SIIG M1 Manual de usuario
1
Universal AC/Dual USB
Power Adapter - 90W
Quick Installation Guide
04-0864A
Introduction
The UniversalAC/DualUSBPowerAdapter-90W isanauto-
switching 90 watt universal laptop AC power adapter/
charger with both a 2.1A and 1A USB charging port.
Features and Benefits
• Perfectasanadditionalor replacementACadapter/
charger for most laptop computers
• Includes 12 adapter tips for a variety of laptop/
notebook computers – including Acer, Asus,
Compaq, Dell, Fujitsu, Gateway, HP, IBM, Lenovo,
Sony, Toshiba and more
• Coded tips make identifying correct tip to match
laptop computer easier
• Output voltage settings adjusted automatically
based on adapter tip or device attached
• Automaticallyadjustsinputvoltageforworldwide
use with no need for voltage converter (country
specific wall plug adapter may be required)
• 5V/2.1A USB and 5V/1A USB charging ports
perfect for fast charging of iPad, Galaxy, iPhone
and other USB powered devices
2
Introduction
The Universal AC/Dual USB Power Adapter - 90W plugs into
any AC power outlet anywhere in the world* and provides
reliable power to run your notebook/laptop computer
and charge its battery. The Universal AC/Dual USB Power
Adapter - 90W uses quality components and features
advanced voltage and heat protection circuits to ensure
safety and efficiency.
*Note: A wall plug adapter may be necessary to
plug into AC power outlets outside of the United
States, however, no voltage converter is needed
anywhere in the world.
This adapter comes with a variety of numbered tips, to
ensure that the proper voltage is delivered to your laptop,
make sure that you are using the correct tip for your
specific laptop model. Read the following instructions and
refer to the Adapter Tip Compatibility List to select the
correct tip for your laptop.
Note: The Universal AC/Dual USB Power Adapter -
90W isnotcompatible with Mac laptop computers.
Safety information
• Do not expose the power adapter to rain, moisture
or dust
• Do not use the adapter in direct sunlight
• Use the Universal AC/Dual USB Power Adapter - 90W
in a well ventilated area
3
• Do not open the power adapter under any
circumstances. The power adapter is not intended
to be repaired. There are no internal servicable
parts.
• Discontinue use if any of the following should
occur:
- The adapter shuts down or the LED turns off when
plugged into your laptop.
- The AC cord, output cable or plug is damaged or
frayed.
• Do not use with laptops that require more than 90
watts of power.
• Make sure to use the correct adapter tip for your
laptop listed in the Adapter Tip Compatibility List.
Do not use a tip that is not listed on the Adapter
Compatibility List with your laptop.
Note: Forthe most updatedadapter tip compatibility
list, please check the support section at
www.siig.com.
Package Contents
•Universal AC/Dual USB Power Adapter - 90W
• 12 Adapter tips
• AC power cord
• Travel bag
• Quick installation guide
4
Layout
Figure1:Layout
Using the Universal AC/Dual USB Power
Adapter - 90W
1. Select your notebook/laptop brand and model
from the Adapter Tip Compatibility List to find the
right adapter tip.
Note: The use of an incorrect adapter tip may
damage your laptop. Do not use this product if
your laptop model is not listed in the Adapter Tip
Compatibility List.
2. Locate the specified adapter tip from the included
adaptertip bundle. Each tip is clearly marked on the
side. See Figure 2 below.
AC Adapter
LED
Output Cable
Adapter Tip
AC Cord
Figure 2: Adapter Tip
Ridge
Tip Number
5V/2.1A (max) USB
Charging Port
5V/1A (max) USB
Charging Port
5
3. Connect the selected adapter tip to the end of the
output cable, make sure that the ridge on the inside
of the adapter tip aligns with the groove in the
output cable connector. Also, make sure that the
adapter tip is pushed all the way into the connector.
4. Plug the AC cord into the AC adapter.
5. Plug the other end of the AC cord into a reliable
power outlet. The LED on the AC adapter turns
green indicating that it is powered and ready for
use.
Note: If the LED does not turn on or turns off,
discontinue use.
6. Plug the adapter tip into your laptop. The Universal
AC/Dual USB Power Adapter - 90W powers the
laptop and charges it's battery.
6
Dual USB Charging Port
The additional 5V/2.1A USB and 5V/1A USB charging
ports can be used to charge your iPad, tablet computer,
iPhone,mobile phone, MP3player,and other USBpowered
devices. You can charge your laptop and use the USB
charging ports individually or at the same time.
1. Connect your USB charging cable to your device,
then connect the USB charging cable into the USB
charging port of the Universal AC/Dual USB Power
Adapter - 90W.
2. Plug the Universal AC/Dual USB Power Adapter -
90W into a reliable AC power outlet.
Note: The USB charging ports do not function like
a regular USB port. It will only charge your device.
7
Adapter Tip Specification
Tip M1
• Output voltage: 15V
• Voltage range: 14.2V - 15.5V
• Output current (max): 6A
• Connectors: 6.3 (OD) x 3.0 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• Toshiba: 15V/3A, 15V/4A, 15V/5A, 15V/6A
• NEC: 15V/4A, 15V/6A
Tip M2
•Output voltage: 16V
•Voltage range: 15.2V - 16.5V
•Output current (max): 5A
•Connectors: 5.5 (OD) x 2.5 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• IBM / Lenovo: 16V/2.2A,16V 3.36A,16 /3.5A,16V/
4.5A,16V/4.5A
8
Tip M3
• Output voltage: 16V
• Voltage range: 15.2V - 16.5V
• Output current (max): 5A
• Connectors: 6.0 (OD) x 4.4 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• Sony: 16V/3.42A, 16V/3.75A, 16V/4A
• Fujitsu: 16V/2.5 to 4A
Tip M4
• Output voltage: 18.5V
• Voltage range: 18.2V - 19V
• Output current (max): 4.9A
• Connectors: 4.8 (OD) x 1.7 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• HP/Compaq:18.5V/2.7A,18.5V/3.5A, 18.5V/ 3.8A,
18.5V / 4.9A
• ASUS: 19V/2.64A, 19.3V/3.42A
9
Tip M5
• Output voltage: 19V
• Voltage range: 18.2V - 19.5V
• Output Current (max): 4.7A
• Connectors: 5.5 (OD) x 2.5 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• ASUS: 19V/4.74A
• Dell: 19V/3.16A, 19V/3.42A
• Compaq/HP: 18.5V/4.9A, 19A/4.9A
• Toshiba:19V/3.16A, 19V/3.42A, 19V/4.74A;
• Fujitsu: 19V/4.22A
• Gateway:19V/3.16A,19V/3.42A,19V/3.68A, 19V/
4.74A
• ACER: 19V/4.7A
• NEC: 19V/3.0A
Tip M6
• Output voltage:19V
• Voltage range: 18.2V - 19.5V
• Output current (max): 4.7A
• Connectors: 5.0 (OD) x 3.0 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• Samsung: 19V/3.16A, 19V/3.75A, 19V/4.22A,
19V/4.74A
10
Tip M7
• Output voltage: 19V
• Voltage range: 18.2V - 19.5V
• Output current (max): 4.7A
• Connectors: 5.5 (OD) x 2.1 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• Acer: 19V/3.16A, 19V/3.42A, 19V/4.74A
• Gateway: 19V/3.0A, 19V/3.7A, 19V/4.74A
• Compaq/HP: 19V/3.0A
• IBM/Lenovo: 19V/4.7A
• Dell: 19V/3.0A
Tip M8
• Output voltage: 19.5V
• Voltage range: 18.7V - 20V
• Output current (max): 4.5A
• Connectors: 6.0 (OD) x 4.4 (ID) x 10.7 (L) mm
Replacement: voltage and amperage for each notebook
the tip can replace
• Sony: 19.5V/2.7A,19.5V/3A, 19.5V/4.1A, 19.5V/
4.7A
