Siemens SIMATIC ET 200SP Documento técnico

SIMATIC

ET 200SP

Digital output module RQ

4x120VDC

-230VAC/5A NO MA ST

(6ES7132-6MD00-0BB1)

Equipment Manual

A5E36107692

-AB

Preface

ET 200SP Documentation

Guide

Product overview

Wiring

Parameters/address space

Interrupts/diagnostics

alarms

Technical specifications

Parameter data record

A5E36107692-AB

Ⓟ

07/2020 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

Siemens AG

Digital Industries

Postfach 48 48

90026 NÜRNBERG

GERMANY

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

Equipment Manual, , A5E36107692-AB 3

Preface

Purpose of the documentation

This manual supplements the ET 200SP distributed I/O system

(https://support.automation.siemens.com/WW/view/en/58649293) system manual.

Functions that generally relate to the system are described in this system manual.

The information provided in this manual and in the system/function manuals supports you in

commissioning the system.

Changes compared to previous version

Compared to the previous version, this manual contains the following change:

•Wiring and block diagram for 2-wire and 3-wire connection has been changed.

•The technical specifications have been updated.

Conventions

CPU: When the term "CPU" is used in the following, it applies to the CPUs of the S7-1500

automation system as well as to the CPUs/interface modules of the ET 200SP distributed I/O

system.

STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the

configuration and programming software "STEP 7 (TIA Portal)".

Please also observe notes marked as follows:

Note

A note contains important information on the product described in the documentation, on

the handling of the product or on th

e section of the documentation to which particular

attention should be paid.

Recycling and disposal

For environmentally friendly recycling and disposal of your old equipment, contact a certified

electronic waste disposal company and dispose of the equipment according to the applicable

regulations in your country.

Preface

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

4Equipment Manual, , A5E36107692-AB

Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, systems, machines and networks.

In order to protect plants, systems, machines and networks against cyber threats, it is

necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial

security concept. Siemens’ products and solutions constitute one element of such a concept.

Customers are responsible for preventing unauthorized access to their plants, systems,

machines and networks. Such systems, machines and components should only be connected

to an enterprise network or the internet if and to the extent such a connection is necessary

and only when appropriate security measures (e.g. firewalls and/or network segmentation)

are in place.

For additional information on industrial security measures that may be implemented, please

visit (https://www.siemens.com/industrialsecurity).

Siemens' products and solutions undergo continuous development to make them more

secure. Siemens strongly recommends that product updates are applied as soon as they are

available and that the latest product versions are used. Use of product versions that are no

longer supported, and failure to apply the latest updates may increase customers' exposure to

cyber threats.

To stay informed about product updates, subscribe to the Siemens Industrial Security RSS

Feed visit (https://www.siemens.com/industrialsecurity).

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

Equipment Manual, , A5E36107692-AB 5

Table of contents

Preface ................................................................................................................................................... 3

1 ET 200SP Documentation Guide ............................................................................................................ 6

2 Product overview................................................................................................................................... 8

2.1 Properties ............................................................................................................................ 8

3 Wiring .................................................................................................................................................. 10

3.1 Wiring and block diagram .................................................................................................. 10

4 Parameters/address space ................................................................................................................... 14

4.1 Parameters ........................................................................................................................ 14

4.2 Explanation of the parameters ........................................................................................... 16

4.3 Address space.................................................................................................................... 17

5 Interrupts/diagnostics alarms .............................................................................................................. 19

5.1 Status and error display...................................................................................................... 19

5.2 Interrupts .......................................................................................................................... 21

5.3 Diagnostics alarms............................................................................................................. 21

6 Technical specifications....................................................................................................................... 22

6.1 Technical specifications ..................................................................................................... 22

6.2 Switching cycles ................................................................................................................ 27

A Parameter data record......................................................................................................................... 29

A.1 Parameter assignment and structure of the parameter data record ..................................... 29

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

Equipment Manual, , A5E36107692-AB 6

ET 200SP Documentation Guide

The documentation for the SIMATIC ET 200SP distributed I/O system is arranged into three

areas.

This arrangement enables you to access the specific content you require.

Basic information

The System Manual and Getting Started describe in detail the configuration, installation,

wiring and commissioning of the SIMATIC ET 200SP distributed I/O system. The STEP 7 online

help supports you in the configuration and programming.

Device information

Product manuals contain a compact description of the module-specific information, such as

properties, wiring diagrams, characteristics and technical specifications.

ET 200SP Documentation Guide

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

Equipment Manual, , A5E36107692-AB 7

General information

The function manuals contain detailed descriptions on general topics regarding the SIMATIC

ET 200SP distributed I/O system, e.g. diagnostics, communication, Web server, motion

control and OPC UA.

You can download the documentation free of charge from the Internet

(https://support.industry.siemens.com/cs/ww/en/view/109742709).

Changes and supplements to the manuals are documented in a Product Information.

You can download the product information free of charge from the Internet

(https://support.industry.siemens.com/cs/us/en/view/73021864).

Manual Collection ET 200SP

The Manual Collection contains the complete documentation on the SIMATIC ET 200SP

distributed I/O system gathered together in one file.

You can find the Manual Collection on the Internet

(https://support.automation.siemens.com/WW/view/en/84133942).

"mySupport"

With "mySupport", your personal workspace, you make the most of your Industry Online

Support.

In "mySupport" you can store filters, favorites and tags, request CAx data and put together

your personal library in the Documentation area. Furthermore, your data is automatically

filled into support requests and you always have an overview of your current requests.

You need to register once to use the full functionality of "mySupport".

You can find "mySupport" in the Internet (https://support.industry.siemens.com/My/ww/en).

Application examples

The application examples support you with various tools and examples for solving your

automation tasks. Solutions are shown in interplay with multiple components in the system -

separated from the focus in individual products.

You can find the application examples on the Internet

(https://support.industry.siemens.com/sc/ww/en/sc/2054).

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

8Equipment Manual, , A5E36107692-AB

Product overview

2.1 Properties

Article number

6ES7132-6MD00-0BB1

View of the module

①

Module type and name

⑧

Toggle/jog switch for manually controlling

the relay

②

LED for diagnostics

⑨

Color coding of module type

③JOG (switch position up: jog)

AUT (switch position "middle": Automatic mode

ON (switch position down: Manual mode

(MANUAL ON))

⑩Function and firmware version

④Wiring diagram ⑪Color code for selection of the color coding

labels

⑤

LEDs for channel status and manual mode

⑫

BU type

⑥

LED for supply voltage

⑬

Article number

⑦

Function class

Figure 2-1 View of the module RQ 4×120VDC-230VAC/5A NO MA ST

Product overview

2.1 Properties

Digital output module RQ 4x120VDC-230VAC/5A NO MA ST (6ES7132-6MD00-0BB1)

Equipment Manual, , A5E36107692-AB 9

Properties

The module has the following technical properties:

•Digital output module with 4 floating relay outputs

•Supply voltage L+

•Output current 5 A (per output)

•Normally open contact (NO: normally open)

•Configurable diagnostics (per module)

•Configurable substitute values (per channel)

•4 toggle/jog switches (jog, automatic or manual mode (MANUAL ON)) for controlling the

relay

•Suitable for solenoid valves, DC contactors, and indicator lights

The module supports the following functions:

•Firmware update

•I&M identification data

•Configuration in RUN

•PROFIenergy

•Value status

You can configure the module with STEP 7 (TIA Portal) and with a GSD file.

Note

When load voltage is present, the relays of the RQ 4x120VDC

-230VAC/5A NO MA ST can also

be act

ivated via a manual switch even when they are in a non-configured state.

When an output is set to manual control, the relay remains active during a firmware update.

Accessories

The following accessories must be ordered separately:

•Color identification labels

•Reference identification label

•Shield connector

Manuales populares de Sistema de E/S de otras marcas

WAGO

WAGO 750-344 Manual de usuario

Teknim

Teknim TWM-1887 Manual de instrucciones

Intelligent Appliance

Intelligent Appliance IA-2662-E Manual de usuario

BERGHOF

BERGHOF ECC DIO 16/16 Manual de instrucciones

Advantech

Advantech PCM-27J3AU Manual de instalación y operación

Festo

Festo CP-E08-M12-CL Manual de usuario

Measurement Computing

Measurement Computing PCI-DAS64/M1/16 Manual de usuario

Hitachi

Hitachi HX-RIO3 Series Manual de usuario

NUUO

NUUO SCB-A08 Manual de usuario

M-system

M-system R3Y-RS8 Manual de usuario

jablotron

jablotron JB-110N Manual de usuario

Omron

Omron SYSMAC C200H Manual de usuario

DOLD

DOLD SAFEMASTER M Manual de usuario

ABB

ABB OPT-MF-001 Manual de usuario

Omron

Omron SYSMAC C2000H Manual de usuario

Helmholz

Helmholz TB20 Manual de usuario

ICP DAS USA

ICP DAS USA tM-AD2 Manual de usuario

Automationdirect.com

Automationdirect.com DL305 Manual de usuario
