Rosewill RX35-AT-SU3 Manual de usuario

SATA TO USB3.0 External Enclosure

RX35-AT-SU3

User Manual

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty information and future support for your product.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

Contents

English………………………………………………………………………….. P.2

Français………………………………………………………………………….P.8

Deutsch…………………………………………………………………………P.14

Español………………………………………………………………………… P.20

Português……………………………………………………………………… P.26

繁體中文………………………………………………………………. ………. P.32

简体中文………………………………………………………………. ………. P.38

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

English

Hard Drive Installation Guide

Note: Please follow the instructions to make sure your Hard Drive is successfully installed into the External

Enclosure.

STEP1: Please open the Enclosure to view the internal structure of the Enclosure

STEP2: Push the Hard Drive towards the SATA connector and make sure the SATA connector is properly connected.

STEP3: Screw the Hard Drive onto the tray tightly.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

STEP4: Insert the installed Hard Drive tray back into the Enclosure.

☆Notice：Carefully insert the tray back into the Enclosure.

STEP5: Screw both sides of the Enclosure to lock the Hard Drive.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

STEP6: Screw in both screws on the back panel.

This will conclude the Hard Drive installation guide.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

Hard Drive Formatting Guide

☆ You may format your Hard Drive by using the USB connection.

☆ Please make sure your External Enclosure is turned on and connected to the PC before formatting the Hard

Drive.

STEP1: Right-click on the “My Computer” and select “Manage”.

STEP2: Select “Disk Management” and you will see your Hard Drive shown as “Unallocated” (Disk number may vary)

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

STEP3: Right-click on the “Unallocated” box and select “New Partition”. (Disk number may vary)

STEP4: The “New Partition Wizard” will appear. Please follow the "New Partition Wizard" step by step instructions to

complete the Hard Drive formatting procedure.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

STEP5: Once the Hard Drive formatting procedure is completed, the Hard Drive will be recognized as a “New Volume”

(New Volume drive letter may vary i.e. “New Volume (Z:)” )

STEP6: Double-click “My Computer”. You will see “New Volume” appear on your PC (Drive letter may vary i.e. “New

Volume (Z:)”)

This will conclude the Hard Drive Formatting guide.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

Français

Guide d'installation du disque dur

Note : Veuillez suivre les instructions pour vous assurer que votre disque dur est correctement installé dans le

boîtier externe.

ÉTAPE 1 : Veuillez ouvrir le boîtier pour voir sa structure interne

ÉTAPE 2 : Poussez le disque dur en direction du connecteur SATA et assurez-vous que le connecteur SATA est bien

connecté correctement.

ÉTAPE 3 : Vissez solidement le disque dur dans le tiroir.

SATA TO USB3.0 External Enclosure RX35-AT-SU3 User Manual

ÉTAPE 4 : Remettez le tiroir avec le disque dur installé dans le boîtier.

☆Attention : Remettez soigneusement le tiroir dans le boîtier.

ÉTAPE 5 : Vissez les deux côtés du boîtier de façon à bloquer le disque dur.
