Sennheiser MKH 80 Manual de usuario

Microphones 4

RF condenser microphone (variable pattern)

MKH 80-P48

Publ.: 30.10.2003

Cat. No. 03004

Description

Features

- Wide, flat frequency response

- Extended low frequency response

- Exceptionally low inherent self-noise

- Wide dynamic range

- Switchable pre-attenuation, switchable roll-off filter

and switchable treble emphasis

- Transformerless and fully floating balanced output

- LED for on-axis alignment

- Haematite-anodised light metal body

Technical data

Pick-up pattern omni-

directional...cardioid...fig.

eight

Sensitivity in free field, no

load (1kHz) 40 mV/Pa +- 1 dB

Nominal impedance 150 Ohm

Min. terminating

impedance 1000 Ohm

Equivalent noise level 10 dB

Equivalent noise level

weighted as per CCIR

468-3

20 dB

Power supply Phantom 48 +- 4 V

Current consumption 3 mA

Dimensions d 26,7 x 176 mm

Weight 135 g

Profile

Studio microphone with 5 switchable pick-up patterns

(omni-directional, wide cardioid, cardioid,

super-cardioid, figure-of-eight), switchable

The MKH 80 is a variable pattern condenser microphone with five

switchable pick-up patterns. It is a superior microphone for any

recording application, offering high clarity and the absolute minimum

colouration. It is visually unobtrusive due to its compact design.

Delivery includes

1 MKH 80 P 48, 1 MZS 80 shock mount,

1 MZW 80 windshield

Recommended Accessories

Battery power supply unit MZA 14 P 48 U Cat. No.02960

Foam windshield MZW 80-ANT Cat. No.03780

Shock mount MZS 80 Cat. No.03685

Popshield MZP 40 Cat. No.03132

Microphones 4

RF condenser microphone (variable pattern)

MKH 80-P48

Publ.: 30.10.2003

Cat. No. 03004

Description

pre-attenuation, switchable roll-off filter and

switchable treble emphasis. Frequency response 30 -

20,000 Hz, sensitivity (free field, no load) 40 mV/Pa ±

1 dB at 1 kHz, nominal impedance 150 Ohm, min.

terminating impedance 1 kOhm, equivalent noise

level A-weighted 10 dB, CCIR-weighted 20 dB, max.

sound pressure level 136 (142) dB at 1 kHz, phantom

powering

48 ± 4 V, supply current 3 mA, dimensions Ø 26.7 x

176 mm, weight 135 g. Values in parentheses with

attenuator switched on (6/12 dB).

The MKH 80 is a variable pattern condenser microphone with five

switchable pick-up patterns. It is a superior microphone for any

recording application, offering high clarity and the absolute minimum

colouration. It is visually unobtrusive due to its compact design.

Delivery includes

1 MKH 80 P 48, 1 MZS 80 shock mount,

1 MZW 80 windshield

Recommended Accessories

Battery power supply unit MZA 14 P 48 U Cat. No.02960

Foam windshield MZW 80-ANT Cat. No.03780

Shock mount MZS 80 Cat. No.03685

Popshield MZP 40 Cat. No.03132
