Security Camera King IPOB-ELS2IR12XA-EP Manual de usuario
i
Network Camera Web3.0 Operation Manual
Version 1.0.0E
ii
Table of Contents
1Network Connection...................................................................................................... 1
2Main Interface Introduction............................................................................................ 2
2.1 Log in................................................................................................................ 2
2.2 Live Interface .................................................................................................... 6
2.3 Encode Setup ................................................................................................... 6
2.4 System Menu.................................................................................................... 7
2.5 Video Window Function Option......................................................................... 7
2.6 Video Window Setup......................................................................................... 8
2.6.1 Hide Image Control..................................................................................... 8
2.6.2 Original size................................................................................................ 9
2.6.3 Full screen.................................................................................................. 9
2.6.4 Width and height ratio................................................................................. 9
2.6.5 Fluency Adjustment.................................................................................... 9
2.6.6 Zoom and Focus......................................................................................... 9
2.6.7 Image control............................................................................................ 10
3PTZ Control................................................................................................................. 12
4Playback...................................................................................................................... 15
4.1 Playback Interface .......................................................................................... 15
4.2 Function of Play.............................................................................................. 15
4.3 Date................................................................................................................ 16
4.4 File List ........................................................................................................... 16
4.5 Progress Bar................................................................................................... 18
5Setup........................................................................................................................... 19
5.1 Camera........................................................................................................... 19
5.1.1 Conditions................................................................................................. 19
5.1.2 Video ........................................................................................................ 25
5.1.3 Audio ........................................................................................................ 30
5.2 Network........................................................................................................... 30
5.2.1 TCP/IP...................................................................................................... 30
5.2.2 Connection ............................................................................................... 32
5.2.3 PPPoE...................................................................................................... 34
5.2.4 DDNS ....................................................................................................... 34
5.2.5 IP filter ...................................................................................................... 36
5.2.6 SMTP （e-mail)........................................................................................ 37
5.2.7 UPnP........................................................................................................ 38
5.2.8 SNMP ....................................................................................................... 39
5.2.9 Bonjour ..................................................................................................... 41
iii
5.2.10 Multicast ................................................................................................... 42
5.2.11 WIFI.......................................................................................................... 43
5.2.12 802.1x....................................................................................................... 46
5.2.13 QoS .......................................................................................................... 47
5.2.14 3G............................................................................................................. 48
5.2.14.1 Dialing Setting.................................................................................... 49
5.2.14.2 Mobile Phone ..................................................................................... 50
5.3 Event............................................................................................................... 51
5.3.1 Video detect.............................................................................................. 51
5.3.2 Alarm........................................................................................................ 56
5.3.3 Abnormity ................................................................................................. 58
5.4 Storage........................................................................................................... 61
5.4.1 Record Schedule and Snapshot Schedule ............................................... 61
5.4.2 Destination................................................................................................ 62
5.4.3 Record control .......................................................................................... 63
5.5 System............................................................................................................ 64
5.5.1 General..................................................................................................... 64
5.5.2 Account..................................................................................................... 66
5.5.3 PTZ........................................................................................................... 70
5.5.4 Default...................................................................................................... 71
5.5.5 Import/Export............................................................................................ 72
5.5.6 Auto Maintenance..................................................................................... 72
5.5.7 Upgrade.................................................................................................... 73
5.6 Information...................................................................................................... 73
5.6.1 Version ..................................................................................................... 73
5.6.2 Log............................................................................................................ 74
5.6.3 Online User............................................................................................... 75
6Alarm........................................................................................................................... 76
7Log out ........................................................................................................................ 77
iv
Important
The following functions are for reference only. Some series products may not
support all the functions listed below.
1
1 Network Connection
These series network camera products support the Web access and management via PC.
Web includes several modules: monitor channel preview, PTZ control, system configuration, alarm and
etc.
Please follow the steps listed below for network connection.
Make sure the network camera has connected to the network properly.
Network camera IP address and PC IP address shall be in the same network segment. If there is
router, please set the corresponding gateway and subnet mask.
Use order ping ***.***.***.***(* network camera address) to check connection is OK or not.
2
2 Main Interface Introduction
2.1 Log in
Open IE and input network camera address in the address bar.
For example, if your camera IP is 192.168.1.108, then please input http:// 192.168.1.108 in IE address
bar. See Figure 2-1.
Figure 2-1
The login interface is shown as below. See Figure 2-2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here
3
Figure 2-2
If it is your first time to login in, you may see the interface shown as in Figure 2-3.
Figure 2-3
4
Click on “Please click here to download and install the plug-in”. The system pops up warning information
to ask you whether run or save this plug-in. See Figure 2-4.
Figure 2-4
You must either run or save the file to local and install it. Follow the following steps. Click on run, you
will see Figure 2-5 and Figure 2-6.
5
Figure 2-5
Figure 2-6
6
When plug-in installation completes, the installation page closes automatically. The web-end will
refresh automatically, and then you can view video captured by the camera.
2.2 Live Interface
After you logged in, you can see the live monitor window. See Figure 2-7
Figure 2-7
There are four sections:
Section 1: Encode setup bar
Section 2: System menu
Section 3: Window function option bar
Section 4: Window adjust bar
2.3 Encode Setup
The encode setup interface is shown as in Figure 2-8.
2
3
1
4
