Quick Installation Guide

GEPON SFU ONU

EPN-102 / EPN-104

Important Safety Instructions



Do not use the GEPON ONU in high humidity or high

temperatures.



Do not use the same power source for the GEPON ONU

as other equipment.



Do not open or repair the case yourself. If the GEPON

ONU is too hot, turn off the power immediately and have it

repaired at a qualified service center.



Avoid using this product and all accessories outdoors.



Place the GEPON ONU on a stable surface.



Only use the power adapter that comes with the package.

Using a different voltage rating power adaptor may

damage the ONU.

Package Content

EPN-102 / EPN-104



EPN-102 / EPN-104 Unit



CD-ROM containing the user’s manual, quick guide



Quick Installation Guide



Power Adapter



RJ-45 cable x 1

If any of the above items are missing or damaged, contact your

local dealer for support.

-2-

Hardware Installation

Please connect the ONU to you devices as follow:

Connecting the RJ-45 network cable.

a. Plug-in the RJ-45 cable to 10/100/1000 GE Port

(EPN-102 only) or 10/100 FE Ports.

b. Plug-in the other side to your host or devices.

Connecting the fiber cable.

Before connecting, please note:

Keep the optical connector and the optical fiber clean.

Make sure the bending diameter of the fiber is more

than 6cm.Otherwise; the optical signal loss may be

increased.

Cover a protective cap to guard against dust and water

when the fiber is not used.

a. Remove the protective cap of the optical fiber.

b. Remove the protective cap of the ONU optical

interface (PON interface). Insert the fiber into the

PON interface.

Connecting Power Adapter.

a. Connect the power adapter to the power socket

on the ONU.

b. Insert the other end into a power outlet.

c. Turn on the power-switch.

-3-

Figure-1 EPN-102 connection diagram

Figure-2 EPN-104 connection diagram

-4-

Verifying the Installation

After power on the ONU, the Power LED will be bright and

system starts to boot. When system is ready, the PON LED will

be flash.

If the PON connection is normal, the PON LED will be off and

Link LED is ON.And then you can enjoy the high bandwidth

connection via PON technology.

Further Configuration

The above steps introduce simple installations and

configurations for EPN-102 / EPN-104. For further information of

Specification, features and applications etc, please refer to the

user’s manual in the CD. If you have other questions, please

contact the local dealer or distributor where you purchased this

product.

2011-BA0020-000
