AY-Q6x50 Family

Anti-Vandal MIFARE Contactless

Smart Card / PIN Readers

Installation and Programming Manual

Models:

AY-Q6250

AY-Q6350

AY-Q6250

AY-Q6350

This manual and the information contained herein are proprietary to ROSSLARE

ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’

(hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to

use the information.

No part of this manual may be re-produced or transmitted in any form or by any

means, electronic or mechanical, for any purpose, without the express written

permission of ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or

other intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN

THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS

AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND

TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION

MAY RESULT IN LEGAL PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third

party any license to these patents, trademarks, copyrights or other intellectual

property rights, except as expressly provided in any written agreement of

ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time,

without being obliged to announce such revisions or changes beforehand or

after the fact.

Table of Contents

AY-Q6x50 Family Installation and Programming Manual iii

Table of Contents

1. Introduction ................................................................8

1.1 Main Features......................................................................... 8

1.2 Supported RFID Transponders .................................................. 9

1.3 Box Content ........................................................................... 9

2. Technical Specifications............................................10

3. Installation ................................................................11

3.1 Mounting Instructions ........................................................... 11

3.2 Wiring Instructions ................................................................ 12

4. How to Use the Reader .............................................14

4.1 Normal Operation ................................................................. 14

4.2 Optical Back Tamper ............................................................. 14

5. Keypad Programming Instructions (AY-Q6350).......15

5.1 Transmit Mode ..................................................................... 15

5.2 LED Control .......................................................................... 15

5.3 Programming Menu .............................................................. 15

5.4Entering Programming Mode................................................. 17

5.5 Exiting Programming Mode ................................................... 17

5.6 Selecting Keypad Transmission Format ................................... 18

5.7 Keypad Transmission Format Option Number ......................... 19

5.7.1 Single Key, Wiegand 6-Bit (Rosslare Format) .................................19

5.7.2 Single Key, Wiegand 6-Bit, Nibble & Parities .................................20

5.7.3 Single Key, Wiegand 8-Bit, Nibbles Complemented ......................20

5.7.4 4 Keys Binary + Facility Code, Wiegand 26-Bit..............................20

5.7.5 1 to 5 Keys + Facility Code, Wiegand 26-Bit .................................21

Table of Contents

iv AY-Q6x50 Family Installation and Programming Manual

5.7.6 6 Keys BCD and Parity Bits, Wiegand 26-Bit..................................22

5.7.7 Single Key, 3x4 Matrix Keypad......................................................22

5.7.8 1 to 8 Keys BCD, Clock & Data .....................................................23

5.8 Selecting the Proximity Card Transmission Format................... 23

5.9 Card Transmission Format Option Number ............................. 24

5.9.1 Wiegand 26-Bit ............................................................................24

5.9.2 Clock and Data.............................................................................25

5.9.3 Wiegand Card + PIN Transmission Format ....................................25

5.9.4 Wiegand 26-Bit and Facility Code .................................................25

5.9.5 Wiegand 32-Bit ............................................................................26

5.9.6 Wiegand 32-Bit Reversed..............................................................26

5.9.7 Wiegand 34-Bit ............................................................................26

5.9.8 Wiegand 40-Bit and Checksum ....................................................27

5.10 Changing the Programming Code.......................................... 27

5.11 Changing the Facility Code.................................................... 28

5.12 Setting the Backlight ............................................................. 28

5.13 Return to Factory Default Settings.......................................... 29

5.14 Replacing a lost Programming Code....................................... 30

A. Limited Warranty ......................................................31

List of Figures

AY-Q6x50 Family Installation and Programming Manual v

List of Figures

Figure 1: Back Plate .........................................................................................11

Figure 2: Connecting the Reader to an Access Control System ........................13

List of Tables

vi AY-Q6x50 Family Installation and Programming Manual

List of Tables

Table 1: Wiring Colors .....................................................................................12

Table 2: Programming Menu ...........................................................................16

Table 3: Keypad Transmission Formats ............................................................19

Notice and Disclaimer

AY-Q6x50 Family Installation and Programming Manual vii

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and

efficient installation and usage of the system and/or product, and/or software

described herein.

BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM,THE INSTALLER AND THE

USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY

REQUIREMENTS AND OPERATING PROCEDURES.

The system must not be used for purposes other than those for which it

was designed.

The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the

purchase documents.

ROSSLARE exclusive warranty and liability is limited to the warranty and

liability statement provided in an appendix at the end of this document.

This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not all

functions described in this manual may be available in the specific system

and/or product configuration you purchased.

Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any

responsibility for consequent noncompliance, damage, or injury.

The text, images and graphics contained in the manual are for the purpose

of illustration and reference only.

All data contained herein subject to change without prior notice.

In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including,

without limitation, any and all damages from business interruption, loss of

profits or revenue, cost of capital or loss of use of any property or capital or

injury).

All graphics in this manual are for reference only, some deviation between

the image(s) and the actual product may occur.

All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and

understanding of the product and may differ from the actual PCB(s).

Introduction

8 AY-Q6x50 Family Installation and Programming Manual

1. Introduction

The AY-Q6250 and AYQ6350 series are metallic, anti-vandal MIFARE®

contactless smart card/PIN readers for indoor and outdoor use. The

units read the MIFARE card serial number (CSN) and transmit in

Wiegand, Clock & Data or Wiegand Card + PIN formats.

In addition, the AY-Q6350 comes with a backlit keypad that can be

programmed to output eight different data formats. The AY-Q6350

supports MIFARE cards that allow multiple card and keypad

transmission formats, thus providing a high level of compatibility and

connectivity with host controllers.

1.1 Main Features

Built-in 13.56 MHz ISO14443A-3 smart card reader

Programmable card transmission formats:

Wiegand 26-Bit (default)

Clock & Data

Wiegand Card + PIN

Wiegand 26-Bit with Facility code output

Wiegand 32-Bit

Wiegand 32-Bit reverse output

Wiegand 34-Bit

Programmable keypad transmission formats (AY-Q6350)

Built-in blue backlit keypad with programmable options (AY-

Q6350)

Built-in, optical back tamper

LED or buzzer control input (set by factory)

Tamper output

Programmable Facility code

Internal buzzer provides audible interface feedback

Introduction

AY-Q6x50 Family Installation and Programming Manual 9

Metallic anti-vandal – suitable for outdoor use

Two, tri-colored LED

1.2 Supported RFID Transponders

The AY-Q6250 and AY-Q6350 read the following transponders:

MIFARE Ultralight 512-bit EEPROM

MIFARE Classic 1K bytes memory

MIFARE Classic 4K bytes memory

MIFARE Ultralight 512-bit EEPROM is only partly supported; only

32 bits out of the 64 bits can be transmitted.

1.3 Box Content

Before beginning, verify that all of the following is in the box. If

anything is missing, please report the discrepancy to your nearest

Rosslare office.

One AY-Q6x50 Reader unit

Installation kit including:

One drilling template (label/sticker)

One security spline key

One security hex screw

Two mounting screws and wall plugs

Installation and Programming Manual

Technical Specifications

10 AY-Q6x50 Family Installation and Programming Manual

2. Technical Specifications

Electrical Characteristics

Power Supply Type Linear type (recommended)

Input Voltage 5–16 VDC

Absolute Maximum Voltage

(non-operating)

18 VDC

Maximum Input Current AY-Q6250:

Standby: 60 mA, Read: 100 mA

AY-Q6350:

Standby: 115 mA, Read: 160 mA

LED/Buzzer Control Input Dry Contact N.O.

Tamper Output Open collector, active low, max. sink

current 32 mA

Max. Controller Cable Distance

150 m (500 ft) (using an 18-AWG cable

Max. Proximity Read Range* 30 mm (1.2 in.)

Frequency 13.56 MHz

Transmission Formats Wiegand and Clock & Data

Card Compatibility MIFARE and all ISO14443A-3 cards

Environmental Characteristics

Operating Temperature Range -31°C to 63°C (-25°F to 145° F)

Operating Humidity Range 0 to 95% (non-condensing)

Suitable for outdoor use (meets IP65)

Operating Environment Suitable for outdoor use (IP65 compliant),

water resistant

Dimensions

Height x Width x Depth 120 x 76 x 27 mm (4.7 x 3.0 x 1.1 in.)

Weight 500 g (1.1 lb)

* Measured using a Rosslare proximity card or equivalent. Range also

depends on electrical environment and proximity to metal.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Lector de tarjetas de Rosslare

Rosslare

Rosslare DR-6280 Manual de usuario

Rosslare

Rosslare AYC-E60B Instrucciones de montaje

Rosslare

Rosslare AY-V12B Manual de usuario

Rosslare

Rosslare AY-Z12 Manual de usuario

Rosslare

Rosslare CSN SELECT AYC-6355 Series Manual de usuario

Rosslare

Rosslare AY-H12C Manual de usuario

Rosslare

Rosslare MIFARE AY-T6350 Instrucciones de montaje

Rosslare

Rosslare AY-D09M Instrucciones de montaje

Rosslare

Rosslare MIFARE Classic AY-25B Series Manual de usuario

Rosslare

Rosslare AY 6255 Series Manual de usuario

Rosslare

Rosslare AY-H6255BT Manual de usuario

Rosslare

Rosslare AY-Q12 Instrucciones originales

Rosslare

Rosslare AY-K6255 Manual de usuario

Rosslare

Rosslare AY 20 Series Manual de usuario

Rosslare

Rosslare AY-Z12A Manual de usuario

Rosslare

Rosslare DR-12C Manual de usuario

Rosslare

Rosslare AY-B8620 Manual de usuario

Rosslare

Rosslare AY-U9**BT series Manual de operación

Rosslare

Rosslare AY-x25B Series Manual de usuario

Rosslare

Rosslare Mifare CP-R25 Instrucciones de montaje

Rosslare

Rosslare AY-x20 Series Manual de usuario

Rosslare

Rosslare AY-U920BT-US Manual de usuario

Rosslare

Rosslare AY-K20C Manual de usuario

Rosslare

Rosslare Multi-Smart AY-K35 Manual de operación

Manuales populares de Lector de tarjetas de otras marcas

Lindy

Lindy 43185 Manual de usuario

Lindy

Lindy 43185 Manual de usuario

ViziT

ViziT RD-4F Manual de usuario

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Manual de usuario

AVID ID

AVID ID AVID1043 Manual de usuario

Conrad

Conrad PCMCIA Manual de usuario

Lindy

Lindy 51541 Manual de usuario

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Manual de usuario

Johnson Controls

Johnson Controls Kantech tyco ioSmart Manual de usuario

ACS

ACS ACR122L Manual de usuario

Secukey

Secukey S2-MF Manual de usuario

Elecom

Elecom MR-SMC07 series Manual de usuario

Alien

Alien ALR-9800 Manual de usuario

ACS

ACS ACR310 Manual de usuario

Datamars

Datamars R-IN1300 MID Manual de usuario

Alarm Lock

Alarm Lock AL-PRE2 Manual de usuario

xpr

xpr B100PROX-AH Guía del usuario

SimpleTech

SimpleTech FlashLink Manual de usuario
