Securam V8 Manual técnico
SECURAM
Finger Vein Door Lock V8
Operation Instruction
Standalone version/Wireless version
Front Panel Function
SECURAM logo plate
Finger vein reader
Lever handle
Emergency key hole
Slide cover
Push up the slide cover
to verify finger. Turn the handle
Mobile wireless
connection indicator
Internet wireless
connection indicator
Low battery indicator
Set language
Reset to factory default
Restrict visitor
Authorize your phone
Set volume
Allow visitor
Cancel operation
Operation successful
Door bell
Setting
Add user
Delete user
Armor system
Battery case screw
Loosen the screw counterclockwise
and then pull out the battery case
and the slide cover returns to
the closed position automatically
Back Panel Function
Back panel slide cover
Lever handle
Thumbturn
Turn to different positions
to enable different functions
Lockout
Disable unlocking
Cancel Lockout
Enable unlocking
Enable away mode
Turn the handle, and lock
can't open. Prevent unlocking
from peephole
1. Loosen the battery case screw counterclockwise
with a coin or a slotted screwdriver, pull out the
battery case, and load 6 1.5V LR6 batteries.
2. Insert the battery case into the front panel, and
tighten the screw.
● Battery must be LR6 alkaline. Otherwise, it may
cause lock malfunction.
Change Battery
Battery loading direction
1.5V LR6 battery
Battery case
Battery case screw
Operation Instruction
Code Masking (Prevent others from viewing your code)：Add
any random digit before or after the correct 6-digit code (at
most 3 digits). The lock will open only if the 6 consecutive digits
of the valid code are entered. Press “√” button to confirm when
the code is less than 9 digits.
1) First-Time Use：Enter the default admin code 123456→ Press
“√” button→Turn the handle to open the door.
2) Add First Owner: Press button→Enter 123456→Press
“√” button→Push up SECURAM logo slide cover→Enroll first
finger 3 times →Enroll second finger 3 times→Enter code twice.
Note: 1. Code can't be 123456.
2. Code can't start with 00. If code is 008888, the voice
prompt will say,“invalid code”
3. Code has to be set for first owner. Otherwise, adding
first owner fails.
3）Unlocking Options:
●Unlock with finger vein：Push up SECURAM logo slide cover,
and place finger on reader following the voice prompt.
88 123456 9
Correct code
Masking code
.
To properly place finger：Lay the finger flat right on the reader.
(Note: Finger nail should not exceed 5mm in length. Otherwise,
it will affect authentication).
● Unlock with code：Enter a valid 6 digit code, and press “√”
button.
To mask your code: Add any random digit before or after the
correct 6-digit code (at most 3 digits). The lock will open only if
the 6 consecutive digits of the valid code are entered. Press “√”
button to confirm when the code is less than 9 digits.
4) Add User：
Add Owner：Press →Verify owner 1's or owner 2's finger
or code→Place first finger 3 times→Place second finger 3 times
→Enter code twice.
Add Visitor: Press →Verify owner 1's or owner 2's finger
or code→Press 0→Place first finger 3 times→Place second
finger 3 times.
Note: 1. Code can't be 123456.
2. After owner finger is added successfully, press “←”
button to cancel code setting according to the voice prompt.
5）Delete User：
Delete Owner: Press →Verify owner 1's or owner 2's finger
or code→Choose the owner ID No. to be deleted→Press the “√”
button to confirm.
Delete Visitor: Press →Verify owner 1's or owner 2's finger
or code→Press 0→Choose the Visitor ID No. to be deleted→
Press the “√” button to confirm.
1) Allow Visitor: Press → Press 0 →Verify owner 1's or
owner 2's finger or code.
2）Restrict Visitor: Press → Press 7 →Verify owner 1's or
owner 2's finger or code.
3）Set Language: Press → Press 3 →Verify owner 1's or
owner 2's finger or code→ Press 3→Press “√” button to
confirm.
4）Reset to Factory Default: Press → Press 5 →Verify
owner 1's or owner 2's finger or code→ Press “√” button twice.
5）Set Volume: Press →Press 9 →Verify owner 1's or
owner 2's finger or code→Press 9→Press “√” button to confirm.
User Rights：
1) Owner 1 and Owner 2 are administrators, and can add and
delete users and set up all parameters.
2) Owners 3-9 can unlock and set codes.
3) Visitors 1-6 can only unlock.
+ Number Button
Emergency Key
Press down the
handle to unlock
Insert the key and
rotate 120° clockwise
Press down the
handle to unlock
Rotate counterclockwise,
pull out the key and lock up
2. Mechanical key is only used to force lock it up
when the electronic part fails. Set the lock back to
the status that allows the electronic part to normally
unlock(as shown in illustration).
1. Unlock with key (as shown in illustration)
Press down the
handle to unlock
Press down the handle.
The handle is in idle status
Lock can't be unlocked.
Rotate 120° clockwise
①Insert the key and rotate
120°clockwise
③Then, continue to rotate with
greater force. A click sound will
be heard. Pull out the key
horizontally to lock it up.
④To unlock again, rotate
the key counterclockwise
by 2 turns to its normal
position. Lock can be
unlocked by the electronic
part (unlock with code or
finger).
②Then, the key can't be
rotated further. The lock can
normally open.
