PCE Instruments PCE-TG 50 Manual de usuario

PCE Americas Inc.

PCE Instruments UK Ltd.

711 Commerce Way

Units 12/13

Suite 8

Southpoint Business Park

Jupiter

Ensign way

FL-33458

Hampshire / Southampton

USA

United Kingdom, SO31 4RF

From Outside US: +1

From Outside UK: +44

Tel: (561) 320-9162

Tel: (0) 2380 98703 0

Fax: (561) 320-9176

Fax: (0) 2380 98703 9

info@pce-americas.com

info@industrial-needs.com

www.pce-instruments.com/us

www.pce-instruments.com/english

www.industrial-needs.com

Manual

Material Thickness Meter PCE-TG 50

Version 1.0

Date of creation: 03.03.2015

Date of last change: 03.03.2015

Manual

Contents

1 Introduction .............................................................................................................3

2 Safety notes.............................................................................................................3

3 Specification............................................................................................................3

4 System description.................................................................................................4

5 Material selection....................................................................................................4

6 Calibration ...............................................................................................................5

7 Measurement...........................................................................................................5

7.1

Measurement with adjusted velocity speed.................................................................................5

8 Changing the batteries ...........................................................................................5

9 Contact.....................................................................................................................6

9.1

PCE Instruments UK ...................................................................................................................6

9.2

PCE Americas .............................................................................................................................6

Manual

1 Introduction

Thank you for purchasing a thickness gauge from PCE Instruments.

The PCE-TG 50 is a thickness gauge which stands out because of its small dimensions, the low weight

and its comfortable and easy use. You will be able to use it many years due to its robust casing by simply

following this manual. Read the manual carefully and keep it for potential questions occurring in future.

2 Safety notes

Please read this manual carefully and completely before you use the device for the first time. The device

may only be used by qualified personnel and repaired by PCE Instruments personnel. There is no

warranty of damages or injuries caused by non-observance of the manual.

The device may only be used in approved temperature range

The opening of the case should only be done by qualified personnel of the PCE Instruments.

The instrument should never be placed with the user interface (e.g. keyboard side on a table)

You should not make technical changes on the device

The appliance should only be cleaned with a damp cloth / use only pH-neutral cleaner

This user's handbook is published from PCE Instruments without any guarantee.

We expressly point to our general guarantee terms, they can be found in our general terms of business.

If you have any questions please contact PCE Instruments.

3 Specification

Display

4 Digits

Measuring range

1,2 …200 mm

Resolution

0,1 mm

Accuracy

±0.5% ±0.1mm

Sound velocity

500 … 9000 m/s

Power supply

4 x 1,5 V AAA batteries

Operation conditions

Temperature: 0 … +50 °C

Rel. Humidity: < 80 %

Rate of measurement

2 measurements per second

Dimensions

140 x 71 x 32 mm

Data output

RS232

Measurement units

mm / inch (selectable)

Weight

Approximately 160 g (incl. batteries)

Delivery content

1 x PCE- TG 50, 1x transportation box, 1 x

ultrasonic sensor, 1 x manual

Manual

4 System description

Calibration button

Material select button

Ultrasonic sensor mm / inch button

Minus button Calibration standard

Plus button

Display

Sensor connection

Velocity button

Power button

5 Material selection

Push the power button on the device in order to switch it on. After doing so please push material selection

button and the button will either show “cdxx” or “xxxx”. “cd” stands for code and “xx” gives information on

the material number which ranges from 1 to 11. “xxx” is the adjusted velocity speed of the material that is

to be measured.

No.

Code

Material

cd01

Steel

cd02

Cast iron

cd03

Aluminum

cd04

Copper

cd05

Brass

cd06

Zinc

cd07

Quartz glass

cd08

cd09

PVC

cd10

Grey cast iron

cd11

Ductile iron

xxxx

Velocity speed

Push the plus or minus button to choose a material code and apply the chosen code with the material

selection button. The display will now show “0”. When you choose a code without pushing the material

selection button the device will display “0” after a few seconds, too. If you do not accept a certain code

the settings will not be saved. When pushing the plus button when “cd11” is displayed you will get the

adjustment of the velocity speed. When pushing the minus button when “cd01” is displayed you will also

be able to adjust the velocity speed.

It is essential that you choose the material before the first measurement. Otherwise the measured data

might be incorrect.

Manual

6 Calibration

Put some contact paste on the calibration standard and push the calibration button. The display will show

“CAL” now. Now press the sensor on the calibration standard. If the sensor is applied correctly you will

see “((•))” on the display. After that the display will show “CAL” and “5 mm”. If the displayed value is

stable press the calibration button again in order to accept the value and to return to the measuring mode.

You now finished the calibration and the measured value is stored.

7 Measurement

Push the power button to switch on the device and choose your needed unit (mm / inch). Make sure that

the sensor is correctly connected to the device. If that is the case, the device will show “((•))”. Give a bit

of contact paste on the upper side and press the sensor on the material you want to measure. The

measured data will now appear on the display. It is shown as long as a new measurement is made or

until the device is switched off.

7.1

Measurement with adjusted velocity speed

Push the VEL button and the device will show you the last chosen velocity speed. By pushing the plus

and minus buttons you will be able to adjust these. By pressing the button once, the instrument will

change the value by 10 m/s. If a button is pressed for more than four seconds the value will be changed

by 100 m/s.

Put some contact paste on the material you want to measure and press the sensor on it. The measured

data will be displayed.

In case you should not know what material is to be measured take a caliper, measure the thickness on

one side and note the thickness. Also note the velocity speed that is adjusted. Now take the thickness

gauge and change the velocity speed as long as the measured value is the same value that you wrote

down. Now write down the velocity speed for that material. If you are willing to perform additional

measurements you will have to change the velocity speed before those measurements.

8 Changing the batteries

If the voltage is to low, the thickness gauge will show a battery sign on the display. To change the battery

open the battery lid, and replace the old batteries.

Manual

9 Contact

If you have any questions about our range of products or measuring instruments please contact PCE

Instruments.

9.1

PCE Instruments UK

By post:

PCE Instruments UK Ltd.

Units 12/13 Southpoint Business Park

Ensign Way, Southampton

Hampshire

United Kingdom, SO31 4RF

By phone:

Support: 02380 987 035

Sales: 02380 987 030

9.2

PCE Americas

By post:

PCE Americas Inc.

711 Commerce Way

Suite 8

Jupiter

33458 FL

USA

By phone:

Phone: 410-387-7703

Fax: 410-387-7714
