SIIG USB-to-PS/2 Manual de usuario

USB-to-PS/2

Quick Installation Guide

Introducing the USB-to-PS/2

The USB-to-PS/2 converts traditional PS/2 keyboard/

mouse to use USB interface. It also allows usage for

multiple keyboards and mice in the same system.

Features and Benefits

• Compliant with USB HID Specifications

• Fully compliant with PS/2 keyboard/mouse

• Supports standard Windows Multimedia keys

• Hot-swapping feature allows you to attach/detach

USB devices without first powering your computer

off

• Low power consumption--powered from USB bus

Serial # Sticker

For future product return or exchange, this serial # is

required. Please keep it for your reference.

04-0292A

System Requirements

• PC or Mac computer with one available USB port

• Windows 98/98SE/ME/2000/XP

• Mac OS 9.0 or later

Package Contents

• (1) USB-to-PS/2 adapter

• This quick installation guide

Layout

Figure 1. USB-to-PS/2 Layout

Installation

ThroughoutWindowsinstallation,youmaybeprompted

to insert Windows Installation CD. Some files on this CD

are neccessary to complete driver installation. Please

insert CD when prompted and follow on-screen

instructions.

PS/2 Keyboard &

Mouse Connectors

To USB Port

1. Connect the PS/2 keyboard and/or mouse to the

appropriate PS/2 connector. Each PS/2 connector has

a picture of either a keyboard or a mouse on it.

2. Connect the USB connector to your system's USB port

and power on your system if it's not already on.

Windows 98/98SE Installation

1. At the Add New Hardware Wizard, click Next.

2. Choose Search for the best driver... and click Next.

3. Clear all check boxes and click Next.

4. Click Next and Finish.

5. In Windows 98, repeat steps 1-4 two more times.

In Windows 98SE, repeat steps 1-4 one more time.

Windows ME/2000/XP Installation

The drivers are built-in with Windows ME, 2000 and XP.

Simply connect the USB-to-PS/2 to an available USB port

and the drivers will install automatically.

Give Windows a few seconds to completely load all

drivers.

Mac OS 9.0 or later

The drivers are built-in with Mac OS 9.0 or later. Simply

connect the USB-to-PS/2 to an available USB port and the

drivers will install automatically.

GiveMacOSafewsecondstocompletelyloadalldrivers.

Technical Support

QUESTIONS? SIIG’s Online Support has the answers!

Simply visit our web site at www.siig.com and click on

Support. Our online support database is updated daily

with new drivers and solutions. The answers to your

problems could be just a few clicks away.

PRODUCT NAME MODEL NUMBER

USB-to-PS/2 US2283

FCC RULES: TESTED TO COMPLY WITH FCC PART 15,

CLASS B OPERATING ENVIRONMENT: FOR HOME OR

OFFICE USE

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

THE PARTY RESPONSIBLE FOR

PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Ave.

Fremont, CA 94538-3152

USB-to-PS/2 is a trademark of SIIG, Inc. All other names

used in this publication are for identification only and may be

trademarks of their respective companies.
