PROAIM DL-SPIN-01 Manual de usuario
1
Instruction Manual
Spin Lightweight Doorway
Platform Dolly (DL-SPIN-01)
2
Subject Page
Foreword 3
Introducon 4
Safety Hints 5
Assembling 6-8
Warranty 9
At Proaim, our goal is to ensure 100% Customer Sasfacon in all that we do.
We back our sales with a 1 year warranty from the date of purchase and work hard
to resolve any problems in the unlikely event one should arise.
With our commitment to connuous improvement and your Feedback, building on
our reputaon of providing aordable, quality products is
PRIORITY #1.
Table of Contents
3
Dear Client,
On behalf of all the people that work so hard to provide you with the most
up-to-date, exible and cost-ecient producon gear, we would like to welcome
you into the Proaim family.
By purchasing your Proaim Spin Lightweight Doorway Plaorm Dolly, you have just
joined a host of designers, engineers, machinists, assembly, customer service and
oce sta that take great pride in all that they do. Our mantra of connuous
improvement has been the guiding principle of how we conduct our business since
day one.
Once you have the opportunity to experience your new Proaim Spin Lightweight
Doorway Plaorm Dolly, we hope you will agree that we cra quality products at a
compeve price. Products designed to meet and exceed the standards of today’s
real producon world.
Standards set by our valued clients and standards we strive to maintain.
With Best Wishes,
Proaim Team
Welcome To Proaim!
4
Proaim Spin Doorway Dolly is an all-in-one dolly system designed to perform the
tasks of full-sized doorway dollies and track dollies in a single, portable system. It is
aperfect, lightweight and cost-eecve camera dolly for majority of small
producons or video shoots, where you need to get moving shots quickly and
easily. It is constructed from highest grade materials for ulmate strength and
supports loads up to 300kg / 661lb. The dolly can be customized with the addion
of oponal accessories, to expand capabilies and features.
Introducon
What’s In The Box
Proaim Track Wheel for
spin dolly (SPN-TRK-WS) Proaim wheel axle
For spin dolly
Proaim Spin Lightweight Doorway
Plaorm Dolly (DL-SPIN-01)
Accessories
4mm 10mm 13mm
5
Safety Hints
ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO
THE GEAR!
ALWAYS FIX BOTH THE PUSH BARS SECURELY
While using the dolly, carefully mount the steering bars on either sides, and ghten
the knobs.
INSPECT THE SURROUNDINGS PRIOR TO OPERATION
The operang area of the dolly and its accessories must be kept clear. Keep a
distance of approximately 0.5m to surrounding objects.
NEVER LEAVE THE FIXTURES LOOSE
All the knobs/screws must be bolted ghtly to avoid destabilizing of dolly and the
whole camera setup.
ALWAYS SET THE CORRECT AIR PRESSURE
While using as doorway dolly, the tyre pressure should never be more than 400 kPa.
FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE
OPERATION.
SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS
AVAILABLE ‘ONLINE’ BY CONTACTING YOUR SALES REPRESENTATIVE.
6
Assembling
Loosen the knob on either rear side of dolly. Insert both Handle Bar together & ghten the
knobs to secure them.
Insert the push bar handle into the
Rear-Wheel Steering and lock it with the
provided pin.
Hold the hex nut with 13mm wrench & loosen the steering rod bolt with 4mm allen key to
remove the allen bolt from dolly.
Converng 4x4 into 2x2
7
Remove the bolts on Pneumac wheels with provided 4mm allen key and detach the wheels.
Then remove the bolt (as shown) with the help of 10mm allen key and detach the front
secon of dolly.
Insert the wheel axle in dolly & screw it ghtly. Then aach the wheel and ghten it properly.
8
Remove the knob to aach the track
wheels.
Now aach the Track wheels. Re-insert
the knob and ghten it properly. Follow
the same steps on the other side of the
dolly.
(SHOWN WITH OPTIONAL ACCESSORIES)
YOUR PROAIM SPIN LIGHTWEIGHT DOORWAY PLATFORM DOLLY
ALL DRESSED UP AND READY TO GO!
9
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
For any other assistance you can reach us via email.
