SIMATIC NET
Produktinformation
Product Information
Information produit
Informazioni sul prodotto
Informaciónsobre producto
Stand/ Dated/ Edition/ Versione/ Versiòn 06/99
CP 343–1 6GK7 343-1BA00-0XE0
ab Ausgabestand 7 (FW–Stand V5.00)
version 7 or higher (firmware V5.00)
à partir de la version 7 (microprogramme V5.00)
a partire dalla versione 7 (versione FW V4.00)
a partir de la versión 7 (FW-V5.00)
SIMATIC S7–300
Deutsch / English / Français / Italiano / Español
ESIEMENS AG 1998
Änderungen vorbehalten
Subject to alteration
Sous réserve de modifications
Con riserva di modifiche
Sujeto a cambios
C79000–Z8964–C038–05
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Hinweis / Note / Avertissement / Avvertenza / Indicación
Achtung
Vor der Inbetriebnahme Hinweise in der entsprechenden aktuellen Dokumentation beachten. Die Bestelldaten
hierfür entnehmen Sie bitte den Katalogen oder wenden Sie sich an Ihre örtliche SI M NSĆNiederlassung.
Die Inbetriebnahme ist solange untersagt, bis festgestellt wurde, daß die Maschine, in die diese Komponente
eingebaut werden soll, den Bestimmungen der Richtlinie 89/392/ WG entspricht.
Attention
Prior to startup you must observe the notes in the relevant documentation. For ordering data of the documentaĆ
tion please refer to catologs or contact your local SI M NS representative.
Startup must not take place until it is established that the machine, which is to accommodate this component,
is in conformity the guideline 89/392/ C.
Attention
Avant la mise en service, respecter les instructions de la documentation actuelle correspondante. Pour les
références de commande de la documentation, veuillezĆvous reporter aux catalogues ou consulter votre
agence locale SI M NS.
La mise en service est interdite tant que la machine dans laquelle est incorporé ce composant n'est pas conĆ
forme aux prescriptions de la directive 89/392/C .
Attenzione
Prima della messa in funzione, osservare attentamente le avvertenze riportate nella documentazione corrente.
Per i dati di ordinazione consultare i cataloghi oppure rivolgersi alla locale fidale SI M NS.
La messa in funzione è vietata fino a quando non è stato acctertato che macchina, in cui il componente deve
essere installato, non rispetta le disposizioni della direttiva 89/392/CC .
Atención
Antes de la puesta en marcha observar las indicaciones contenidas en la documentatción actual corresponĆ
diente. La referencia de la misma puede consultarse en los catáloges o solicitarse a su agencia SI M NS local.
stá prohibida la puesta en marcha hasta comprobar que la máquina en donde va a incorporarse este compoĆ
nente cumple lo especificado en la directiva 89/392/CC .
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
1
Productinformation CP343–1
C79000–Z8964–C038–05
Contents
Notes for the Reader 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 The CP 343-1 Communications Processor 3. . . . . . . . . . . . . . .
1.1 Characteristics 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Performance Data 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1 Characteristics of S7 Communication 7. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.2 Characteristics of ISO Transport Connections 7. . . . . . . . . . . . . . . . . . .
1.3 Displays and Mode Selector 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Further Information on Operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Installation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Module Accessories 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Procedure 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Attaching the CP 343-1 to Industrial Ethernet 13. . . . . . . . . . . . . . . . . . . .
3 Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 General Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Pinout 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Notes on the CE Approval of SIMATIC NET Products 17. . . . . . . . . . . . .
4 References 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compatibility with the Previous Version
The version of the CP 343-1 described here is functionally compatible with and can
be used to replace the CP 343-1 with order number 6GK7 343–1BA00–0XE0 ver-
sion 6.
The CP 343-1 decribed here has more functions. Refer to the information in
Section 1.1.
Reply Form (at the end of this product information):
We would like to know the purpose for which you are using this module
and would also like to know your opinion of the module and the documen-
tation. You can help us to provide you with better support and to further
improve the product. We would be grateful if you would complete the reply
form and return it to us by post or fax.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
2Productinformation CP343–1
C79000–Z8964–C038–05
Notes for the Reader
Safety Guidelines
This manual contains notices which you should observe to ensure your
own personal safety, as well as to protect the product and connected
equipment. These notices are highlighted in the manual by a warning
triangle and are marked as follows according to the level of danger:
Note
draws your attention to particularly important information on the product, handling
the product, or to a particular part of the documentation.
!Caution
indicates that minor personal injury or property damage can result if proper pre-
cautions are not taken.
!Warning
indicates that death, severe personal injury or substantial property damage can
result if proper precautions are not taken.
!Danger
indicates that death, severe personal injury or substantial property damage will
result if proper precautions are not taken.
Wehavecheckedthecontentsofthismanualforagreementwiththe
hardware and software described. Since deviations cannot be
precludedentirely, we cannot guarantee full agreement. However,
the data in this manual are reviewed regularly and any necessary
corrections included in subsequent editions. Suggestions for
improvementare welcomed.
Technical data subject to change.
DisclaimerofLiabilityCopyrightESiemensAG 1998..1999 All rights reserved
The reproduction, transmission or use of this document or its
contents is not permitted without express written authority.
Offenders will be liable for damages. All rights, including rights
createdbypatentgrantorregistrationofautilitymodelordesign,are
reserved.
Siemens AG
A&D
IndustrialAutomationSystems
Postfach4848, D-90327Nürnberg
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
3
Productinformation CP 343–1
C79000–Z8964–C038–05
1 The CP 343-1 Communications Processor
Application
The CP 343-1 communications processor is designed for operation in an
S7-300 programmable logic controller. It allows the S7-300 to be attached to
Industrial Ethernet.
LED displays
Mode selector
AUI/ITP interface
15-pin sub D
with sliding locking
mechanism
Figure1 CP 343-1
Design
The module has been designed to match the components of the S7-300
programmable logic controller and has the following features:
SDouble-width module for simple installation in the S7-300 rack.
SThe operator controls and displays are all located on the front panel.
SNo fan necessary.
SDirect backplane bus connection of the modules via accompanying
backplane module connectors.
S15-pin sub D female connector with sliding locking mechanism for
attaching the CP 343-1 to Industrial Ethernet (automatic switchover
between the AUI interface and Twisted Pair interface).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
4Productinformation CP 343–1
C79000–Z8964–C038–05
Configuration
You can configure the CP 343–1 via MPI or LAN/Industrial Ethernet. You re-
quire STEP 7 with the following version of NCM S7 for Industrial Ethernet
(abbreviated to ”NCM IE”below):
Table 1
Version STEP7/NCM IE Functionality of the CP 343–1
V2.x to V5.x The same functionality is available as with the previous
versions of the CP.
SConfiguration data created with these STEP 7 or NCM
versions can be downloaded to the CP 343–1.
V5.x + SP2 or higher The full functionality including the extended functions as
listed in Section 1.1 can be used.
Information about the required service pack (SP2) is
available on the Internet at:
http://www.ad.siemens.de/csi/net
1.1 Characteristics
Services
The CP 343-1 supports the following communication services:
SS5-compatible communication with
–SEND/RECEIVE interface via ISO transport connections
–FETCH/WRITE services (passive; according to the S5 protocol) via
ISO transport connections and ISO-on-TCP connections
SS7 communication with
–PG functions
–Operator control and monitoring functions
–Data exchange using communication function blocks
PG functions:
Using the PG functions, modules such as the FM 354 or FM 355 can be
accessed via the CP (“extended”PG functions).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
5
Productinformation CP 343–1
C79000–Z8964–C038–05
Note
If there is a diagnostic connection to the CP via the CPU, configuration
data cannot be downloaded automatically to the CP by the CPU at the
same time!
Extended Functions Compared with Version 5
SReading and writing data in the FETCH/WRITE mode
The services FETCH and WRITE are supported for direct access to sy-
stem memory areas on the SIMATIC S7 PLC via ISO transport and and
ISO-on-TCP connections. The SIMATIC S7-300 with the CP 343-1 is
always the server (passive connection establishment), while the fetch or
write access (client functionality with active connection establishment)
originates from a SIMATIC S5 PLC or other device
Requirements –General Operation
The following table shows the S7–300 CPUs with which the CP 343–1 can be
operated with this range of functions:
Table 2
CPU MLFB–Number
CPU 312 IFM 6ES7 312–5AC02–0AB0
CPU 312 (T) 6ES7 312–5AC82–0AB0
CPU 313 6ES7 313–1AD03–0AB0
CPU 314 6ES7 314–1AE04–0AB0
CPU 314 (T) 6ES7 314–1AE84–0AB0
CPU 314 IFM 6ES7 314–5AE03–0AB0
CPU 314 IFM (T) 6ES7 314–5AE83–0AB0
CPU 315 6ES7 315–1AF03–0AB0
CPU 315–2 DP 6ES7 315–2AF03–0AB0
CPU 315–2 DP (T) 6ES7 315–2AF83–0AB0
CPU 316–2 DP 6ES7 316–2AG00–0AB0
CPU 318–26ES7 318–2AJ00–0AB0
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
6Productinformation CP 343–1
C79000–Z8964–C038–05
Table 2
CPU MLFB–Number
CPU 614 6ES7 614–1AH03–0AB3
CPU 614–Z6ES7 614–1AH03–0AB3–Z
The table lists the CPUs approved at the time of printing this product informa-
tion bulletin. S7–300 CPUs approved later and not listed in the table also
support the range of functions described here.
All versions of the SINUMERIK CPUs 840D and 810D are supported.
Requirements –ISO Transport Connections
The following conditions must be taken into account on ISO transport con-
nections depending on the length of the data to be transferred:
Table 3
Functionality Requirement
Transfer of
data fields <= 240 bytes The blocks AG_SEND FC5 and AG_RECV FC6 or as an
alternative the blocks AG_LSEND FC50 and AG_ LRECV
FC60 are required.
Transfer of data
fields > 240 bytes Note the two requirments below:
SYou require the blocks AG_LSEND FC50 and
AG_LRECV FC60. These blocks are shipped with
NCM V 4.02 with service pack 1.
The blocks are shipped as standard components of
newer versions of NCM.
SConfiguration:
When configuring the CP 343–1 with Hardware
Configuration in STEP 7, select the option “Data length
> 240 bytes”under the “Options”tab.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
english
7
Productinformation CP 343–1
C79000–Z8964–C038–05
1.2 Performance Data
1.2.1 Characteristics of S7 Communication
The functions and characteristics of S7 communication are described in /8/
and /11/.
1.2.2 Characteristics of ISO Transport Connections
The following information is important for operating ISO transport connections
(SEND/RECEIVE interface):
Table 4
Characteristic Explanation / Values
Total number of connections on Industrial
Ethernet 32 maximum
Number of connections for S7 communication
on Industrial Ethernet The actual value depends on the CPU type
being used. Please refer to /1/ for the values
for your CPU.
Number of ISO transport connections 16 maximum
Maximum data length for AG_SEND and
AG_RECV blocks AG_SEND and AG_RECV allow the transfer
of data fields of between 1 and 240 bytes.
Maximum data length for AG_LSEND and
AG_LRECV blocks AG_LSEND and AG_LRECV are shipped for
the CP 343–1 from version 5 or higher
(firmware V3.00) and permit the transfer of
data fields of between 1 and 8192 bytes (for
more detailed information, see Table 3 ).
Reaction Times of ISO Transport Connections
The calculation of the reaction times with ISO transport connections is deter-
mined by the run time of the function blocks required on the S7-300 CPU
(AG-SEND, AG–RECV).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Hardware de computadora de Siemens
Siemens
Siemens LMV50 series Manual de usuario
Siemens
Siemens SIMATIC NET CP 5614 A2 Manual de usuario
Siemens
Siemens 928B Guía del usuario
Siemens
Siemens Simatic S7-300 Manual de instrucciones
Siemens
Siemens XMS-SP Manual de usuario
Siemens
Siemens SIMATIC NET CP 1411 Manual de usuario
Siemens
Siemens SIMOTION TB30 Manual de usuario
Siemens
Siemens SINUMERIK 808D Manual de usuario
Siemens
Siemens SIMATIC NET CP 443-5 Extended Manual de usuario
Siemens
Siemens SIMATIC S7-1200 CP 1243-8 IRC Manual de usuario
Siemens
Siemens SIMATIC NET CP 5603 Manual de usuario
Siemens
Siemens Simatic S7-1500 Manual de usuario
Siemens
Siemens CP 443-1 Manual de usuario
Siemens
Siemens Fujitsu D1159 Manual de usuario
Siemens
Siemens Simatic S7-300 CP 341 Manual de usuario
Siemens
Siemens SIMATIC S7 400 Guía del usuario
Siemens
Siemens SIMEAS-Hub 7KE6000-8AD /CC Manual de usuario
Siemens
Siemens SIMATIC CP 340 Manual de usuario
Siemens
Siemens SENTRON PROFIBUS DPV1 Series Manual de usuario
Siemens
Siemens SIMATIC NET CP 243-1 IT Manual de usuario
Manuales populares de Hardware de computadora de otras marcas
EMC2
EMC2 VNX Series Manual del propietario
Panasonic
Panasonic DV0PM20105 Manual de usuario
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manual de usuario
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manual de usuario
Raidon
Raidon iT2300 Manual de usuario
National Instruments
National Instruments PXI-8186 Manual de usuario
