Ruijie RG-SAP825-SP Manual de instalación y funcionamiento

Ruijie RG-SAP825-SP Access Point

Hardware Installation and Reference Guide

Document Version: V1.1

Date: August 31, 2023

Networks

All rights are reserved in this document and this statement.

Any reproduction, excerption, backup, modification, transmission, translation or

commercial use of this document or any portion of this document, in any form or by any

means, without the prior written consent of Ruijie Networks is prohibited.

Trademark and are owned by Ruijie

Networks.

All other trademarks or registered trademarks mentioned in this document are owned by

their respective owners.

Disclaimer

The products, services, or features you purchase are subject to commercial contracts and

terms. Some or all of the products, services or features described in this document may

not be within the scope of your purchase or use. Unless otherwise agreed in the contract,

Ruijie Networks does not make any express or implied statement or guarantee for the

content of this document.

Due to product version upgrades or other reasons, the content of this document will be

updated from time to time. Ruijie Networks reserves the right to modify the content of

the document without any notice or prompt.

This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy

and will not shoulder any responsibility for losses and damages caused due to content

omissions, inaccuracies or errors.

Preface

Intended Audience

This document is intended for:

Network engineers

Technical support and servicing engineers

Network administrators

Technical Support

Ruijie Networks Website: https://www.ruijienetworks.com/

Technical Support Website: https://ruijienetworks.com/support

Case Portal: https://caseportal.ruijienetworks.com

Community: https://community.ruijienetworks.com

Technical Support Email: service_rj@ruijienetworks.com

Live Chat: https://www.ruijienetworks.com/rita

Conventions

1. Signs

The signs used in this document are described as follows:

Warning

An alert that calls attention to important rules and information that if not understood or

followed can result in data loss or equipment damage.

Caution

An alert that calls attention to essential information that if not understood or followed

can result in function failure or performance degradation.

Note

An alert that contains additional or supplementary information that if not understood or

followed will not lead to serious consequences.

Specification

An alert that contains a description of product or version support.

2. Note

The manual offers information (including model, port type and command line interface)

for indicative purpose only. In case of any discrepancy or inconsistency between the

manual and the actual version, the actual version prevails.

Contents

Preface.................................................................................................................................................. I

1Product Overview ............................................................................................................................ 5

1.1 Hardware Features...................................................................................................................5

1.2 Package Contents.....................................................................................................................7

1.3 Technical Specifications...........................................................................................................8

1.3.1 Dimensions and Weight...............................................................................................8

1.3.2 Radio Specifications .....................................................................................................8

1.3.3 Port Specifications......................................................................................................10

1.3.4 Power Supply and Consumption ..............................................................................11

1.3.5 Environment and Reliability ......................................................................................11

1.4 LED and Reset Button ............................................................................................................12

1.4.2 SFP Module .................................................................................................................13

2Preparing for Installation.............................................................................................................. 15

2.1 Safety Precautions..................................................................................................................15

2.1.1 General Safety Precautions .......................................................................................15

2.1.2 Handling Safety ..........................................................................................................15

2.1.3 Electric Safety..............................................................................................................16

2.1.4 Storage Security .........................................................................................................16

2.2 Installation Environment Requirements..............................................................................16

2.2.1 Bearing Requirements...............................................................................................17

2.2.2 Ventilation Requirements..........................................................................................17

2.2.3 Space Requirements ..................................................................................................17

2.2.4 Temperature/Humidity Requirements.....................................................................17

2.2.5 Cleanliness Requirements.........................................................................................18

2.2.6 Anti-interference Requirements ...............................................................................19

2.2.7 Lightning Protection Requirements .........................................................................19

2.2.8 Installation Site Requirements..................................................................................19

2.3 Installation Tools....................................................................................................................20

3Installing the Access Point............................................................................................................ 21

3.1 Installation Flowchart ............................................................................................................21

3.2 Before You Begin....................................................................................................................22

3.3 Precautions.............................................................................................................................23

3.4 Installing the Access Point.....................................................................................................23

3.4.1 Ceiling Mount .............................................................................................................23

3.4.2 Wall Mount..................................................................................................................25

3.4.3 Removing the Access Point .......................................................................................27

3.5 Installing Other Modules.......................................................................................................28

3.5.1 Installing the Securing Latch.....................................................................................28

3.5.2 Installing an SFP Module ...........................................................................................29

3.6 Connecting Cables .................................................................................................................30

iii

3.7 Bundling Cables......................................................................................................................31

3.7.1 Precautions.................................................................................................................31

3.7.2 Steps............................................................................................................................31

3.8 Checklist After Installation ....................................................................................................31

3.8.1 Checking Access Point ...............................................................................................31

3.8.2 Checking Cable Connection.......................................................................................31

3.8.3 Checking Power Supply .............................................................................................31

4Verifying Operating Status ........................................................................................................... 32

4.1 Setting up Configuration Environment................................................................................32

4.2 Powering on the Access Point...............................................................................................32

4.2.1 Checklist Before Power-on ........................................................................................32

4.2.2 Checklist After Power-on (Recommended) ..............................................................32

5Monitoring and Maintenance....................................................................................................... 33

5.1 Monitoring ..............................................................................................................................33

5.1.1 LED...............................................................................................................................33

5.1.2 CLI Commands ...........................................................................................................33

5.2 Remote Maintenance.............................................................................................................33

5.3 Hardware Maintenance .........................................................................................................33

6Common Troubleshooting............................................................................................................ 34

6.1 General Troubleshooting Flowchart.....................................................................................34

6.2 Common Faults ......................................................................................................................34

6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In..................34

6.2.2 LED Is Off for a Long Time.........................................................................................34

6.2.3 LED Is Solid Red..........................................................................................................35

6.2.4 LED Is Solid Green......................................................................................................35

6.2.5 LED Keeps Blinking Blue at an Interval of 0.2s (in Fit Mode)..................................35

6.2.6 LED Does Not Turn Solid Blue or Blinking Blue.......................................................35

6.2.7 Clients Can Not Find the Access Point......................................................................35

7Appendix ........................................................................................................................................ 36

7.1 Connectors and Media...........................................................................................................36

7.2 SFP Module and Specifications .............................................................................................38

7.3 Cabling ....................................................................................................................................39

7.4 DC Connector Specifications .................................................................................................44

Hardware Installation and Reference Guide Product Overview

1 Product Overview

The RG-SAP825-SP is a dual-radio Wi-Fi 6 access point (AP) launched by Ruijie for indoor

scenarios covering higher education, government, general education, finance, and

business. Compliant with the IEEE 802.11ax standard, the AP works in both 2.4 GHz and 5

GHz frequency bands. It delivers a combined peak data rate of 2.976 Gbps, with up to

574 Mbps in the 2.4 GHz band and 2.402 Gbps in the 5 GHz band. The RG-SAP825-SP

provides uplink optical and electrical ports, enabling flexible deployment in various

application scenarios

1.1 Hardware Features

The RG-SAP825-SP provides two radio frequency (RF) connectors, one 10/100/1000 BASE-

T Ethernet port, one 2.5GE SFP port, one RJ45 console port, and one DC power connector.

The AP supports PoE or DC power supply.

Figure 1-1Top View

Hardware Installation and Reference Guide Product Overview

Figure 1-2Front View

Table 1-1 LED

No.

LED

Description

System status LED

Indicates the system operating status.

Figure 1-3Side View
