Panasonic CZ-RWRU3 Manual de usuario

Installation Instructions

Infrared Receiver for U

Model No. CZ-RWRU3

CZ-RWRU3W

Part Names ................................................... 2

Supplied accessories .................................. 2

Safety Precautions ...................................... 3

Speciﬁ cations .............................................. 5

Installation Precautions .............................. 6

Wiring ........................................................... 7

Mounting ...................................................... 8

Setting .......................................................... 9

Address Setting ................................................9

Test Operation ........................................... 10

Self-diagnostics table and

detected contents ............................................11

Contents

English

Read through the Installation Instructions before you proceed

with the installation.

In particular, you will need to read under the “Safety

Precautions” on page 3.

W1121-0

2(EN)

Part Names

(1) Light receiving section

Receives signals.

(2) Indication lamp

Indicates operation status.

(3) Emergency operation button

Starts/Stops emergency operation.

Supplied accessories

< >: Number of pieces

Installation Instructions

<1>

Installation Instructions Disc

<1>

Clamper

<1>

(EN)

Safety Precautions

We assume no responsibility for accidents

or damages resulting from methods other

than those described in the installation

instructions or methods without using

speciﬁ ed parts.

Malfunctions that occurred due to the

unauthorised installation methods are not

covered by the product warranty.

 Read the installation instructions supplied

with indoor units as well.

 After the installation is complete,

perform test operation to conﬁ rm that no

abnormality is present.

 When relocating or repairing this receiver,

provide the Installation Instructions to the

servicing personnel.

 Do not clean inside the receiver by users.

Engage authorised dealer or specialist

for cleaning.

WARNING

This symbol refers to a hazard or unsafe

practice which can result in severe personal

injury or death.

CAUTION

This symbol refers to a hazard or unsafe

practice which can result in personal injury or

product or property damage.

WARNING

 Turn oﬀ the circuit breaker of

the units before installation.

 This receiver shall be installed

in accordance with National

Wiring Regulations.

 Connect and ﬁ x the speciﬁ ed

cables for wiring securely.

 Do not allow the connection

to be exposed to the external

force of the cables.

 Select an installation location

which is rigid and strong

enough to support or hold the

receiver, and select a location

for easy maintenance.

 This receiver must not be

modiﬁ ed or disassembled

under any circumstances.

Modiﬁ ed or disassembled

receiver may cause ﬁ re,

electric shock or injury.

Read before installation

This receiver must be installed by the sales dealer or installer.

These instructions are all you need for most installation sites and maintenance conditions.

If you require help for a special problem, contact our sales/service outlet or your certiﬁ ed

dealer for additional instructions.

4(EN)

Safety Precautions

CAUTION

 Do not use the receiver at the

following locations.

• Location where ﬂ ammable

gases, etc. may leak

• Location where corrosive

gases, etc. may leak

• Location with lots of water

or oil droplets (including

machine oil)

• Location where droplets of

organic solvents spread

• Location where acidic or

alkaline solutions or special

sprays are frequently used

 Do not wash with water.

 Do not operate with wet

hands.

NOTICE The English text is the original instructions. Other languages are translation of

the original instructions.

(EN)

Speciﬁ cations

Model No. CZ-RWRU3 / CZ-RWRU3W

Dimensions (H) 29.7 mm × (W) 211.8 mm × (D) 211.8 mm

Weight 160 g

Temperature /

Humidity range

0 °C to 40 °C / 20% to 80% (No condensation)

*Indoor use only.

Power Source DC16 V (supplied from indoor unit)

6(EN)

Installation Precautions

The receiver uses a very weak infrared light for its signal, which can result in the signal not being

received because of the following inﬂ uences, so take care in where the indoor unit is installed.

• Inverter or rapid-start type ﬂ uorescent lights (Models without glow lamps)

• Plasma display or LCD televisions

• Direct sunlight or other sources of bright light

Do not bundle together with the power source wiring or store in the same metal tube. Operation

error may occur.

Be careful not to connect cables to other terminals of indoor units (e.g. power source wiring

terminal). Malfunction may occur.

Avoid the following locations for installation.

• Location where condensation occurs

• Location where voltage ﬂ uctuation frequently occurs

• Location where there is a machine producing electromagnetic radiation

(EN)

Wiring

Connect the wires from the receiver to the terminals for RC wiring on the indoor unit.

Wiring Diagram

Infrared Receiver for UIndoor unit

CN001

2P white

Terminals for RC wiring

RC wiring

• No polarity

Installation when setting Main/Sub for the remote controller and the receiver

It is possible to operate one or more indoor units using two remote controllers.

After installation, set one to [Main] and the other to [Sub].

When using the infrared remote controller and the wired remote controller in combination, set the

wired remote controller to [Main].

R1 R2

12 CN001

R1 R2 R1 R2 R1 R2

12 CN001

Indoor unitIndoor unit Indoor unit Indoor unit

Terminals for

RC wiring

• No polarity

Receiver

(Sub)

Wired RC

(Main)

Receiver

(Sub)

Wired RC

(Main)

 Using 1 indoor unit  Using more than 1 indoor unit

Note

The receiver can be connected to any indoor unit for operation.

Multiple infrared remote controllers cannot be used simultaneously for a single indoor unit.

Wiring connected via remote controllers is prohibited.

Also see the “Installation Instructions” supplied with the indoor unit or wired remote controller when

performing remote control with the main and sub remote controllers or group-controlling.

8(EN)

Mounting

1 Remove the air inlet grille.

Installation position for

receiver (Fig. A)

Indoor unit electric

component box

Air Inlet grille

Ceiling panel

2 Remove the screw ﬁ xing the corner cover.

Screw

Corner cover

3 Place a hand on both the right and left convex

parts of the corner cover to remove it.

Convex partCeiling panel

Corner cover

4 Hang the string of the receiver on the pin of

the ceiling panel.

Receiver

String

Ceiling panel

5 Pass the wiring from the receiver section into

the slit.

For more wiring information, see the section

“Wiring”.

6 Fix the wiring with the clamper (supplied) while

leaving enough length of wiring to remove the

receiver.

●When attaching the ﬁ lter chamber, cut the

clamper (a), and attach the receiver.

Slit

Fix with the clamper (supplied).

(a) Cut this clamper.

7 Fit the receiver to the ceiling panel so the

5 claws are properly set, and ﬁ x it with the

removed screw.

●Make sure the wire is not caught.

●Refer to the installation instructions supplied

with the panel.

The receiver can be installed only on the corner shown in Fig. A. Consider the direction where the

panel is attached to the indoor unit.

(EN)

Setting

Before installing the receiver, check the settings of the receiver address switches.

Remove the cover from the receiver when performing the settings.

123 4

Screw

Cover

Receiver

Main/Sub switch (4)*

OFF: Main

ON: Sub

Factory default: OFF (1 – 4)

Address switch (1 – 3)

* When using the infrared remote controller and the wired remote controller in combination, set the

wired remote controller to [Main].

Address Setting

When more than 1 receiver is installed in the same room, setting addresses prevents interference.

For how to change addresses of infrared remote controllers, see the operating instructions of

infrared remote controllers.

Infrared remote

controller

address display

Address Address Address Address Address Address Address ON/OFF

States

ALL123456

Infrared

receiver

address switch

positions

Receiving is

possible at

all address

positions.

1234 1234 1234 1234 1234 1234 OFF ON

10 (EN)

Test Operation

Preparation: Turn on the circuit breaker of units and then turn the power on. After the power is turned

on, infrared remote controller operation is ignored for approx. 1 minute because setting

is being made. This is not malfunction. (Contents received while setting are disabled.)

1 Press and hold the emergency operation button for 10 seconds.

2 The indication lamps (OPERATION, TIMER, STANDBY) blink during test operation.

3 To ﬁ nish test operation, press and hold the emergency operation button for 10 seconds.

Attention

Do not use this mode for purposes other than the test operation.

(To prevent overload of the units)

Read the installation instructions supplied with the units.

The test operation can be performed in Heat or Cool mode.

Temperature cannot be changed.

The test operation mode is automatically turned oﬀ in 60 minutes.

(To prevent continuous test operation)

Outdoor units do not operate for approx. 3 minutes after the power is turned on or operation is

stopped.
