Security Camera King IPOB-EL2IRE Manual de usuario

IPOB-EL2IRE User’s Manual

Version 1.2.5

Welcome

Thank you for purchasing our network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction)

Please note: Do not connect two power supplying sources to the device at the same time; it may

result in device damage! The product must be grounded to reduce the risk of electronic shock.

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

iii

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

Dome enclosure is the optical component, do not touch the enclosure when you are installing the

device or clean the enclosure when you are doing maintenance work. Please use professional optical

clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result

in poor IR effect of camera with IR function.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Network Camera Unit

Quick Start Guide

Installation Accessories Bag

Warranty Card and Certificate

Table of Contents

1General Introduction......................................................................................................1

1.1 Overview...........................................................................................................1

1.2 Features............................................................................................................1

1.3 Specifications....................................................................................................2

1.3.1 Performance...............................................................................................2

2Framework.....................................................................................................................9

2.1 Cable.................................................................................................................9

2.2 Framework and Dimension.............................................................................10

3Device Installation .......................................................................................................13

4Quick Configuration Tool.............................................................................................15

4.1 Overview.........................................................................................................15

4.2 Operation........................................................................................................15

5Web Operation ............................................................................................................17

5.1 Network Connection........................................................................................17

5.2 Login and Main Interface.................................................................................17

6FAQ.............................................................................................................................19

Appendix Toxic or Hazardous Materials or Elements ........................................................20

1General Introduction

1.1 Overview

This series network camera integrates the traditional camera and network video technology. It adopts

video data collection, transmission together. It can connect to the network directly without any auxiliary

device.

This series network camera uses standard H.264 video compression technology, which maximally

guarantees the video quality.

It supports the IR night vision function. In the night environments, the device can use the IR light to

highlight the object which is suitable for the surveillance function in the low illumination environments.

The built-in waterproof design conforms to the IP 66 level. It has the sound waterproof function

suitable for use in the outdoor environments.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its multiple functions and various uses, this series

network camera is widely used in many environments such as home, office, bank, road monitor and

etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

Storage

Function

Support central server backup function in accordance with your configuration

and setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end

PC.

Support network storage function such as FTP.

Data

Transmission

Support data transmission via Ethernet.

Network

Monitor

Network camera supports one-channel video data transmit to network

terminal and then decode. Delay is within 270ms (network bandwidth support

needed)

Max supports 20 connections.

Adopt the following video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web or client-end.

Support abundant network protocols.

Power

External power adapter DC12V.

Support PoE.

Warning！

Do not connect these two power supplying sources to the device at the

same time; it may result in device damage!

Assistant

Function

Log function

Support system resource information and running status real-time display.

Day/Night mode auto switch.(with ICR switch)

Support picture parameter setup such as electronic shutter and gain setup.

Backlight compensation: screen auto split to realize backlight compensation

to adjust the bright.

Support digital WDR.

Support video watermark function to avoid vicious video modification.

Support dual bit streams, ACF.

1.3 Specifications

1.3.1 Performance

Please refer to the following sheet for network camera performance specification.

Model

Parameter

System

Main Processor

High performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/4-inch CMOS

Pixel

1280(H) *720(V)

Day/Night Mode

Support day/night mode switch.

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Exposure Mode

Auto/Manual

It ranges from 1/3 to 1/10000.

Video

Compression

Standard

H.264/H.264B/MJPEG

Video Frame

Rate

PAL:

Main stream(1280*720@25fps)

extra stream(704*576@25fps),

NTSC:

Main stream(1280*720@30fps)

extra stream(704*480@30fps),

Video Bit Rate

H.264H: 16Kbps-8192Kbps;

MJPEG: adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, tampering.

Lens

3.6mm, 6mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100;

area threshold ranges from 0 to 100.

Activation event: video storage, image snapshot, log, email function

and etc.

Recor

d and

Backu

Storage

Management

Support display network storage status

Network

Wire Network

1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network Protocol

Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,

SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,

SNMP.

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc.

IR light

IR distance 20~30m

General Parameter

Power

DC12V power, PoE.

DC12V

Power

Consumption

4.5W MAX

3.6W MAX

Working

Temperature

-30℃~+60℃

Working

Humidify

≤95%

Dimensions(mm)

70*66*155

Weight

620g

420g

Installation

Installation with the bracket.

Model

Parameter

IPOB-EL2IRE

System

Main Processor

High performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3-inch CMOS

Pixel

2048（H）*1536（V）

1280（H）*960（V）

Day/Night Mode

Support day/night mode switch.

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Electronic

Shutter

Manual/Auto/Low noise/Low motion blur

It ranges from 1/3 to 1/100000.

Video

Compression

Standard

H.264/H.264B/H.264H/MJPEG

Video Frame

Rate

PAL:

Main stream(1920*1080@25fps)

extra stream(704*576@25fps),

PAL:

Main stream(1280*960@25fps)

extra stream(704*576@25fps),

NTSC:

Main stream(1920*1080@30fps)

NTSC:

Main stream(1280*960@30fps)

extra stream(704*480@30fps),

Video Bit Rate

H.264H: 16Kbps-8192Kbps;

MJPEG: adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, tampering.

Lens

3.6mm, 6mm, 8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100;

area threshold ranges from 0 to 100.

Activation event: video storage, image snapshot, log, email function

and etc.

Record

and

Backup

Record Priority

Manual > video detect > schedule

Storage

Management

Support NAS storage

Network

Wire Network

1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network Protocol

HTTP，TCP，ARP，RTSP，RTP，UDP，RTCP，SMTP，FTP，

DHCP，DNS，DDNS，PPPOE，IPv4/v6，QoS，UPnP，NTP，

HTTPS，Bonjour

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc.

Platform

Interface

Standard

Support ONVIF

IR light

IR distance 30m

General Parameter

Power

DC12V power, PoE.

Note: 05 series does not support PoE.

Power

Consumption

DC 12V 6W MAX

Working

Temperature

-30℃~+60℃

Working

Humidify

≤95%

Dimensions(mm)

70*66*155

Weight

(excluding box)

620g

420g

620g

420g

Installation

Installation with the bracket.

Model

Parameter

Syste

Main Processor

High performance DSP

Embedded LINUX

System

Support real-time network, local record, and remote operation at the

Resources

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3-inch CMOS

Pixel

1280(H)*960(V)

2048(H)*1536(V)

Day/night

Support day/night mode switch

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Exposure Mode

Manual/Auto/Low noise/Low motion blur

It ranges from 1/3 to 1/100000.

Video

Compression

Standard

H.264/H.264H/MJPEG

Video Frame

Rate

PAL:

Main stream (1280*960@25fps)

extra stream 1 ( 704*576@25fps)

extra stream 2 ( 1280*720@8fps)

PAL:

Main stream (2048*1536@20fps)

extra stream 1 (704*576@20fps)

extra stream 2 (1280*720@1fps),

Main stream (1920*1080@25fps)

extra stream 1 ( 704*576@25fps)

extra stream 2(1280*720@11fps),

NTSC:

Main stream (1280*960@30fps)

extra stream 1 ( 704*480@30fps)

extra stream 2 ( 1280*720@1fps)

NTSC:

Main stream (2048*1536@20fps)

extra stream 1 (704*480@20fps)

extra stream 2 (1280*720@1fps),

Main stream (1920*1080@30fps)

extra stream 1 ( 704*480@30fps)

extra stream 2(1280*720@1fps),

Note:

Extra stream 2’s actual frame depends on device max capacity set

which can be adjusted within its range.

Video Bit Rate

H.264H: 40Kbps-8192Kbps

MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, tampering, overlay.

Lens

3.6mm, 6mm, 8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100;

area threshold ranges from 0 to 100.

Activation event: video storage, image snapshot, log, email function

and etc.

Rec

ord

Record Priority

Manual >Video detect>Schedule

Tabla de contenidos

Otros manuales de Cámara de seguridad de Security Camera King

Security Camera King

Security Camera King DS-2CD63C5G0-IVS Manual de usuario

Security Camera King

Security Camera King TVIPTZ-TP2IR18XME Manual de usuario

Security Camera King

Security Camera King QUADBRID HDVD-SB2IRZW Manual de usuario

Security Camera King

Security Camera King TVIOD-PR5EXIR28 Manual de usuario

Security Camera King

Security Camera King CVIPTZ-EL1MPL20X Manual de usuario

Security Camera King

Security Camera King IPOD-EL1MPIR50-E Manual de usuario

Security Camera King

Security Camera King CVIOB-EL4IRZD Manual de usuario

Security Camera King

Security Camera King PRIME TVIOB-PR2IR Manual de usuario

Security Camera King

Security Camera King OD-LX700IR50-W Manual de usuario

Security Camera King

Security Camera King IPVD-EL3MPIR Series Manual de usuario

Security Camera King

Security Camera King TVIOB-PR2EXIRZ Manual de usuario

Security Camera King

Security Camera King IPVD-EL3MPIR100 Manual de usuario

Security Camera King

Security Camera King TVIVD-PR5EXIR28 Manual de usuario

Security Camera King

Security Camera King PRIME Series Manual de usuario

Security Camera King

Security Camera King PRIME Series Manual de usuario

Security Camera King

Security Camera King IPPTZ-EL1MPIR250L20X Manual de usuario

Security Camera King

Security Camera King IPOB-EL1MPIR50-E Manual de usuario

Security Camera King

Security Camera King IPOB-ELS2IR12XA-EP Manual de usuario

Security Camera King

Security Camera King IPVD-PR12FA Manual de usuario

Security Camera King

Security Camera King IPOD-EL2IRE Manual de usuario

Security Camera King

Security Camera King TVIOD-PR2EXIR28 Manual de usuario

Security Camera King

Security Camera King TVIOB-PR2EXIR Manual de usuario

Security Camera King

Security Camera King OD-CM600IR50-B Series Manual de usuario

Security Camera King

Security Camera King EL2MPIR250L30X Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
