Siemens SIMATIC IOT2050 Manual de usuario

SIMATIC IOT2050 Starterkit

Product Information

06/2021

A5E50831253

-AA

Package list

Preparing for installation

Mounting the device

Connecting the device

Installing the IOT2000

Input/Output Module

Insert Micro SD card

Siemens AG

Digital Industries

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E50831253-AA

Ⓟ

05/2021 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

SIMATIC IOT2050 Starterkit

Product Information, 06/2021, A5E50831253-AA 3

Table of contents

1 Package list ............................................................................................................................................ 4

2 Preparing for installation....................................................................................................................... 6

2.1 Checking the delivery........................................................................................................... 6

2.2 Identification data of the device........................................................................................... 8

2.3 Permitted mounting positions and mounting types .............................................................. 8

3 Mounting the device ........................................................................................................................... 10

3.1 Mounting instructions........................................................................................................ 10

3.2 Mounting on DIN rails ........................................................................................................ 11

3.2.1 Secure the mounting clips.................................................................................................. 11

3.2.2 Mounting on DIN rails ........................................................................................................ 13

3.3 Wall mounting ................................................................................................................... 14

3.3.1 Vertical wall mounting....................................................................................................... 14

3.3.2 Horizontal wall mounting................................................................................................... 15

4 Connecting the device......................................................................................................................... 16

4.1 Notes on connecting.......................................................................................................... 16

4.2 Connecting the function earth ........................................................................................... 17

4.3 Connecting the power supply............................................................................................. 19

5 Installing the IOT2000 Input/Output Module ...................................................................................... 20

6 Insert Micro SD card............................................................................................................................. 23

Index .................................................................................................................................................... 24

SIMATIC IOT2050 Starterkit

4Product Information, 06/2021, A5E50831253-AA

Package list

SIMATIC IOT2050 Starterkit

Product Information, 06/2021, A5E50831253-AA 5

IOT2050 Starterkit contains the following components:

Quantity

Name

Specification

SIMATIC IOT2050

6ES7647-0BA20-0SP2

SIMATIC IOT2000 In-

put/Output Module

A5E39310827

5 x DI, 2 x AI, 2 x DO

Cover for Input/Output

Module and three plastic

mounting clamps

A5E50613788

SD card (Inserted in

IOT2050)

8 GB

Power adapter

AC-DC Power supply, 12 V

Network cable

RJ45 cable, 1.5 m

Accessory Kit

Mounting bracket, mounting clamps and

screws

Quick Install Guide

Printed paper

OSS Readme

Printed paper

Important notes on your

device

Printed paper

Note: Additional information on the software topics, commissioning and Micro SD image is

available in the SIMATIC IOT2000 Forum (http://www.siemens.com/automation/forum).

SIMATIC IOT2050 Starterkit

6Product Information, 06/2021, A5E50831253-AA

Preparing for installation

2.1 Checking the delivery

Procedure

1. When accepting a delivery, please check the packaging for visible transport damage.

If any transport damage is present at the time of delivery, lodge a complaint at the

shipping company in charge. Have the shipper confirm the transport damage

immediately.

2. Unpack the device at its installation location.

3. Keep the original packaging in case you have to transport the unit again.

Note

Damage to the d

evice during transport and storage

If a device is transported or stored without packaging, shocks, vibrations, pressure and

moisture may impact the unprotected unit. A damaged packaging indicates that ambient

conditions have already had a massive impact on

the device.

The device might be damaged.

Do not dispose of the original packaging. Pack the device during transportation and

storage.

4. Check the contents of the packaging and any accessories you may have ordered for

completeness and damage.

–Device

–DC connecting terminal, already plugged into the device.

–One mounting accessory kit including: 1 x Rail clamp, 2 x mounting brackets and

screws.

Preparing for installation

2.1 Checking the delivery

SIMATIC IOT2050 Starterkit

Product Information, 06/2021, A5E50831253-AA 7

5. If the contents of the packaging are incomplete, damaged or do not match your order,

inform the responsible delivery service immediately.

WARNING

Electric shock and fire hazard due to damaged device

A damaged device can be under hazardous voltage and trigger a fire in the machine or

plant. A damaged device has unpredictable properties and states.

Death or serious injury could occur.

Make sure that the damaged device is not inadvertently installed and put into operation.

Label the damaged device and keep it locked away. Send off the device for immediate

repair.

NOTICE

Damage from condensation

If the device is subjected to low temperatures or extreme fluctuations in temperature

during transportation, for example in cold weather, moisture could build up on or inside

the device (condensation).

Moisture causes a short circuit in electrical circuits and damages the device.

In order to prevent damage to the device, proceed as follows:

•Store the device in a dry place.

•Bring the device to room temperature before starting it up.

•Do not expose the device to direct heat radiation from a heating device.

•If condensation develops, wait approximately 12 hours or until the device is

completely dry before switching it on.

6. Keep the enclosed documentation in a safe place. You need the documentation when you

commission the device for the first time.

7. Write down the identification data of the device.

Preparing for installation

2.2 Identification data of the device

SIMATIC IOT2050 Starterkit

8Product Information, 06/2021, A5E50831253-AA

2.2 Identification data of the device

The device can be clearly identified with the help of this identification data in case of repairs

or theft.

You can find this information on the rating plate. The following illustration shows an

example.

Example rating plate:

Enter the identification data in the table below:

Order number

6ES ...

Serial number

S V

Production version

All existing Ethernet ad-

dresses (MAC)

2.3 Permitted mounting positions and mounting types

The device can be mounted horizontally or vertically on a DIN rail or to a wall.

Vertical mounting position, preferred

Horizontal mounting position

Preparing for installation

2.3 Permitted mounting positions and mounting types

SIMATIC IOT2050 Starterkit

Product Information, 06/2021, A5E50831253-AA 9

Consider the permitted temperature range for operation that depends on the mounting

position.

Mounting type

Ambient temperature for operation

Rail mounting

•Vertical: 0 to 50 °C

•

Horizontal: 0 to 40 °C

Wall mounting

•Vertical: 0 to 45 °C

•Horizontal: 0 to 40 °C

Clearances

Ensure that the following clearances measurements to another component or to a wall of a

housing are complied with:

•Below the device: ≥50 mm

•Above the device: ≥50 mm

SIMATIC IOT2050 Starterkit

10 Product Information, 06/2021, A5E50831253-AA

Mounting the device

3.1 Mounting instructions

Note the following:

•The device is approved for indoor operation only.

•For installation in a cabinet, observe the SIMATIC setup guidelines

(http://support.automation.siemens.com/WW/view/de/1064706) as well as the relevant

DIN/VDE requirements or the applicable country-specific regulations.

•When the device is used in the area of Industrial Control Equipment in accordance with

UL61010-2-201, note that the device is classified as "Open equipment".

•Siemens recommends you use 0.6 Nm tightening torque to install the mounting clamps

and brackets.

Fasten securely

NOTICE

Insufficient load carrying capacity

If the mounting surface for wall mounting does not have an enough load-bearing capacity,

the device may fall and be damaged.

Ensure that the mounting surface on the wall can bear four times the total weight of the

device, including fixing elements.

NOTICE

Incorrect fixing elements

If you use anchors and screws other than those specified below for wall mounting, safe

mounting is not guaranteed. The device can fall and may be damaged.

Only use the anchors and screws specified in the following table.

Material

Bore diameter

Fixing element

Concrete

Select according to the specifi-

cation of the mounting ele-

ments used

•Anchor, ∅6 mm, 40 mm long

•

Screw, ∅4 mm, 40 mm long

Plasterboard,

(at least 13 mm thick)

Toggle plug, ∅12 mm, 50 mm

long

Metal,

(at least 2 mm thick) •Screw M4 × 15

•M4 nut

Otros manuales para SIMATIC IOT2050

Tabla de contenidos

Otros manuales de Puerta de Siemens

Siemens

Siemens MindConnect Nano Manual de usuario

Siemens

Siemens SCALANCE X-200 Manual de usuario

Siemens

Siemens HiPath HG 1500 Manual de usuario

Siemens

Siemens HG 3500 V4 Manual de usuario

Siemens

Siemens FDCW241 Manual de usuario

Siemens

Siemens SIMATIC NET IE/WSN-PA Link Guía del administrador

Siemens

Siemens MindConnect Nano Manual de usuario

Siemens

Siemens Tiastar LV MCC Manual de usuario

Siemens

Siemens 5935 Manual de usuario

Siemens

Siemens A53457 Guía de mantenimiento y servicio

Siemens

Siemens 5WG1 141-1AB31 Manual de servicio

Siemens

Siemens OCT200.KNBA Manual de usuario

Siemens

Siemens SIMATIC IOT Manual de usuario

Siemens

Siemens SIMATIC FDE Gateway V1.1 Documento técnico

Siemens

Siemens SMG 71 Manual de usuario

Siemens

Siemens ProtoAir FPA-W44 Guía del usuario

Siemens

Siemens NK8237 MP4.81-02 Guía rápida

Siemens

Siemens SpeedStream 6500 Series Manual de usuario

Siemens

Siemens FDCW241 Manual de usuario

Siemens

Siemens GW-23 Manual de usuario

Siemens

Siemens NK8225 Manual operacional

Siemens

Siemens SpeedStream 6500 Series Manual de usuario

Siemens

Siemens SIMATIC RTLS Series Manual de usuario

Siemens

Siemens SpeedStream 6500 Series Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
