pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

pickering

USER MANUAL

VERY HIGH DENSITY MULTIPLEXER

MODULE

(MODEL No. 40-670)

www.pickeringswitch.com

Pickering Interfaces Ltd.

Stephenson Road

Clacton-on-Sea

CO15 4NL

United Kingdom

Tel: +44 (0)1255-428141

Fax: +44 (0)1255-475058

E-Mail: sales@pickeringswitch.com

Pickering Interfaces Inc.

966 SW 6th Street

Grants Pass

Oregon 97526

USA

Tel: 541 471 0700

Fax: 541 471 8828

E-Mail: ussales@pickeringswitch.com

Pickering Interfaces GmbH

Buchenstrasse 15

D-77880

Sasbach

Germany

Tel: +49 7841 66 49 10

Fax: +49 7841 66 49 12

E-Mail: desales@pickeringswitch.com

Pickering Interfaces AB

Karl Nordströmsväg 31

432 53

Varberg

Sweden

Tel: +46 340-69 06 69

Fax: +46 340-69 06 68

E-Mail: ndsales@pickeringswitch.com

ISO 9002

Reg No. FM38792

Issue 2, Jul 2002

Page ii

pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or

by any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

Page iii

pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, fax, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for

a period of two years from the date of delivery to the original purchaser. Any product found to be defective within

this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Warranty is on a return to factory basis, however, for most systems, the module may be replaced on a module

exchange basis. A module will be delivered to the user and the faulty part returned to Pickering Interfaces on

receipt.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, fax, the website or via

e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to fulll all relevant environmental laws and regulations and reduce wastes and releases

to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment

and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop

and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and

environmentally friendly manner.

Observe the Electrical Hazard Warning detailed in Section 7.

Observe the Electrostatic Sensitive Device Caution detailed in Section 7.

Page iv

pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

THIS PAGE INTENTIONALLY BLANK

Page v

pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

Technical Support and Warranty....................................... iii

Contents (this page)........................................................... v

Section 1

Introduction......................................................................... 1.1

Section 2

Connector Pin Outs............................................................ 2.1

Section 3

Programming ...................................................................... 3.1

Section 4

Fault Diagnosis................................................................... 4.1

Section 5

Technical Specication...................................................... 5.1

Section 6

Parts List ............................................................................. 6.1

Section 7

Warnings and Cautions ..................................................... 7.1

CONTENTS

Page vi

pickering

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

THIS PAGE INTENTIONALLY BLANK

SECTION 1 - INTRODUCTION

Page 1.1

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

pickering

GENERAL

The 40-670 range of Very High Density Multiplexer Modules which form part of the System 40 PXI Programmable

Switching system feature a wide range of switching congurations. Typical applications include signal routing in ATE

and data acquisition systems.

The 40-670 multiplexer may be operated as a conventional multiplexer

with break-before-make action when a new channel is selected. In

addition multiple channels may be simultaneously selected (not available

in 1 pole mode).

Built-in Automatic Isolation Switching (available in 1, 2 and 4 pole mode)

connects only the currently active multiplexer bank to the analogue

common, thereby keeping capacitive loading and leakage currents in

large multiplexer systems to a minimum. Larger multiplexers may be

constructed by daisy chaining the common signals from multiple PXI

cards.

Connections are made via a front panel 200 pin connector.

The screened version (40-670-022-S) is suitable for switching frequencies

up to 100MHz. It may also be used with low frequency signals where very

good isolation and crosstalk performance is required.

The Multiplexer Module is provided in the following congurations (typical schematics are provided in Figure 1.1):

Single Mode

• V H D MUX 198 Channel 1 Pole 40-670-022-198/1

Multi-Mode

• H D 99 Channel 1 Pole 40-670-021-99/1

• H D 49 Channel 2 Pole 40-670-021-49/2

• H D 24 Channel 4 Pole 40-670-021-24/4

• H D 10 Channel 8 Pole 40-670-021-10/8

• H D 5 Channel 16 Pole 40-670-021-S-5/16

• V H D MUX 99 Channel 2 Pole 40-670-022-99/2

• V H D MUX 49 Channel 4 Pole 40-670-022-49/4

SECTION 1 - INTRODUCTION

MECHANICAL DESCRIPTION

The 40-670 range of Multiplexer Modules conform to the 3U height (128mm)

Eurocard standard. Each module comprises the following:

• CPCI Ejector Handle

• Front Panel mounted 200-way SCSI 2 Type connector

• 100 Ruthenium Reed Switches, or

• 100 Screened Ruthenium Reed Switches (-S) versions only

• Two spare Reed Switches (Relays RL101 and 102)

• Compact PCI backplane connector

• PCI Bridge (U1)

• Control Logic

The front panel is secured to the PCB by two M2.5 x 6mm pan-head posi-drive screws.

• V H D MUX 24 Channel 8 Pole 40-670-022-24/8

• V H D MUX 10 Channel 16 Pole 40-670-022-10/16

• V H D MUX 5 Channel 32 Pole 40-670-022-5/32

• H D Screened 99 Channel 1 Pole 40-670-021-S-99/1

• H D Screened 49 Channel 2 Pole 40-670-021-S-49/2

• H D Screened 24 Channel 4 Pole 40-670-021-S-24/4

• H D Screened 10 Channel 8 Pole 40-670-021-S-10/8

• H D Screened 5 Channel 16 Pole 40-670-021-S-5/16

Page 1.2

SECTION 1 - INTRODUCTION

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

pickering

Isolation

Switches

Common

1.2

1.1

1.4

1.3

2.2

2.1

2.4

2.3

49.2

49.1

49.4

49.3

Chan 1

Chan 2

Chan 49

40-670-022 49 Channel 4 Pole Multiplexer

Isolation

Switch

Common

198

40-670-022 198 Channel 1 Pole Multiplexer

Isolation

Switches

Common

1.2

1.1

2.2

2.1

99.2

99.1

40-670-022 99 Channel 2 Pole Multiplexer

GND

40-670-021-S 99 Channel Screened Multiplexer

Chan 1 IN

Common Out

24 24

Chan 5 IN

40-670-022 5 Channel 32 Pole Multiplexer

Figure 1.1 - Multiplexer Module (40-670): Schematic Diagrams

SECTION 1 - INTRODUCTION

Page 1.3

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670

pickering

FUNCTIONAL DESCRIPTION

A functional block diagram is provided in Figure 1.2. The Multiplexer Module is powered by a +5V input via Compact

PCI connector J1. The interface to the user test equipment is via the front panel mounted 200-way SCSI type

connector, J2. A bank of relays are energised via control signals from storage registers U8 to U20. The storage

registers are addressed by PCI bridge U1 to output the required signal. Module conguration is determined by

hardwired links and data stored in EEPROM U7. PCI Bridge U1 is congured by EEPROM U2.

Figure 1.2 - Multiplexer Module (40-670): Functional Block Diagram

200-WAY SCSI

CONNECTOR

STORAGE

REGISTERS

U8 TO U20

MODULE

CONFIGURATION

U5, U6 AND U7

PCI BRIDGE

CONFIGURATION

TERMINATING

RESISTORS

R4 TO R15



COMPACT PCI

BUS

CONNECTOR

+5V

RELAY COILS

RELAY CONTACTS
