Siemens SIMATIC NET MM900 Series Guía del administrador

A5E03275846-04, 11/2015 1

SIMATIC NET

Industrial Ethernet switches

MM900 media modules for SCALANCE

XR-500M

Compact Operating Instructions

Legal information

Qualified Personnel

The product/system described in this documentation may be operated only by

personnel

qualified

for the specific task in accordance with the relevant documentation, in particular its

warning notices and safety instructions. Qualified personnel are those who, based on their

training and experience, are capable of identifying risks and avoiding potential hazards when

working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the

relevant technical documentation. If products and components from other manufacturers are

used, these must be recommended or approved by Siemens. Proper transport, storage,

installation, assembly, commissioning, operation and maintenance are required to ensure that

the products operate safely and without any problems. The permissible ambient conditions

must be complied with. The information in the relevant documentation must be observed.

MM900 media modules for SCALANCE XR-500M

2A5E03275846-04, 11/2015

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as

well as to prevent damage to property. The notices referring to your personal safety are

highlighted in the manual by a safety alert symbol, notices referring only to property damage

have no safety alert symbol. These notices shown below are graded according to the degree of

danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest

degree of danger will be used. A notice warning of injury to persons with a safety alert symbol

may also include a warning relating to property damage.

MM900 media modules for SCALANCE XR-500M

A5E03275846-04, 11/2015 3

Table of contents

1 Introduction..................................................................................................3

2 Description...................................................................................................4

2.1 Type designation....................................................................... 4

2.2 Product characteristics.............................................................. 5

2.3 Unpacking and checking ........................................................... 6

3 Installation ...................................................................................................6

4 Technical data..............................................................................................9

4.1 Mechanical and electrical data.................................................. 9

4.2 Cable lengths of the MM900 media modules for

SCALANCE XR-500M............................................................. 13

4.3 Other properties ...................................................................... 15

5 Dimension drawings ...................................................................................15

6 Approvals...................................................................................................17

Introduction

Purpose of the compact operating instructions

Based on the compact operating instructions, you will be able to install and connect

up the MM900 media module correctly.

Validity of these compact operating instructions

These compact operating instructions apply to the MM900 product group of the

SCALANCE X-500 product line as of product version 1.

Note

Additional literature

When working with m

edia modules, you should also read the compact operating

instructions of the SCALANCE XR

-500M product group.

You will find the compact operating instructions of the SCALANCE XR

500M product

group on the supplied CD.

Description

MM900 media modules for SCALANCE XR-500M

4A5E03275846-04, 11/2015

Description

2.1

Type designation

Structure of the type designation

The type designation an MM900 media module for SCALANCE X-500 consists of

several parts with the following meaning:

Interface

Property

10/100/1000 Mbps RJ-45 port electrical.

CUC

10/100/1000 Mbps RJ-45 port electrical with securing collar.

SFP

100/1000 Mbps SFP media module.

[-] 100 Mbps ST port optical, multimode fiber-optic cables,

up to max. 3 km.

1000 Mbps SC port optical, multimode fiber-optic cables,

up to max. 750 m.

LD 100 Mbps ST port optical, single mode fiber-optic cables,

up to max. 26 km.

1000 Mbps SC port optical, single mode fiber-optic cable,

up to max. 10 km.

PoE

10/100/1000 Mbps PoE port electrical, max. 60 W.

PoEC 10/100/1000 Mbps PoE port electrical, with securing collar, max.

60 W.

Description

MM900 media modules for SCALANCE XR-500M

A5E03275846-04, 11/2015 5

2.2

Product characteristics

Media modules

Type

Properties

Article number

MM991-4 4 x 100 Mbps, ST ports optical, multi-

mode fiber-optic cable, up to max. 5 km.

6GK5 991-4AB00-

8AA0

MM991-4LD 4 x 100 Mbps, ST ports optical, single

mode fiber-optic cable, up to max. 26 km.

6GK5 991-4AC00-

8AA0

MM992-4 4 x 1000 Mbps, SC ports optical, multi-

mode FO cable, up to max. 750 m.

6GK5 992-4AL00-

8AA0

MM992-4LD 4 x 1000 Mbps, SC ports optical, single

mode FO cable, up to max. 10 km.

6GK5 992-4AM00-

8AA0

MM992-4SFP 4 x 100 / 1000 Mbps, SFP media module 6GK5 992-4AS00-

8AA0

MM992-4CU 4 x 10/100/1000 Mbps, RJ-45 ports elec-

trical

6GK5 992-4SA00-

8AA0

MM992-4CUC 4 x 10/100/1000 Mbps, RJ-45 ports elec-

trical with securing collars

6GK5 992-4GA00-

8AA0

MM992-4PoE 4 x 10/100/1000 Mbps, PoE ports electri-

cal, max 60 W

6GK5 992-4QA00-

8AA0

MM992-4PoEC 4 x 10/100/1000 Mbps, PoE ports electri-

cal with securing collars, max 60 W

6GK5 992-4RA00-

8AA0

Components of the product

The following components are supplied with an MM900 media module:

●MM900 media module

●Compact operating instructions

Installation

MM900 media modules for SCALANCE XR-500M

6A5E03275846-04, 11/2015

2.3

Unpacking and checking

WARNING

Do not use any parts that show evidence of damage

If you use damaged parts, there is no guarantee that the device will function

according to the specification.

If you use damaged parts, this can lead to the following problems:

•Injury to persons

•Loss of the approvals

•Violation of the EMC regulations

Use only undamaged parts.

1. Make sure that the package is complete.

2. Check all the parts for transport damage.

If the consignment is incomplete or if there is damage to the exterior, contact your

supplier or your local Siemens office.

Installation

NOTICE

Failure of the data traffic due to contamination of optical plug-in connections

Optical sockets and plugs are sensitive to contamination of the end face.

Contamination can lead to the failure of the optical transmission network.

Close unused optical sockets and plugs as well as pluggable transceivers and slots

with the supplied protective caps.

Remove the protective caps only immediately before you use the plug-in

connection.

NOTICE

Use only approved media modules

In the module slots of SCALANCE XR500, use only approved media modules

"MM900" of the X-500 IE switch product line.

Installation

MM900 media modules for SCALANCE XR-500M

A5E03275846-04, 11/2015 7

Note

Slots for PoE modules

PoE modules can only be used in slots1, 2 and 3.

Note

The names and labeling of the media modules differ

Example: The device is called, for example MM992

-4SFP [6GK5 992-4AS00-8AA0],

the labeling on the device is 9924AS.

Note

Factory settings of the media modules

When inserting a media module, the parameters of the ports are set to the factory

defaults. Fir

st plug a media module into the device, and then assign the parameters

for the ports.

Identification of the media module slots and ports

The following table shows the arrangement of the slots and ports of a SCALANCE

XR552-12M:

Slot

Port P1 P2 P3 P4 P1 P2 P3 P4 P1 P2 P3 P4

Slot

Port

Slot 0,

port

(SFP+)

P1 P2 P3 P4

Slot

Port

Slot

Port

With a SCALANCE XR528-6M, there are total of six slots and four SFP+ ports.

Note

Slot number

In modular devices, the MM900 media modules can be assigned a slot number to aid

orientation. The slot number labels ship with the modular devices.

Installation

MM900 media modules for SCALANCE XR-500M

8A5E03275846-04, 11/2015

Plugging in media module

Figure 3-1 Plugging a media module into a SCALANCE XR552-12M. SCALANCE

XR528-6M is used analogously.

Follow the steps below to plug an MM900 media module into a SCALANCE XR500:

1. Remove the dummy covers of the device slot into which you want to insert a

media module.

2. Pull the handle out of the media module. The media module cannot be installed

unless the handle is pulled out.

3. Place the media module in the guide rails of the device slot. The media module is

correctly installed when it locks easily into the device and the front panel of the

module is flush with the front of the device.

4. Push the handle back into the module. The media module is then locked in place.
