Ricoh PB3040 Manual de usuario
1
Paper Feed Unit PB3040/LCIT PB3050
(Code: D351, D352)
For Machine Code: G179
INSTALLATION GUIDE
R
CAUTION:
Attaching the Paper Feed Unit
This section describes how to attach
the 1000-sheet paper feed unit or
2000-sheet paper feed unit to the
printer. The procedure is the same for
both units. The 1000-sheet paper feed
unit is used as an example.
R
CAUTION:
Important
❒When attaching multiple options,
attach the paper feed unit first.
❒Either the 1000-sheet paper feed
unit or 2000-sheet paper feed unit
can be attached, but not both.
❒When the 1000-sheet paper feed
unit or the 2000-sheet paper feed
unit is attached, you can also at-
tach the 1200-sheet paper feed
unit. To attach the 1200-sheet pa-
per feed unit, contact your sales or
service representative.
❒Before using the new paper feed
unit, you must configure settings
in the printer driver.
A
Check the contents of the package.
For 1000-sheet paper feed unit:
For service personnel only (D009, D011,
D012, D013)
When installing the Paper Feed Unit, follow
the installation procedure in the service
manual.
•The printer weights approxi-
mately 73 kg (161 lb.).
•Four or more people are re-
quired to move the printer. Hold
the handles located on both
sides, and then lift it slowly. Lift-
ing it carelessly or dropping it
may cause an injury.
•It is dangerous to handle the
plug with wet hands. Doing this
may result in receiving an elec-
tric shock.
•Before moving the machine, un-
plug the power cord from the out-
let. If the cord is unplugged
abruptly, it could become dam-
aged. Damaged plugs or cords
can cause an electrical or fire
hazard.
BEK501S
AlexP1_pera_pfu-GB-F1_FM_forPaper.book Page 1 Thursday, April 24, 2008 5:34 PM
2
For 2000-sheet paper feed unit:
BTurn the printer off and unplug
the power cord.
CRemove the packaging from the
paper feed unit.
DPull out the handle from the right
side of the printer.
ELift the printer using the handles
on both sides.
The printer should always be lifted
by at least four people.
FAlign the front of the printer with
the front of the paper feed unit,
and slowly lower it.
Place it so that it is held firmly in
place by the vertical pins.
Return the handle you pulled out
from the printer to its original po-
sition.
BEK500S
BEK011S
BEJ126S
BEJ124S
AlexP1_pera_pfu-GB-F1_FM_forPaper.book Page 2 Thursday, April 24, 2008 5:34 PM
3
GPull out tray 2 of the printer slow-
ly until it stops, lift the front of
the tray slightly, and then pull out
the tray completely.
Place the tray on a flat surface.
HAttach a screw in the hole on the
left side of the tray opening to se-
cure the printer to the paper feed
unit.
Tighten the screw firmly using a
coin.
ILift the front of the tray, and slide
it carefully into the printer until it
stops.
JOn the rear of the unit, attach two
brackets using the remaining
screws.
Tighten the screws firmly using a coin.
KPlug in the power cord, and then
turn on the printer.
LPrint the configuration page to
confirm that the unit was attached
correctly.
Note
❒To confirm whether the optional
paper feed unit was correctly at-
tached, print the configuration
page, and check "Attached Equip-
ment" on the configuration page. If
the unit was attached correctly, the
following will be displayed:
• 1000-sheet paper feed unit:
Lower Paper Trays
• 2000-sheet paper feed unit: Tray 3
❒
If the optional paper feed unit was
not installed properly, repeat the
procedure from step
2
. If it cannot
be installed correctly even after reat-
tempting installation, contact your
sales or service representative.
Reference
For information about printing the
configuration page, see "Test Print-
ing", Quick Installation Guide
If the print area is not centered cor-
rectly, see "Adjusting Printing Po-
sition", Hardware Guide
BEK103S
BEJ115S
BEK105S
BEK106S
AlexP1_pera_pfu-GB-F1_FM_forPaper.book Page 3 Thursday, April 24, 2008 5:34 PM
4
Copyright © 2008
Printed in China
GB GB EN USA D351-6600A
D3516600A
