PROAIM P-SFT-DT-12 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Swi Camera Dolly System with 12

Straight Track (P-SFT-DT-12)

Assembly Manua l

4x 4’ Central Secon with Nylon Aachment Bushings

2x 4’ Extension Rods

2 x Track Stoppers

Swi Dolly with Wheels Aached

Bags Packing

10 x Track Riser Supports (Blue)

10 x Track Riser Supports (Black)

14” Central

Support System

15” Camera

Mounng Post

 Remove the outboard set of screws from the

secons using a wrench, slide extension

secon into each end to complete a 12' run,

install and ghten the screws to secure.

 Aach the Track Supports, and Track Riser

Supports to the track.

 Note: Track Supports oers rigidity and

prevent dolly from running o the rails.

 The track is now ready to use.

 Remove the lock knob from the 27" central

secon and connect the 32" dolly rods to give

it a triangular shape.

 Aach the 27" rod to the wheelset and

ghten the knob to secure.

Track Setup

 Loosen the lock knob from the 32" rods of the

dolly secon, connect with 27" of central area,

and ghten the knob to secure.

 Aach the 14" central support system rod to

the base and ghten the screws to secure it.

Swi Dolly Setup

E to E

C to C

YOUR PROAIM SWIFT CAMERA DOLLY SYSTEM WITH 12FT STRAIGHT TRACK

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

 Place the dolly on the tracks as shown in the

image.

 Aach a 15" camera mounng post to the

base and ghten the screws as shown in the

images.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
