PROAIM Cinema VCTR-LT Manual de usuario

Victor Lite Video Producon Camera Cart (VCTR-LT)

Assembly Manua l

Available Size: 32”, 36”, 42” & 48”

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

2 x Handles

Top Shelf

Boom Shelf with (4 x 6” Foldable Rods) 4 x Pneumac Wheels

1 x Accessory Crossbar 1 x Suitcase Handle 4 x Knobs

• Open the 4 x legs of the boom shelf of the

Trolley.

• Tighten the 4 x legs properly with the help of

the provided knob on the boom shelf of the

Trolley.

Victor Cart Setup

• Slide pneumac wheels onto the cart's

boom shelf and lock them with the top

knob, as shown in the image.

• Pneumac wheels are correctly assembled, as

shown in the image

• Mount Top Shelf of Trolley onto Rods, as

shown in the image.

NOTE: Two people are required to set the top

shelf on the rods.

• Open all 4 locks of the Trolley to take out all

the parts, as shown in the image.

• Follow the same process for the other rubber

handle, and both of your rubber handles are

aached to the rods.

• Finally, 4 x knobs are properly aached to the

4 corners on the cart's top shelf.

• Insert the 4 x knobs into the 4 corners of the

top shelf and ghten it.

• For aaching Crossbar, loosen the side clamp

knobs of the accessory crossbar.

• Now for rubber handles, Lose the rubber

handle & aach the rubber handles to the

rods. Set the height as per your

requirements.

• Then mount the Crossbar on the rods and

ghten the knob properly.

• Align the handle with the boom Shelf, put

the bolt back, and ghten it using a 4mm

Allen key.

• Aach the Suitcase Handle to the boom

shelf.

• Now, for aaching the Suitcase Handle,

Remove the buon heads of the handle with

the help of the 4mm Allen key.

• Proaim Victor Lite Video Producon Camera

Cart is ready to use.

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.

YOUR PROAIM VICTOR LITE VIDEO PRODUCTION CAMERA CART

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)
