Panasonic KX-UT113 Manual de usuario

Getting Started

SIP Phone

KX-UT113/KX-UT123

Model No. KX-UT133/KX-UT136

Document Version: 2011-10

English/

Nederlands

Deutsch/

Svenska

Español/

Dansk

Français/

Português

Italiano

Thank you for purchasing this Panasonic product.

Please read this manual carefully before using this product and save this manual

for future use.

Note

• In this manual, the sufx of each model number (e.g., KX-UT113NE) is omitted

unless necessary

Outline

This manual briey describes basic information about the installation of the unit.

Related Documentation

Operating Instructions

Describes information about the installation and operation of the unit.

Administrator Guide

Describes information about the programming and maintenance of the unit.

These manuals and supporting information are provided on the Panasonic Web

site at:

https://panasonic.net/cns/pcc/support/sipphone/

Note

• If the unit is connected to a Panasonic KX-NS1000 PBX, refer to the

documentation of the KX-NS1000 for information about the operation,

programming, and maintenance of the unit.

For details, consult your dealer.

Other Information

Open Source Software Notice

Parts of this product use open source software. For details about the open source

software, see the Operating Instructions.

Trademarks

• Plantronics is a trademark or registered trademark of Plantronics, Inc.

For Your Safety

To reduce the risk of injury, loss of life, electric shock, re, malfunction, and damage

to equipment or property, always observe the following safety precautions.

Explanation of symbols

The following symbols are used to classify and describe the level of hazard and

injury caused when the denotation is disregarded and improper use is performed.

WARNING Denotes a potential hazard that could result

in serious injury or death.

CAUTION Denotes a hazard that could result in minor

injury or damage to the unit or other equip-

ment.

The following symbols are used to classify and describe the type of instructions to be

observed.

This symbol is used to alert users to a specic operating procedure that

must not be performed.

This symbol is used to alert users to a specic operating procedure that

must be followed in order to operate the unit safely.

WARNING

General Safety

Do not disassemble this unit. Dangerous electrical shock could result.

The unit must only be disassembled and repaired by qualied service

technicians.

Never attempt to insert wires, pins, etc. into the vents or other holes of

this unit.

To prevent possible re or electric shock, do not expose this unit to rain or

moisture.

For Your Safety

Do not splash water on the AC adaptor or the power cord, nor get them

wet. Doing so can result in re, electric shock, or injury. If they do get wet,

immediately disconnect the AC adaptor and power cord, and contact an

authorised service centre.

Do not touch the AC adaptor for extended periods of time. Doing so can

lead to low-degree burns.

Unplug this unit from the AC outlet and have the unit serviced by qualied

service personnel in the following cases:

A. When the power supply cord or plug is damaged or frayed.

B. If liquid has been spilled on the unit.

C. If the unit has been exposed to rain or water.

D. If the unit does not work normally by following the manual. Adjust only

controls covered by the manual. Improper adjustment may require

repair by an authorised service centre.

E. If the unit has been dropped, or damaged.

F. If the unit's performance deteriorates.

If damage to the unit exposes any internal parts, immediately disconnect

the cable or cord. If the power is supplied from the network to the SIP

Phone [Power-over-Ethernet], disconnect the Ethernet cables. Otherwise,

disconnect the AC adaptor cord. Then return this unit to an authorised

service centre.

This handset earpiece is magnetised and may retain small ferrous

objects.

The use of excessive sound volume through earphones, headphones, or

headsets may cause hearing loss.

Disconnect this unit from power outlet/the Ethernet cables if it emits

smoke, an abnormal smell, or makes unusual noise. These conditions can

cause re or electric shock. Conrm that smoke has stopped and contact

an authorised service centre.

Installation

Do not make power connections that exceed the ratings for the AC outlet

or power equipment. If the power rating of a surge protector, etc. is

exceeded, it can cause a re due to heat buildup.

Do not bundle up the AC adaptor cord. The cord may become damaged,

which can lead to a re, electric shock, or electric short.

For Your Safety

The unit should only be connected to a power supply of the type as shown

on the label on the unit.

Completely insert the AC adaptor into the AC outlet. Failure to do so may

cause electric shock and/or excessive heat resulting in a re.

Placement

Care should be taken so that objects do not fall onto, and liquids are not

spilled into, the unit. Do not subject this unit to excessive smoke, dust,

moisture, mechanical vibration, shock, or direct sunlight.

Do not place heavy objects on top of this unit.

Place this unit on a at surface.

Allow 10 cm clearance around the unit for proper ventilation.

Wall Mounting

Make sure that the wall that the unit will be attached to is strong enough

to support the unit (approx. 1.09 kg). If not, it is necessary for the wall to

be reinforced.

Only use the optional wall mount kit with the unit. The wall mount kit

includes the necessary screws, washers, and wall mounting adaptor.

When driving the screws into the wall, be careful to avoid touching any

metal laths, wire laths or metal plates in the wall.

When this unit is no longer in use, make sure to detach it from the wall.

For Your Safety

CAUTION

Keep the unit away from heating appliances and devices that generate

electrical noise, such as uorescent lamps, motors and televisions. These

noise sources can interfere with the performance of the unit. It also should

not be placed in rooms where the temperature is less than 0 ºC or greater

than 40 ºC.

Wipe the unit with a soft cloth. Do not clean the unit with abrasive

powders or with chemical agents such as benzine or thinner.

The handset hook poses a choking hazard. Keep the handset hook out of

reach of children.

When left unused for a long period of time, disconnect the unit from

the AC outlet. When the unit receives power from a PoE power supply,

disconnect the Ethernet cables.

When the unit is mounted on a wall, make sure the cables are securely

fastened to the wall.

Notice

• If the unit does not operate properly, disconnect the AC adaptor cord and

Ethernet cables and then connect again.

• If you are having problems making calls, disconnect the Ethernet cables

and connect a known working SIP Phone. If the known working SIP Phone

operates properly, have the defective SIP Phone repaired by an authorised

service centre. If the known working SIP Phone does not operate properly,

check the SIP server and the Ethernet cables.

• Under power failure conditions, the SIP Phone may not operate. Please

ensure that a separate telephone, not dependent on local power, is available

for use in remote sites in case of emergency.

• For information regarding network setup of the SIP Phone such as IP

addresses, please see the Operating Instructions.

• If an error message is shown on your display, consult your phone system

dealer or the network administrator.

• Use only the correct Panasonic handset.

Important Safety Instructions

When using this unit, basic safety precautions should always be followed to reduce

the risk of re, electric shock and injury to persons, including the following:

1. Do not use the unit near water, for example, near a bathtub, washbowl, kitchen

sink, or laundry tub, in a wet basement, or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm.

There may be a remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

SAVE THESE INSTRUCTIONS

For information of Compliance with EU relevant Regulatory Directives,

Contact to Authorised Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany

Accessory Information

Included Accessories

Handset (1) Handset Cord (1)

Stand (1)

For KX-UT113/KX-UT123: For KX-UT133/KX-UT136:

Note

• The illustrations may differ from the appearance of the actual product.

Optional Accessories

AC Adaptor*1KX-A239CE (PQLV206CE)

Wall Mount Kit KX-A432X (for KX-UT113/KX-UT123)

KX-A433X (for KX-UT133/KX-UT136)

*1 To order an optional AC adaptor, please order using the "KX-A239" model

number.

Location of Controls

Front View

For KX-UT136:

BCD

KLM NOP QR

HG I J

Location of Controls

For KX-UT133:

BCD

KLM NO P QR

HG I J
