SeeMeCNC Artemis Manual de usuario
SeeMeCNC Guides
Configuring Artemis
Configuring your Artemis printer. Connecting it to your network and getting everything dialed in for
successful printing.
Written By: SeeMeCNC
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 1 of 11
Step 1 — Close Other APPs
Close other applications that may
use the USB com port.
This printer is NOT designed to run
from the USB port. Only connect the
USB cable during setup of the
printer.
The printer is designed to run from
either (a) browser window over your
intranet or (b) by addition of
touchscreen with SD card reader
Close Cura, Mattercontrol, or other
slicers you may have open.
Close any non-3D related programs,
like Arduino or other programs that
may use the USB com port.
Step 2 — STOP! READ THIS STEP
If you purchased a fully assembled printer, an RTP (ready to print) model, DO NOT install or
update new firmware. Your new printer is ready to use. Follow steps to configure the WiFi
connection, then proceed to the last step of this guide to get started with the slicing software.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 2 of 11
Step 3 — Download Duet Driver Files
If you are running windows, click
here to download the Duet Wifi
Drivers. If you are running Mac or
Linux, you won't need them - skip
this step. Unzip the file and save the
drivers somewhere you'll be able to
find them. On windows 10, just
double click the "duet.inf" file and in
will install the driver. On windows 7,
you'll need to find the duet in Device
Manager and click update driver.
If you don't already have a program
installed to send commands to a 3D
printer, we recommend YAT
(Download here:
https://sourceforge.net/projects/y-a-
ter...). Once it's downloaded you
shouldn't need to change any
settings, just connect to the printer.
If you are using Simplify 3D,
Pronterface, or MatterControl to
connect to the printer, make sure it's
not converting all your text to
uppercase when you're setting up
your wifi in the next step.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 3 of 11
Step 4 — WiFi Setup - MAC
If you are not using a MAC, proceed
to the next step.
Mac OSX Users: Open Applications
> Utilities > Terminal .
Run ls /dev/tty.*
Copy the result that has USB in
the name. For example;
/dev/tty.usbmodem1411
Run screen
/dev/tty.usbmodem1411 115200.
Replace "usbmodem1411" with
the result you received. You
should see a blank screen. Hit
enter and you should see OK
returned. You are connected
successfully.
If you get an error, Sorry, could
not find a PTY. unplug the USB,
plug it back in and try again.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 4 of 11
Step 5 — Wifi Setup - Windows
Plug the micro USB cable into the USB slot on the (top) left side of your printer.
Connect to the printer with YAT, S3D, MatterControl, or carrier pigeon. Note that you'll need to set
the baud rate to 115200 in order to connect. Then send the following commands:
M552 S0
M587 S"yourssid" P"yourpass"
M552 S1
After sending M552 S1 , you should see a confirmation, and the IP address of your printer. Write
the IP address down, you'll use it in the next steps
Make sure your printer is close to your Wifi Router. If you a getting a lot of AJAX disconnected
errors, it's probably because the printer can't talk to your wifi reliably. Keep the distance between
them to a minimum.
The SD card can become partially unseated in shipping. It is highly recommended to remove it
(push it in until you hear the click, then it'll come out) and put it back in (push until you hear the
click) before you get too far into the setup.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 5 of 11
Step 6 — Initial Setup
Check that your FSR's are working properly. You should see a blue light through the slots in the
side of the base with the power cord. Push down on the bed in a few different places and make
sure the lights flash/blink - you shouldn't need to push very hard. If they don't blink, contact
support.
Open a web browser and download the newest config files here:
https://github.com/seemecnc/Artemis
Open a new tab and enter the IP Address of your printer. When the page loads, click on "Settings"
in the lower left of the screen. Click on the "Upload Files" button, and upload the config.zip file that
you just downloaded.
Once it's uploaded, you will be prompted to reboot the Duet. Click yes. After about 10 seconds,
click the Refresh button on your browser and your printer will be running with the new config files.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 6 of 11
Step 7 — Calibrating your printer
We have setup a custom macro to
take care of all the heavy lifting for
your first calibration. On the
"Machine Control" tab, you can click
"First Probe" under "User-Defined
Macros" to do your first calibration.
The macro will do an initial
calibration that starts extra high off
the bed to account for slight
variances in build height. Once it's
completed, it will do a second
calibration, double checking each
height reading, and save the final
results to your SD card. Don't worry,
future calibrations go much faster
than the first one.
Test your calibration by putting a
sheet of paper on the bed and
running: "G0 Z0" in the gcode
console. Your nozzle should just
touch and pinch the paper so it's
hard to move. If it's too loose, run
the following GCode: "G31 P500 X0
Y0 Z-0.25", then run "G32" to
recalibrate, then "M500" To save all
your current calibrations and
settings.
If it's too tight, you want to try "G31
P500 X0 Y0 Z-0.35", then run "G32".
If it's still too tight, make the number
after Z a larger negative number. If
it's still too loose, make it a smaller
negative number.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 7 of 11
After your initial calibration, you can
calibrate by clicking the "Auto Delta
Calibration" button, or by sending
"G32" in the gcode console. We
highly recommend probing with the
bed cold. FSR's get finicky with
temperature increases and the
thermal expansion of the bed is so
minimal as to be non-existent.
You might see a line or two that
says the Height Error Difference was
above the maximum tolerance. Don't
worry about them unless you see a
lot of them.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 8 of 11
Step 8 — Loading Filament
You can load filament by heating the hot end up to 220 degrees and manually feeding the filament
in through the EZR and boden tube, or by using the "Filament Load" macro
If your printer didn't come with the macro, you can find the gcode with our Artemis setup files on
github, and setup the macro on your printer .
To use the load filament macro, hold in the red button on the EZR extruder and press the filament
in until it is just peeking out the side with the boden tube. Then click "Filament Load" under User-
Defined Macros, and click OK.
Click here for the guide on creating macros.
Click here to go to the list of SeeMeCNC Macros.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 9 of 11
Step 9 — Printing!
Upload and print your first gcode
file. You can do this two different
ways. You can either click "Upload &
Print" at the top of the page, or click
on G-Code files at the side of the
page, then "Upload G-Code File(s)",
then select your file from the list.
If you'd like a pre-sliced file for your
first print, FIRST PRINT
NOTE: On the first heatup of your
bed, you may notice a small amount
of smoke from the bed / base of the
printer. This is nothing to worry
about, this is excess residue on the
silicone bed from the manufacturing
process. We cycle every bed at
SeeMeCNC before shipping to
reduce / eliminate this issue, but
some are more determined than
others.
Configuring Artemis
© 2018 seemecnc.dozuki.com/ Page 10 of 11
