[RX355-U]

3.5" IDE to USB Ext. Enclosure

With Removable 80mm fan

User Manual

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Please read this installation carefully before you use the product.

Precaution:

1. If it is a new HDD, needs to processing the disk partition

2. Win98SE and WinME do not recognize NTFS formatted drives,

so if you want to use your drive on those platforms, we

recommend you to use FAT32 instead.

3. Mac OS does not recognize NTFS formatted drives, to use your

device on both platforms, we recommend you using FAT32.

4. If you use Win2000 / WinXP/ Win Vista and FAT32, the biggest

single partition you can create will be 32GB. To create larger

partitions, you need to use the DOS command under Win98SE

or WinME or change to NTFS format.

5. Make sure the jumper settings of your hard drive is “master”.

System Requirement:

•Minimum Intel Processor II 350MHz, 64MB RAM

•Compatible with IBM PC, USB interface included，Windows

98/ME/2000/XP/Vista operate system.

•Minimum Apple G3 processor, 64MB RAM

•MAC computer system MAC OS V9.x or higher.

•Linux OS : please download kernel USB stack.

Available Interfaces

•USB 2.0 HIGH SPEED for IDE HDD

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Protection of DC adapter:

1. Primary (Input) Protection

The input power line will be fused with a fuse 2.0A, 250 VAC.

2. Secondary (Output) protection

2.1.Over Current (OC) Protection

When an internal fault occurs, or an external fault is applied to

the power, such that an overload or short circuit is applied to

the output, the power will be shutdown. Power latch is not

allowed.

2.2 Over Voltage (OV) Protection

If an over-voltage fault occurs on the adapter output, the power

will shutdown.

2.3 Short Circuit Protection

The power will protect itself, and shut down, if a short circuit is

placed between DC return and the output. This condition will

cause no damage to the power. Power latch is not allowed.

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Package Contents

USB 2.0 interface

Item Quantity

3.5” External Enclosure 1 pcs

Driver Disk 1 pcs

Installation Guide 1 pcs

AC adapter 1 pcs

USB cable 1 pcs

Foot stand 1 pcs

Screw Kit 1 set

Fan kit 1 set

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

FEATURE

1. Standard USB 2.0 high speed transfer rate.

2. Aluminum HDD framer for easy installation.

3. Removable 80 mm fan kit.

4. Suitable for all 3.5" IDE HDD.

5. All aluminum and super slim design, to enhance heat dissipation.

6. Foot-stand for vertical style.

7. Plug and play & Hot Swappable

8. Built-in with integrated 80 mm ultra silent cooling fan provides

excellent heat dissipation.

9. Fan control for the 80mm cooling fan

10. LED indicator

11. Support up to 750 GB HDD

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Technical Specifications

External Interface USB 2.0 ( Speed up to 480 Mbps)

Internal Interface 3.5” IDE HDD

Connectors USB B receptacle

Operating

System

Win 98SE/ME/2000/XP/Vista

Mac OS 9.x and above.

IDE Standard Compliant with ATA-6 UDMA 66/100/133

HDD Space Up to 750GB

LED Power On / Access

Power Supply AC Adapter 12V / 2A

AC Input 100V ~240V full range

Dimensions 220(L) x 130(W) x 65(H) mm

Weight 2.43 lbs.

Certification CE

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Installation Guide:

1. Release the screws to pull out the HDD frame.

2. Fix the HDD by screws (after HDD located with the connecter).

3. Pull in the frame into external box.

4. Fix the rear panel by screws.

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

5. After connect transfer cable and Power cord, the external HDD will

appear the relativity

6.Cooling fan cable installation:

Plug to DC fan cable into rear panel & cooling fan’s DC jack, and the

fan will be operating after the power on. (Please view image below)

Attention:

1. Only one interface at one time can be used

2. If this HDD is new one, please partition & format disk,

otherwise the system cannot detect HDD.

3. The HDD jumper should be set to “master”.

4. Make sure your PCI Host Card is installed correctly

5. If required, update your OS (win 2000 to SP4, Win XP to

SP1a)

6. Only one computer at one time can access the drive.

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Driver Installation:

Windows 98SE

1. After plug the external box into, the system will remind you

there is a new hardware of USB Storage Adapter adds into.

2. Design the driver of the safe path (in the driver), the system

will active the installation automatically.

3. After for a while, click "My Computer", USB HDD will appear

the relativity on the PC.

Windows ME/2000/XP/Vista

The system already provided support for the software.

MAC OS 9.x or above

OS 9.X edition:

The system already provides support for the software.

The divided partition of the external HDD

Win 98SE/ME SYSTEM

FDISK is command that doing the divided partition to HDD, The step

of how to divided partition from the HDD by using FDISK as follows:

1. Plug the cable of USB into PC, and be sure that the PC has

identified HDD.

2. Execute "FDISK" under the model of COMMAND.

3. After enter the FDISK program [If the FDISK program does not work,

please restart your PC again (don't plug out the USB HDD) then it will

be work]. Firstly select "The fifth item" --select the USB HDD you

want to divided partition for and then just see the illustration as

follows: Then just follow the instruction to divided partition for the

HDD of USB.

3.5" IDE to USB Ext. Enclosure With Removable 80mm fan UserManual

Windows 2000/XP/Vista

Plug the HDD into your system it will appear the hot plug a play. Just

click “Control Panel”/ “manage tool” / “computer management” /

“Disk management”. All the disk connects to the PC will appear on

the chart, as well as the state of the HDD. Find out the HDD and click

the right bottom of the mouse under the state of chart, just follow the

step. Take a look of the icon on the bottom.

Mac OS

Mac OS9.x and earlier version does not support creating partition on

an external HDD. For your new HDD, you need to purchase additional

3rd party software to creating your HDD partition.

For Mac OS X, use the Disk Utility to format and divided partitions on

your external disk.

• Select “Disk Utilities” in the utilities folder.

• Choose your external drive and format it.

Notice: If you want your ENCLOSURE on a Windows as well as on

your Mac OS, we recommend you to use a PC to format the drive.

Choose FAT32 format and do not change anything on the partition or

format on your Mac, otherwise the Windows OS can not be able to

recognize the ENCLOSURE.
