bracket from an available PCI slot.
4. Carefully align the card to the selected PCI slot push
the board down firmly, but gently, until it is well
seated.
5. Replace the slot bracket's holding screw to secure
the card.
6. Replacethecomputercoverand reconnect the power
cord.
Driver Installation
To ensure proper installation of this board, please follow
these instructions step-by-step.
Windows 98SE
1. Install the board, boot up the system, and insert the
driver CD.
2. WhenWindowsbootsup,attheAdd New Hardware
Wizard window, click Cancel four times.
5
3. Click Start, then Run. Type in X:\setup.exe and
click OK. (Change X: to match your CD-ROM drive
letter)
4. Click Next, Next, at the Warning box click OK, then
click Finish to restart.
5. When the VIA ...Universal Host Controller is
detected, click Next.
6. Choose Search for the best driver... and click Next.
7. Clear all check boxes, click Next, Next, Next.
NOTE: If prompted for Windows 98SE Installation
CD, click OK. Insert this CD and click OK.
8. Click Finish.
9. When the VIA ...Universal Host Controller is
detected, click Next.
10. Repeat steps 6, 7and 8.
11. WhentheUSBEnhancedHostController isdetected,
click Next.
12. Repeat step 6.
13. Clear all check boxes, click Next, Next, then Finish.
14. When the VIA OHCI IEEE 1394 Host Controller is
detected, click Next.
15. Repeat steps 6and 13 to complete the installation.
Windows ME
1. Install the board, boot up the system, and insert the
driver CD.
2. WhenWindowsbootsup,attheAdd New Hardware
Wizard window, click Cancel. Click No to decline
restart.
6
3. Click Start, then Run. Type X:\setup.exe and click
OK. (Change X: to match your CD-ROM drive
letter).
4. Follow the on-screen instructions to install the
driver. When prompted click Finish to restart.
5. At the Add New Hardware Wizard, choose
Automatic search for a better ..., click Next, then
click Finish.
6. Click Yes to restart Windows to complete.
Windows 2000
Windows 2000 Service Pack 3 (SP 3) or later is required
for this installation.
If you have have Windows 2000 Service Pack 4 (SP4) or
later installed, Windows will automatically detect and
install the correct driver for this board. Otherwise, follow
all steps below.
1. Install the board, boot up the system, and insert the
driver CD.
2. When Windows boots up, at the Found New
Hardware Wizard window, click Cancel.
3. Click Start, then Run. Type X:\setup.exe and click
OK. (Change X: to match your CD-ROM drive
letter).
4. Click Next, Next to accept the license agreement,
then Next to install the USB 2.0 driver.
5. Click Yes to confirm restarting the system
automatically.
6. Click Yes to accept Software License Agreement,
then click OK.
7. Click the Print to File icon, then click OK.
7
8. When Windows restarts, the drivers will install
automatically.
Windows XP/Server 2003
Windows XP Service Pack 1 (SP 1) or later is required for
this installation.
Windows XP Service Pack 1 or later will automatically
detect and install the correct drivers for this board.
Windows2003Serverwill automatically detect andinstall
the correct drivers for this board.
To Verify Successful Driver Installation
1. Check Device Manager to verify successful driver
installation.
Windows 98SE/ME: From the main desktop, right
click My Computer, then click Properties. Click
Device Manager tab.
Windows 2000/XP/Server 2003: Right click My
Computer, then click Manage. Click Device
Manager.
2. The drivers for this controller show up differently
under different versions of Windows. Please refer
to the correct Windows version to verify.
Windows 98SE/ME/2000 (with sp3):
a) Under the Universal Serial Bus Controllers:
- VIA PCI to USB Enhanced Host Controller
- USB 2.0 Root Hub
- VIA ... USB Universal Host Controller
- VIA ... USB Universal Host Controller
- USB Root Hub
- USB Root Hub
8
b) Under the 1394 Bus Controller or IEEE 1394 Bus
host controllers:
- VIA OHCI Compliant IEEE 1394 Host Controller
Windows 2000 (with SP4 or later):
a) Under the Universal Serial Bus Controllers:
- VIA ... Universal Host Controller
- VIA ... Universal Host Controller
- VIA USB Enhanced Host Controller
- USB 2.0 Root Hub
- USB Root Hub
- USB Root Hub
b) Under the IEEE 1394 Bus host controllers:
- VIA OHCI Compliant IEEE 1394 Host Controller
Windows XP (with SP1 or later)/Server 2003:
a) Under the Universal Serial Bus Controllers:
- VIA ... USB Universal Host Controller
- VIA ... USB Universal Host Controller
- VIA USB Enhanced Host Controller
- USB Root Hub
- USB Root Hub
- USB Root Hub
b) Under the IEEE 1394 Bus host controllers:
- VIA OHCI Compliant IEEE 1394 Host Controller
9
Ulead VideoStudio Software Installation
TheUSB 2.0 + 1394 DV Kit includesUlead®VideoStudioTM
digital video editing software for producing home videos
complete with attractive titles, transitions and sounds.
Before installing VideoStudio, make sure your adapter
andDV camcorder are properly installed and configured.
See next section, Connecting DV Camcorder,for more
details on how to properly install your DV camcorder.
1. Insertthe UleadVideoStudioDVsoftwareCD. Auto-
run should start automatically. If not, click Start,
Run, type in X:\Setup.exe, then click OK. (Change
X: to match your CD-ROM drive letter).
2. Select a language, click Next and follow on-screen
instructions to complete installation.
Note: For instructions on how to use Ulead
VideoStudio, please refer to VStudio.pdf file
located in the Manual directory on the Ulead
VideoStudio DV software CD.
Connecting DV Camcorder
Before setting up the digital video camcorder, make sure
to verify the driver for the adapter has been successfully
installed in your system and follow the setup procedures
listed below.
1. Boot up your system.
2. Connect the 4-pin connector of the provided
FireWire (1394) 6-pin/4-pin DV cable into your
digital camcorder, and connect the 6-pin connector
into an available port on the 1394 adapter. Power on
the camcorder. The camcorder should now appear
in Device Manager.
10
To Verify Successful DV Camcorder Setup
1. Check Device Manager to verify successful driver
installation.
Windows 98SE/ME: From the main desktop, right
click My Computer, then click Properties. Click
Device Manager tab.
Windows 2000/XP/2003: Right click My Computer,
click Manage,then click Device Manager.
2. Double click Imaging Device(s).
-A MicrosoftDVCameraandVCRorDVCamcorder
should be displayed.
