Perlesmith PSTVS12 Manual de usuario
2
PSTVS12
Table Top TV Stand
•Carefully open the carton, remove contents and lay out on cardboard or other
protective surface to avoid damage.
•Check package contents against the Supplied Parts and Hardware List to assure
that all components were received undamaged. Do not use damaged or defective
parts.
•Not all parts and hardware included will be used. lf you require replacement parts,
•Carefully read all instructions before attempting installation.
•If you do not understand the instructions or have any concerns or questions, please
•This product may contain moving parts. Use with caution.
•Do not use this product for any purpose that is not explicitly specified in this
manual. Do not exceed weight capacity. We cannot be liable for damage or injury
caused by improper mounting, incorrect assembly or inappropriate use.
•Please check www.perlesmith.com for more products and company information.
UNPACKING INSTRUCTIONS AND IMPORTANT SAFETY INFORMATION
7
(x1)
Tempered Glass
6(x2)
Safety Lock
5
(x1)
Plastic Cover
2
(x2)
TV Bracket
1
(x1)
TV Plate
(x1)
4Upper Support
Pillar
3
(x1)
Lower
Support Pillar
Supplied Parts and Hardware List
Cable Clip
(x2)
8
MAX: 400mm/15.7in.
MAX: 400mm/
15.7in.
200 mm ≈ 7 7/8 in.
400 mm ≈ 15 3/4 in.
100 mm ≈ 4 in.
300 mm ≈ 11 3/4 in.
Check the VESA Pattern of TV before the Installation
1
2
7
H
7
Tempered
Glass
M8x25mm
Step 1
AD8.5
Washer
ERubber
Foot
H
5mm
Allen key
I
x1 x1 x1
x3 x3 x4
x1
5
Plastic Cover
3
Lower Support
Pillar
Step 1-1
7
3
Connecting the Lower Support Pillar to Tempered Glass
Attach Rubber Foot (H) to the Tempered Glass 7in the
Corners
Screw
M6x15mm(X4)
M-B
Screw
M4x30mm(X4)
M-A
Screw
M6x35mm(x4)
M-C
Screw
M8x20mm(x4)
M-D
Screw
M8x35mm(x4)
M-E
M-G
2.5mm Spacer(x8)
M-H
10mm Spacer(x4)
M-I
22mm Spacer(x4)
Screw
M8x50mm (x4)
M-F K
D4/D6/D8 Washer(x4)
H
Rubber Foot(x4)
G
D10.5xD30.0x2.5
Washer(x1)
E
D8.5xD18.0x1.5
Washer(x3)
F
D10.5xD28.0x1.0
Plastic Washer(x1)
M8x25mm(x3)
A
M10 Nut (x1)
B
M6 Nut (x4)
D
J
M6-M10
17mm Wrench(x1)
I
5mm Allen Key(x1)
3
Connecting the Upper Support Pillar to Lower Support Pillar
Step 2 4
4
Upper
Support Pillar x1 x1
x1 x1
3
B
M10 Nut
G
D10.5
Washer
x1
F
D10.5
Plastic Washer
J
M6-M10
Wrench
Step 1-2 Connect the Lower Support Pillar 3 to Tempered Glass7
B
J
G
F
4
3
7
3
I
7
3
5
A
E
Connecting the TV Plate to Upper Support Pillar
1
Step 3 4
x1 x4 x1
TV Plate
1M6-M10
Wrench
J
M6 Nut
D
x2
Cable Clip
8
Select TV Screws
4
Only one screw size fits your TV.
M6M4 M8
D
1
J
1
4
3
Step 4 Mounting the TV Brackets 2to TV
x2 x4 x4
x4 x4 x4
x4
x4
K
D4/D6/D8
Washer x8
M-G
2.5mm Spacer
M-H
10mm Spacer x4
M-I
22mm Spacer
M4x30mm
M-A
Screw M6x15mm
M-B
Screw
M6x35mm
M-C
Screw
M8x20mm
M-D
Screw
2
TV
Bracket
M8x35mm
M-E
Screw
x4
M8x50mm
M-F
Screw
Securing the Cable Clips 8
to Lower Support Pillar 3
8
5
Too Short Too Long Correct Correct
Screw length: Verify adequate thread engagement with screws or screws/spacers
combination. We recommend thread engagement by at least 5 turns.
-Too short will not hold the TV.
-Too long will damage the TV.
Option A (For Flat Back TV)
Option B (For Round Back TV)
Alternate
Spacer
Setups
2
2
M-A / M-C
M-E / M-F
K
M-G to M-I
2
Note: If necessary, the spacers can be used in multi-layer. If the installation fails
after trying various methods, please contact customer service at
2
2
M-B/M-D
K
2
Alternate
Spacer
Setups
(If needed)
M-G/M-H
Option D
6
Spacers may be necessary for 2 holes ONLY.
Option C (For TV with A “Bump”)
Spacers maybe necessary when brackets
interfere with cables or USB.
Alternate
Spacer
Setups
Alternate
Spacer
Setups
2
2
2
2
M-A / M-C
M-E / M-F
K
M-G to M-I
2
M-A / M-C
M-E / M-F
K
M-G to M-I
2
Adusting Angle of TV StandStep 7
Height AdjustmentStep 6
x1
J
Step 5 Securing TV to TV Plate 1
6
Safety Lock x2
6
Fasten the safty locks
7
J
HEAVY! You may need
assistance with this step.
TV brackets are three-height-adjustable.
You can choose the proper height.
The third choice
HEAVY! You may need
assistance with this step.
Insert the safety locks into the
brackets and tighten the screws
until the screws touch the bumps
of the TV plate. Please note, there
is no screw holes in the TV plate.
