24-Port 10/100Mbps TP + 4-Port Gigabit TP/2-Port mini-GBIC

Layer 3 Managed Ethernet Switch

Data Sheet

Cost-Effective Solution

The PLANET WGS3-2820 is a 24-Port 10/100Mbps Layer 3 Managed

Ethernet Switch. Its essentials Layer 3 functionality of multimedia switch

brings high-end security and traffic control to the edge of the network.

With IP routing capability and flexible management tools, the PLANET

Managed Multi-Layer Switch Solution performs a cost-effective way for

today with the ability to expend as the growing of network demands.

High Performance

PLANET WGS3-2820 boasts the high performance switch architecture that

is capable of providing non-blocking switch fabric and wire-speed

throughput as high as 12.8Gbps. Its two built-in Fiber uplink ports also

offer incredible extensibility, flexibility and connectivity to the other core

switches or Servers.

Excellent Traffic Control

PLANET WGS3-2820 is loaded with powerful traffic management and QoS

features to enhance services offered by telecoms. The functionality includes

QoS features such as wire-speed Layer 4 traffic classifiers, bandwidth

limiting, Policy-Based DiffServ that are particular useful for multi-tenant

units, multi business units, Telco, or Network Service Provide applications.

It also empowers the enterprises to take full advantages of the limited

network resources and guarantees the best performance of VoIP and

Video conferencing transmission.

Powerful Security

PLANET WGS3-2820 offers comprehensive Access Control List (ACL) for

enforcing security to the edge. Its protection mechanisms comprises of

port-based 802.1x user and device authentication. The port-security is

effective in limit the numbers of clients pass through. The administrators

can now construct highly secured corporate networks with time and effort

considerably less than before.

Flexibility and Extension Solution

The two mini-GBIC slots are compatible with 1000Base-SX / LX and WDM

SFP (Small Factor Pluggable) fiber-optic modules. The distance can be

extended from 550 meters (Multi-Mode fiber), up to above 10/50/70/120

kilometers (Single-Mode fiber or WDM fiber). They are well suited for

usage within the enterprise data centers and distributions.

Efficient Management

With its built-in web-based management, the PLANET WGS3-2820 offers

an easy-to-use, platform-independent management and configuration

facility. The PLANET WGS3-2820 supports standard Simple Network

Management Protocol (SNMP) and can be managed via any standard-

based management software. For text-based management, the WGS3-

2820 can also be accessed via Telnet and the console port. For remote

secured management, the WGS3-2820 supports SSL and SSH connection

which encrypt the packet content at each session.

WGS3-2820

Data Sheet

WGS3-2820

Layer 2 Features

• The 10/100Base-TX ports support auto-sensing and auto-negotiation

• Supports Jumbo frame up to 9K bytes on 10/100/1000Base-T ports

• Provides wire speed of L2 switching performance

• Supports up to 16K MAC address entries

• IEEE 802.3x Flow Control for Full-Duplex mode and Back-Pressure of

Half-Duplex mode

• Provide Store-and-Forward forwarding scheme

• Provides Broadcast storm protection

• Supports IGMP snooping v1, v2 and V3

• Supports 802.1Q Tagged VLAN, Protocol-Based VLAN and GVRP

protocol for dynamic VLAN Management

• Supports double-tagged for Q-in-Q VLAN tag frame

• Supports Spanning Tree Protocol with 802.1d STP, 802.1w RSTP and

802.1s MSTP

• Link Aggregation bandwidth gathering supports 802.3ad LACP and

Static Port Trunk

• Provides Port Mirror (many-to-1)

IP Routing Features

•IP Routing protocol supports RIP v1 / v2, OSPF v2

•Routing interface provides per-Port routing and VLAN routing mode

•Supports router discovery (IRDP)

•VRRP protocol for redundant routing deploy

•Supports route redistribution

Multicast Routing Features

•Supports PIM-DM and PIM-SM

•Supports DVMRP

•Supports IGMP v1 / v2 / v3

Security

• User / Password protected system management

• L2 / L3 / L4 ACL (Access Control List)

• RADIUS and TACACS client

• IEEE 802.1x Port-Based Authentication for network access control

• Port MAC lock Security

Quality of Service

• IEEE 802.1p based CoS

• IP TOS / Precedence and DSCP based CoS

• 8 priority queues per port

• Policy based DiffServ per port

• Supports for strict priority and Weighted Round Robin (WRR) CoS

policies

Management

• Provides 1 male DB9 RS-232 console interface

• Supports Command Line Interface of switch management

• Supports Web management for switch

• Supports SNMP v1, v2c, and v3 switch management

• Supports BOOTP and DHCP for IP address assignment

• Supports software and configuration upload/download via XMODEM or

TFTP

• Supports SSH v1 / v2 and SSL v3 / TLS v1 switch management and

security network login

• Supports SSH / SSL / TLS keys download via TFTP

• Supports SNTP (Simple Network Time Protocol)

• Supports Ping and telnet function

• Supports message / event / error / trap logs

• Supports logging to local file and Syslog server

• Supports Private Enterprise MIB

• Supports RMON groups 1, 2, 3 and 9

Key Feature

WGS3-2820

24-Port 10/100Mbps TP + 4-Port Gigabit TP/2-Port mini-GBIC

Layer 3 Managed Ethernet Switch

Product

Specification

Model

Hardware Specification

10/100Base-TX Ports

10/100/1000Base-T Ports

SFP / mini-GBIC Slots

Switch Architecture

Switch Fabric

Switch Throughput

Address Table

Layer 3 Routing Table

Buffer Memory

Flow Control

LED

Layer 2 Function

Management Interface

Port Configuration

Port Status

VLAN

Port Trunking

QoS

IGMP Snooping

IP Routing Protocol

Multicast Routing Protocol

Standards Conformance

Regulation Compliance

Standards Compliance

Physical Specifications

Dimensions (W x H x D)

Weight

Environment Specifications

Operating

Storage

WGS3-2820

24 RJ-45 Auto-MDI / MDI-X ports

4 RJ-45 Auto-MDI / MDI-X ports

2 SFP interfaces

Store-and-Forward

12.8Gbps Capacity

9.5Mpps

16K MAC address table with Auto learning function

2048

2Mbits for packet buffer

Back pressure for Half-Duplex

IEEE 802.3x Pause Frame for Full-Duplex

Power, Link / Act- for per port status definition

Console. Telnet, SSH, Web, SSL, SNMP

Port disable / enable. Auto-negotiation 10/100Mbps full and half duplex mode selection Flow

Control disable / enable. Bandwidth control on each port

Display each port's speed duplex mode, link status and Flow control status. Auto negotiation

status and trunk status

IEEE 802.1Q Tagged Based VLAN ,up to 4041 VLAN groups

Supports 10 groups of 8-Port trunk

Traffic classification based on Port Number, 802.1p priority and DS / TOS field in IP Packet

Allow to be disabled or enable.

Static Route, RIPv1 / v2, OSPFv2, IRDP, VRRP

DVMRP, PIM-DM / SM

FCC Part 15 Class A, CE

IEEE 802.3  10BASE-T

IEEE 802.3u 100BASE-TX / 100BASE-FX

IEEE 802.3z Gigabit SX / LX

IEEE 802.3ab Gigabit 1000T

IEEE 802.3x Flow Control

IEEE 802.3ad Port trunk with LACP

IEEE 802.1d Spanning tree protocol 

IEEE 802.1w Rapid Spanning tree protocol

IEEE 802.1s Multiple Spanning Tree Protocol

IEEE 802.1p Class of service

IEEE 802.1Q VLAN Tagging

430 x 44.5 x 350 mm, 1U height

4.5 KG

Temperature 0°C ~ 50 Degree C

Relative Humidity  20% ~ 85% (non-condensing)

Temperature  -40°C ~ 70 degree C

Relative Humidity  20% ~ 90% (non-condensing)

Data Sheet

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

05-07 C-WGS32820-1

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518  Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

Data Sheet

WGS3-2820

24-Port 10/100Mbps TP + 4-Port Gigabit TP/2-Port mini-GBIC Layer 3 Managed Ethernet Switch

WGS3-2820

Applications

Ordering Information

SFP-Port 1000Base-T Module

SFP-Port 1000Base-SX mini-GBIC module

SFP-Port 1000Base-LX mini-GBIC module

SFP-Port 1000Base-LX mini-GBIC module-30km

SFP-Port 1000Base-LX mini-GBIC module-50km

SFP-Port 1000Base-LX mini-GBIC module-70km

SFP-Port 1000Base-LX mini-GBIC module-120km

SFP-Port 1000Base-LX (WDM, TX:1310nm) mini-GBIC module-10km

SFP-Port 1000Base-LX (WDM, TX:1550nm) mini-GBIC module-10km

SFP-Port 1000Base-LX (WDM, TX:1310nm) mini-GBIC module-20km

SFP-Port 1000Base-LX (WDM, TX:1550nm) mini-GBIC module-20km

SFP-Port 1000Base-LX (WDM, TX:1310nm) mini-GBIC module-40km

SFP-Port 1000Base-LX (WDM, TX:1550nm) mini-GBIC module-40km

MGB-GT

MGB-SX

MGB-LX

MGB-L30

MGB-L50

MGB-L70

MGB-L120

MGB-LA10

MGB-LB10

MGB-LA20

MGB-LB20

MGB-LA40

MGB-LB40

Available Modules

Core Routing Switch

With 24 10/100Mbps ports and 4 Gigabit TP with 2 shared SFP fiber

interfaces and Layer 3 IP/Multicast Routing capability, the WGS3-2820

provides a cost-effective and high-performance solution for Telecom,

Network Service Provider and enterprise.

1000 SX / LX 100 FX 100 TX1000 T

Department Security and QoS Switch

With its 12.8 Gigabits per second and non-blocking switch fabric, the

WGS3-2820 can easily provide a local, high bandwidth, and Gigabit

Ethernet network for backbone of your department. With the two

SFP ports, the WGS3-2820 provides the uplink to the backbone

network through Gigabit Ethernet LX/SX SFP modules. With the

security and QoS features, it improves the network efficiency and

protects the network clients.

ISP / Telecom Backbone Routing Switch

With build-in robust Layer 3 IP and Multicast routing protocols, the

WGS3-2820 ensures reliable routing between VLANs and network

segmentation. The routing protocols can be applied by per-port or

VLAN interface with up to 2K routing entries, and the high-density

routing interfaces provide expandability to meet the growing needs of

networks. Moreover, with the hot VLAN feature,Q-in-Q (VLAN

stacking) supported, it allows the service providers to offer certain

services, such as Internet access on specific VLANs for specific

customers, and it still allows them to provide other types of services

for their other customers on other VLANs.

Switch Converter

Video

Data

Voice

WGS3-2820 10 Km

2 Km

20 Km

2 Km

40 Km 20 Km

FTTH

FTTPFTTB

ISP

Internet

Edge Switch

Other L3 Switch

WGS3-2820

10km

Server Farm

Router

Otros manuales de Enrutador de red de Planet

Planet

Planet VIP-280 Manual de usuario

Planet

Planet FGSW-2620VM Series Manual de usuario

Planet

Planet FGSW-2620VM Series Manual de usuario

Planet

Planet gsd-1002vhp Manual de usuario

Planet

Planet ADSL VPN/Firewall Router ADW-4200 Manual de usuario

Planet

Planet ADE-3400 Manual de usuario

Planet

Planet WGSW-2620HP Manual de usuario

Planet

Planet ADE-3400 Manual de usuario

Planet

Planet ADE-3410v4 Manual de usuario

Planet

Planet ADSL 2/2+ VPN Firewall Router ADE-4300A/B Manual de usuario

Planet

Planet IGS-6325 DIN rail Series Manual de usuario

Planet

Planet EPN-102 Manual de usuario

Planet

Planet Gaw9.2Z18-4 Manual de usuario

Planet

Planet FNSW-4800v2 Manual de usuario

Planet

Planet ADSL 2/2+ VPN Firewall Router ADW-4302A v2 Manual de usuario

Planet

Planet WSD-800 Manual de usuario

Planet

Planet 85M Powerline to Ethernet Bridge with 4-Port Switch... Manual de usuario

Planet

Planet IGS-5227-6T Manual de usuario

Planet

Planet MH-3400 Manual de usuario

Planet

Planet GSW-1602SF Manual de usuario

Planet

Planet WGSD-10020 Manual de usuario

Planet

Planet GS-4210-24P2S Manual de usuario

Planet

Planet ADE-3100 Manual de usuario

Planet

Planet FGSW-2402PVS Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
