Side Tray Type M3

Machine Code: D725

Field Service Manual

July, 2014

Subject to change

Revision Lists

Version Section Details

1.00 - Initial release of this document.

Created this manual for D146 series.

1.10

All Revised all sections according to the release

of D197 series.

Read This First > Safety and Symbols Modified some icons.

Replacement and Adjustment >

Drive Motor Unit

Modified items need to be removed in Step

2, 3, and 6.

Replacement and Adjustment >

Upper Paper Exit Sensor

Modified items need to be removed in Step 6

and Step 10.

Replacement and Adjustment > Left

Paper Exit Sensor

Modified items need to be removed in Step

Replacement and Adjustment >

Upper Paper Exit Tray Set Switch Modified items need to be removed in Step

Replacement and Adjustment >

Paper Exit Switching Unit Set Switch

Safety and Symbols

This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations

are as follows:

Clip ring

Screw

Connector

Clamp

SEF Short Edge Feed

LEF Long Edge Feed

[A] Short Edge Feed (SEF)

[B] Long Edge Feed (LEF)

Trademarks

Microsoft®, Windows®, and MS-DOS® are registered trademarks of Microsoft Corporation in the

United States and /or other countries.

PostScript® is a registered trademark of Adobe Systems, Incorporated.

PCL® is a registered trademark of Hewlett-Packard Company.

Ethernet® is a registered trademark of Xerox Corporation.

PowerPC® is a registered trademark of International Business Machines Corporation.

Other product names used herein are for identification purposes only and may be trademarks of their

respective companies. We disclaim any and all rights involved with those marks.

TABLE OF CONTENTS

Revision Lists........................................................................................................................................................1

Safety and Symbols............................................................................................................................................2

Trademarks.....................................................................................................................................................2

1. Replacement and Adjustment

Drive Motor Unit.................................................................................................................................................5

Upper Paper Exit Sensor....................................................................................................................................9

Left Paper Exit Sensor.......................................................................................................................................13

Upper Paper Exit Tray Set Switch...................................................................................................................14

Paper Exit Switching Unit Set Switch..............................................................................................................15

1. Replacement and Adjustment

Drive Motor Unit

1. Upper extension tray [A], Left extension tray [B].

2. Fixing plate [A] ( ×1).

3. Side tray [A] ( ×1).

1. Replacement and Adjustment

4. Drive motor unit cover [A] ( ×2).

5. Side tray rear cover [A] ( ×1).

Drive Motor Unit

6. Drive motor unit [A] ( ×3, ×2).

1. Replacement and Adjustment
