Sartorius Combics 1 Manual de usuario

WCI5005-e03104

Service Manual

Sartorius Combics 1 | Combics 2

Models CIS1U | CIS2U | CISL1U | CISL2U

for Combics Indicators

and

Models CAPP.U-...-LU | CAPS.U-...-LU

for Combics Weighing Platforms

including Service Specifications

REF

Contents

Overview

04 Service Concept

04 General Information

05 When to Use Which Procedure

05 Combics Indicators

07 Overview of the Models

07 Auxiliary Service Tools and Equipment

08 Accompanying Literature

09 Operating Concept

09 Keys below the Display

10 Configuring the Combics

10 Purpose, Features

12 Function of the Keys when Configuring the Menu

12 Printing the Parameter Settings

13 Description of the Equipment

14 Function of the Service Keys and Switches

14 A. Menu Access Switch

14 B. SBI/BPI Key

15 Activating the BPI Mode

15 C. Boot Key

16 Activating the xBPI Protocol

17 Activating the Service Mode

19 Working in the Service Mode

19 Additional Menus in Service Mode

22 Menu Item 1-18:

Entering Calibration/Linearization Weights

22 1-18-1: External User-defined Calibration

Weight (Service Mode not Required)

23 1-18-2 1. Entering 1st Linearization Weight

24 Calibration/Adjustment Routines in Service Mode (General

Information)

25 Valid areas for Use

26 Zone “D”

27 Menu Line 1-9: Calibration/Adjustment Functions

28 1-9-1 External Calibration/Adjustment with Default

Weights

28 1-9-3 External Calibration/Adjustment with User-

defined Weights

30 1-9-5 Internal Linearization (Only for WP1 on COM1 or

UniCOM Ports)

30 1-9-7 External Linearization with User-defined Weights

33 1-9-8 Setting the Preload

34 1-9-9 Clearing the Preload

36 Adjustment without Weights

36 Menu Item 1-19:

Entering the Specifications of the Load Cell(s)

39 Menu Item 1-20: Entering the Geographical Latitude and

Altitude, or the Acceleration of Earth Gravity

40 Entering the Place of Adjustment with Subsequent

Adjustment (Example)

40 Menu Item 1-13: Zero at On

46 Configuring the A/D Converter of the Combics Indicator

(Service Mode)

46 Menu Item 11: A/D Converter Settings (Configuration:

Standard, Trade)

47 A/D Converter Configuration (General Information)

47 Notes on A/D Converter Configuration

48 Descriptions of the Individual Menu Items

49 Selecting the Weighing Range Structure

(Menu Item 11-3)

52 Menu Item 9-1: A/D Converter Configuration (Example:

Trade Configuration)

57 Menu Item 9-1: A/D Converter Configuration with Load

Cell(s) Connected (Example: Standard Configuration)

58 Loading the Standard Configuration

(if the Trade configuration is currently loaded)

62 Menu Item 1-19: Entering the Specifications of the Load

Cell(s)

64 Entering the Date of Service

65 Entering the Serial Number of the Combics Indicator

67 Entering the Model Designation of the Combics Indicator

68 Defining Transaction Numbers for Data Records (Weight

Values) which were stored in the Alibi Memory

69 Repairing the Combics Indicator

69 Replacing the Front Panel

70 Blank Display

70 Replacing the Power Cord

71 Replacing the Power PCB

72 Replacing the DC/DC Converter

73 Replacing the A/D Converter

73 Quick-test of the A/D Converter

74 Replacing the Digital PCB

75 Checking the IP67 Protection

75 Torque Values for Cable Glands and Vent Valve

76 Adjusting the Weighing Platform

76 Adjusting the Off-center Load

76 Procedure (Example Illustrated on the Left)

77 Diagram: Determining the Adjustment Resistance

78 Off-center Load Adjustment: 0-ohm Resistors (Example)

79 Setting the Overload Stops

79 1. Weighing Platforms with 1 Load Cell: Steel

80 2. Weighing Platforms with 1 Load Cell: Stainless Steel

81 3. Weighing Platforms with 4 Load Cells: Steel

82 4. Weighing Platforms with 4 Load Cells: Stainless Steel

83 Repairing the Weighing Platforms

83 Replacing the Connecting Cable

84 Replacing Load Cells

85 Torque Values

86 Pin Assignments in the Junction Box

87 Replacing the Load Cell Foot

87 Color Codes of the Wiring for Weighing Platforms, Models

CAPS../CAPS..

88 Error Codes

90 The Combics Weighing Platforms

91 Type Designation

91 Complete Combics scale

92 Complete Combics stainless steel scale

93 Service Specifications

93 CAPP/CAPS1U-.....-LU

94 CAPP/CAPS4U-.....-LU

Overview

Service Concept

Prerequisites for performing maintenance and repair work on Sartorius Combics

scales requires considerable experience with both indicators and weighing platforms.

In case of defects, repairs are performed on site. Generally, the equipment is not

replaced.

General Information

– Do not connect or disconnect cables to or from the equipment; always disconnect the

power cable from the wall socket (mains supply) first!

– To ensure safety, an isolating transformer must be installed between the indicator and

the power supply before performing work that entails opening the Combics indicator

housing.

On Combics scales, check and adjust as necessary:

(The procedure is the same as for all scale and weighing platform models.)

– Repeatability (standard deviation)

– Off-center load

– Span

– Linearity

When to Use Which Procedure

Combics Indicators

Activate the service mode to perform all adjustments See page 17

Important: All adjustments required after repair work (such as

replacement of the A/D converter or the load cells) are

performed using the terminal.

The Sartocas service software is not required for these adjustments.

Using this software, however, can make some adjustments

unnecessary (see „Use Sartocas software“ below).

Activate the BPI mode to load a modified data record in the controller

of the A/D converter See page 15

Activate the xBPI protocal to perform calibration and adjustment, if necessary See page 16

using Sartocas

Use Sartocas software - to reactivate the SBI protocol by selecting the „Close“

command on the Combics terminal (or by restoring

factory defaults (menu line 9-1)

- to program a new A/D converter PCB with data read from the old PCB

The necessary adjustments and customer specific menu settings

are not necessary

Use PPLoader software to update the application software in the terminal

Drift, display

Inf 02 when starting an

adjustment routine to check the A/D converter (quick-test) See page 73

or with the strain-gauge simulator,

check load cell(s) with the load cell tester

Display blank (dark) Disconnect the equipment from the power supply and

disconnect all cables and wires from the subassemblies,

connect equipment to power again, connect subassemblies

in turn and measure voltages See pages 70-72

No communication with

connected equipment Check connections and data transfer parameters;

start internal test program; if necessary, replace

Overview of the Models

The hardware configuration consists of either a Combics 1 or 2 indicator and

Sartorius weighing platform(s), or a Combics 1 or 2 indicator and weighing

platform(s) (strain-gauge load cells) from another manufacturer.

Important: Mechanical and electrical service or repair work on the Combics scale requires

considerable experience, and for this reason should be performed only by

Sartorius technicians trained at the factory. Any attempt to perform repair work

can result in damage to the equipment.

Auxiliary Service Tools and Equipment

In addition to standard tools, you will need the following special tools to work on

the Combics scale:

Qty. Designation Order No.

1 Laptop

1 Sartocas service software, version 1.46 or later 6740-33

1 Psion Server version 4.10 or later

1 PPLoader software

1 Isolating transformer

1 Flintec LCT-01 load cell tester

1 Socket wrench, double hexagon, 10-32 mm,

“ square driver

1 Adapter for Allen screws, SW 5 - 17, ” square driver

Qty. Designation Order No.

1 Torque wrench, 10-120 Nm 14x18, stainless steel

1 Torque wrench, 60-320 Nm 14x18, stainless steel

1 Set of open-ended wrenches with sockets

1 Set of sockets, up to 30 mm (hexagonal, stainless steel)

2 Transport belt (to move load plates or weighing

platforms; available from specialist suppliers)

2 Ring lugs (stainless steel; for moving the load plates or

weighing platforms; available from specialist suppliers)

1 Set open-ended wrenches (spanners) (up to 24 mm, stainless steel)

1 Threaded rod, M 16x120, for lifting the weighing platform

(available from specialist supplier)

1 Testing device for checking IP66/67 protection (not yet defined)

1 Set of screwdrivers (slotted)

1 Set of screwdrivers (Phillips head )

1 Set of Allen wrenches

1 Digital voltmeter (Beckman) 6738-62

1 Strain gauge simulator 6740-74

1 RS-232/485 converter 6740-68

Accompanying Literature

Operating instructions for “Combics 1 | 2 Indicators“ WCI6004-e03081 98648-012-27

Operating instructions for “Painted or Stainless Steel Weighing Platforms“ WCA6004-e03081 98648-012-26

Operating Concept

Keys below the Display

eOn/off

(On) Turns the Combics on and off.

(Standby) Combics switched off displays

“off“.

nToggle the display between

(Scale #) the weighing platforms

(Combics 2 only)

With two weighing platforms

connected, this key toggles

the display between the two

readouts.

(During weighing:

(Zero) Zero the scale

In the operating menu:

Closes active submenu and

returns to next higher menu

level and menu level (unless

the first menu level is already

shown)

During alphanumeric input

in the operating menu:

– Press briefly:

Activate character to the left

of the currently active

character

(with the first character

active: Exit the input mode

without saving changes)

– Press and hold (> 2 sec ):

Exit the input mode without

saving changes

)During weighing:

(Tare) – Press briefly:

Tare the scale

– Press and hold (> 2 sec ):

Calibration/adjustment

In the operating menu:

– Press briefly:

Display the next lower menu

level or

Select and store a menu item

– Press and hold (> 2 sec ):

Exit the operating menu

During alphanumeric input in the

operating menu:

– Press briefly:

Activate character/s to the

right of the currently active

character ®

(after the last character:

store input)

– Press and hold (> 2 sec ):

Store current input and display

the menu item

kDuring weighing:

(Function)Toggle (depends on operating

menu settings) between:

– first and second weight unit or

– gross and net or

– normal and 10-fold increased

display resolution

In the operating menu:

Show the next item on the

same menu level (scroll

through values in series)

Combics_1Folie_u.eps

Combics 1

During alphanumeric input

in the operating menu:

– Cursor in first position,

no characters entered yet:

Delete entire string and

enter “0“

– Change the displayed

character; scroll forward

(sequence: 0 through 9,

decimal point, minus

sign, Z through A, pace)

pDuring weighing:

(Print) – Press briefly:

– Press and hold (> 2 sec ):

Print GMP footer

In the operating menu:

Print the menu settings

starting from the current

position; or print Info data

During alphanumeric input in

the operating menu:

– Cursor in first position, no

characters entered yet:

Delete entire string and

enter a space

– Change the displayed

character; scroll

backwards ÿ (sequence:

Space, A through Z,

minus sign, decimal

point, 9 through 0)

Note:

The sequence in which keys are

pressed in the following

descriptions (“Key sequence:“)

are given as examples only.

Other sequences are possible.

Configuring the Combics

Purpose

You can configure the Combics to

meet individual requirements by

entering user data and setting

selected parameters in the operating

menu. The operating menu is a

combination of text levels and

numeric codes.

Features

The operating menu parameters are

divided into the following categories

1. Text-menu level

– Application programs »APPL«

– Key assignments k »fn-key«

– Device parameters »setup«

– Device information »InFo«

– Language for calibration and

adjustment printouts »LAnG«

Combics 2

Combics_2Folie_u.eps

Otros manuales para combics 1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Escala de Sartorius

Sartorius

Sartorius M-prove Series Manual de usuario

Sartorius

Sartorius PMA.Qualit Series Manual de usuario

Sartorius

Sartorius QC7CCE-S Manual de usuario

Sartorius

Sartorius TopMix2.Touch TM02-X Manual de usuario

Sartorius

Sartorius Entris BCE Series Manual de usuario

Sartorius

Sartorius Cubis MCA Series Manual de usuario

Sartorius

Sartorius Signum: Option Y2 SIWR Instrucciones originales

Sartorius

Sartorius EVO1S Manual de usuario

Sartorius

Sartorius PMA35001-Y Manual de usuario

Sartorius

Sartorius CPA 12001S Manual de usuario

Sartorius

Sartorius PMA.Vision VIS1Y EU Series Manual de usuario

Sartorius

Sartorius Master series Manual de usuario

Sartorius

Sartorius M-Power AZ214 Manual de usuario

Sartorius

Sartorius Genius Series Manual de usuario

Sartorius

Sartorius Cubis MCA Series Manual de usuario

Sartorius

Sartorius PMA 35D Manual de usuario

Sartorius

Sartorius Master series Manual de usuario

Sartorius

Sartorius Secura 224-1S Manual de usuario

Sartorius

Sartorius PMA.Evolution Manual de usuario

Sartorius

Sartorius MSA6.6S Manual de usuario

Sartorius

Sartorius PMA.Evolution Manual de usuario

Sartorius

Sartorius YDK 01 Manual de usuario

Sartorius

Sartorius SIWABBP Manual de usuario

Sartorius

Sartorius M-Power AZ214 Manual de usuario

Manuales populares de Escala de otras marcas

AWS

AWS ZEO-50 Manual de usuario

Gima

Gima Glass Body Fat Analyzer Manual de lista de piezas

Seca

Seca 374 Manual de usuario

TEC

TEC TEC SL59 SERIES Manual de usuario

Axis

Axis B/E Series Manual de usuario

Alecto

Alecto ACW-40 Manual de usuario

Rice Lake

Rice Lake MSI-4260 IS Manual de usuario

IKA

IKA RCT basic safety control Manual de usuario

ADE

ADE M20011 Manual de usuario

Duronic

Duronic KS3000 Manual de usuario

Digi

Digi SM-720 Manual de usuario

Cardinal

Cardinal CS Series Manual de usuario

Korona

Korona Kastella Manual de usuario

A&D

A&D FC-50Ki Manual de usuario

BDA

BDA CAMARGUE Manual de usuario

Tanita

Tanita HD-357 Manual de usuario

Leifheit

Leifheit 03173 Manual de usuario

Lumme

Lumme LU-1340 Manual de usuario

Sartorius combics 1 Manual de usuario

Manuales populares de Escala de otras marcas
