UM10601

LPC800 User manual

Rev. 1.0 — 7 November 2012 Preliminary user manual

Document information

Info Content

Keywords ARM Cortex M0+, LPC800, USART, I2C, LPC810M021FN8,

LPC811M001FDH16, LPC812M101FDH16, LPC812M101FD20,

LPC812M101FDH20

Abstract LPC800 Preliminary user manual

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 2 of 313

Contact information

For more information, please visit: http://www.nxp.com

For sales office addresses, please send an email to: [email protected]

NXP Semiconductors UM10601

LPC800 User manual

Revision history

Rev Date Description

1 20121107 Preliminary LPC800 user manual

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 3 of 313

1.1 Introduction

The LPC800 are an ARM Cortex-M0+ based, low-cost 32-bit MCU family operating at

CPU frequencies of up to 30 MHz. The UM10601 support up to 16 kB of flash memory

and 4 kB of SRAM.

The peripheral complement of the UM10601 includes a CRC engine, one I2C-bus

interface, up to three USARTs, up to two SPI interfaces, one multi-rate timer, self wake-up

timer, and state-configurable timer, one comparator, function-configurable I/O ports

through a switch matrix, an input pattern match engine, and up to 18 general-purpose I/O

pins.

1.2 Features

•System:

–ARM Cortex-M0+ processor, running at frequencies of up to 30 MHz.

–ARM Cortex-M0+ built-in Nested Vectored Interrupt Controller (NVIC).

–Micro Trace Buffer

–System tick timer

•Memory:

–16 kB on-chip flash programming memory.

–4 kB SRAM.

–In-System Programming (ISP) and In-Application Programming (IAP) via on-chip

boot loader software.

•Boot ROM API support:

–UART drivers

–I2C drivers

–Power profiles

–IAP/ISP

•Digital peripherals:

–High-speed GPIO interface connected to the ARM Cortex-M0+ I/O port with up to

18 General Purpose I/O (GPIO) pins with configurable pull-up/pull-down resistors.

–Pin interrupt generation capability with boolean pattern-matching feature onup to

eightselectable GPIO inputs.

–Switch matrix for flexible configuration of each I/O pin function.

–State Configurable Timer (SCT) with input and output functions (including capture

and match) assigned to pins through the switch matrix.

–Multiple-channel multi-rate timer for repetitive interrupt generation at up to four

programmable, fixed rates.

–Wake-up timer for self-timed wake-up from reduced power modes.

UM10601

Chapter 1: LPC800 Introductory information

Rev. 1.0 — 7 November 2012 Preliminary user manual

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 4 of 313

NXP Semiconductors UM10601

Chapter 1: LPC800 Introductory information

–CRC engine.

–Windowed Watchdog timer

•Analog peripherals:

–Comparator with external voltage reference with pin functions assigned through

the switch matrix.

–Internal reference voltage.

•Serial interfaces:

–Three UART interfaces with pin functions assigned through the switch matrix.

–Two SPI controllers with pin functions assigned through the switch matrix.

–One I2C-bus interface with open-drain full I2C spec fast Modeplus.

•Clock generation:

–12 MHz internal RC oscillator trimmed to 1 % accuracy that can optionally be used

as a system clock.

–Crystal oscillator with an operating range of 1 MHz to 25 MHz.

–Programmable watchdog oscillator with a frequency range of 9.4 kHz to 2.3 MHz.

–PLL allows CPU operation up to the maximum CPU rate without the need for a

high-frequency crystal. May be run from the external clock input (CLKIN), the

system oscillator, or the internal RC oscillator.

•Power control:

–Integrated PMU (Power Management Unit) to minimize power consumption.

–Reduced power modes (Sleep, deep-sleep, power-down, deep power-down).

–Power-On Reset (POR).

–Brownout detect.

•Unique device serial number for identification.

•Single power supply.

•Available in a SO20 package, TSSOP20 package, TSSOP16, and DIP8 package.

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 5 of 313

NXP Semiconductors UM10601

Chapter 1: LPC800 Introductory information

1.3 Ordering information

Table 1. Ordering information

Type number Package

Name Description Version

LPC810M021FN8 DIP8 plastic dual in-line package; 8 leads (300 mil) SOT097-2

LPC811M001FDH16 TSSOP16 plastic thin shrink small outline package; 16 leads; body width 4.4 mm SOT403-1

LPC812M101FDH16 TSSOP16 plastic thin shrink small outline package; 16 leads; body width 4.4 mm SOT403-1

LPC812M101FD20 SO20 plastic small outline package; 20 leads; body width 7.5 mm SOT163-1

LPC812M101FDH20 TSSOP20 plastic thin shrink small outline package; 20 leads; body width 4.4 mm SOT360-1

Table 2. Ordering options

Type number Flash/kB SRAM/kB USART I2CSPI Comparator GPIO Package

LPC810M021FN8 4 1 2 1 1 1 6 DIP8

LPC811M001FDH16 8 2 2 1 1 1 14 TSSOP16

LPC812M101FDH16 16 4 3 1 2 1 14 TSSOP16

LPC812M101FD20 16 4 2 1 1 1 18 SO20

LPC812M101FDH20 16 4 3 1 2 1 18 TSSOP20

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 6 of 313

NXP Semiconductors UM10601

Chapter 1: LPC800 Introductory information

1.4 Block diagram

Fig 1. LPC800 block diagram

65$0

N%

$50

&257(;0

7(67'(%8*

,17(5)$&(

)/$6+

N%

+,*+63(('

*3,2

$+%72$3%

%5,'*(

&/2&.

*(1(5$7,21

32:(5&21752/

6 67(0

)81&7,216

5(6(7&/.,1

FORFNVDQG

FRQWUROV

/3&

DDD

VODYH

VODYH VODYH

520

N%

VODYH

&5&

VODYH

3,1,17(558376

3$77(510$7&+

$+%/,7(%86

,5&

:'2VF

%2'

325

63,

86$57

6'$

6&/

&7,1B>@

&7287B>@

[

3,2

[

::'7

,2&21

308

6(/)

:$.(837,0(5

08/7,5$7(7,0(5

63,

,&%86

6&7

6:,7&+

0$75,;

&203$5$725

;7$/,1

;7$/287

$&03B2

6 6&21

5;'&76

7;'576

$&03B,

9''&03

6&.66(/

0,62026,

6&.66(/

0,62026,

$/:$ 62132:(5'20$,1

;7$/

6&/.

86$57

5;'&76

7;'576

6&/.

86$57

5;'&76

7;'576

6&/.

&/.287

6:&/.6:'

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 7 of 313

NXP Semiconductors UM10601

Chapter 1: LPC800 Introductory information

1.5 General description

1.5.1 ARM Cortex-M0+ core configuration

The ARM Cortex-M0+ core runs at an operating frequency of up to 30 MHz. Integrated in

the core are the NVIC and Serial Wire Debug with four breakpoints and two watchpoints.

The ARM Cortex-M0+ core supports a single-cycle I/O enabled port (IOP) for fast GPIO

access at address 0xA000 0000.

The core includes a single-cycle multiplier and a system tick timer (SysTick).

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 8 of 313

2.1 How to read this chapter

The memory mapping is identical for all LPC800 parts. Different LPC800 parts support

different flash memory sizes.

2.2 General description

The LPC800 incorporates several distinct memory regions. Figure 2 shows the overall

map of the entire address space from the user program viewpoint following reset.

The APB peripheral area is 512 kB in size and is divided to allow for up to 32 peripherals.

Each peripheral is allocated 16 kB of space simplifying the address decoding.

The registers incorporated into the ARM Cortex-M0+ core, such as NVIC, SysTick, and

sleep mode control, are located on the private peripheral bus.

The GPIO port and pin interrupt/pattern match registers are accessed by the ARM

Cortex-M0+ single-cycle I/O enabled port (IOP).

UM10601

Chapter 2: LPC800 Memory mapping

Rev. 1.0 — 7 November 2012 Preliminary user manual

DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 9 of 313

NXP Semiconductors UM10601

Chapter 2: LPC800 Memory mapping

2.2.1 Memory mapping

2.2.2 Micro Trace Buffer (MTB)

The LPC800 supports the ARM Cortex-M0+ Micro Trace Buffer.

The private peripheral bus includes the ARM Cortex-M0+ peripherals such as the NVIC, SysTick, and the core control registers.

Fig 2. LPC800 Memory mapping

$3%SHULSKHUDOV

[

[

[&

[

[

[

[

[

[&

[

[

[

[&

[

[

[&

[

[

[

[

[&

[

[

::'7

057

VHOIZDNHXSWLPHU

308

UHVHUYHG

DQDORJFRPSDUDWRU

[&

UHVHUYHG

[

[































UHVHUYHG

[

*%

*%

*%

*%

[

[)))

[)))

[

[

[

[))))))))

UHVHUYHG

[

[

$3%SHULSKHUDOV

[

[$

[$

&5&

6&7

*3,2

[$

SLQLQWHUUXSWVSDWWHUQPDWFK

[

N%65$0/3&

[

N%65$0/3&

[

N%65$0/3&

[

[

N%07%

/3&

[

[

[

N%RQFKLSIODVK/3&

N%RQFKLSIODVK/3&

N%RQFKLSIODVK/3&

N%ERRW520

[

[&

DFWLYHLQWHUUXSWYHFWRUV

DDD

UHVHUYHG

IODVKFRQWUROOHU

63,

VZLWFKPDWUL[

,2&21

6 6&21

[





 63,

86$57

[

86$57

[&

86$57

[



[(

[(

SULYDWHSHULSKHUDOEXV

,&











UHVHUYHG









DRAFT

DRAFT DRAFT DR

DRAFT DRAFT DRAFT DRAF

DRAFT DRAFT DRAFT DRAFT DRAFT D

DRAFT DRAFT DRAFT DRAFT DRAFT DRAFT DRA

Preliminary user manual Rev. 1.0 — 7 November 2012 10 of 313

3.1 How to read this chapter

The NVIC is identical on all LPC800 parts.

The SPI1 and USART2 interrupts are implemented on parts LPC812M101FDH20 and

LPC812M101FDH16 only.

3.2 Features

•Nested Vectored Interrupt Controller that is an integral part of the ARM Cortex-M0+.

•Tightly coupled interrupt controller provides low interrupt latency.

•Controls system exceptions and peripheral interrupts.

•The NVIC supports 32 vectored interrupts.

•Four programmable interrupt priority levels with hardware priority level masking.

•Software interrupt generation using the ARM exceptions SVCall and PendSV.

•Support for NMI.

•ARM Cortex M0+ Vector table offset register VTOR implemented.

3.3 General description

The Nested Vectored Interrupt Controller (NVIC) is an integral part of the Cortex-M0+. The

tight coupling to the CPU allows for low interrupt latency and efficient processing of late

arriving interrupts.

3.3.1 Interrupt sources

Tabl e 3 lists the interrupt sources for each peripheral function. Each peripheral device

may have one or more interrupt lines to the Vectored Interrupt Controller. Each line may

represent more than one interrupt source. The interrupt number does not imply any

interrupt priority.

See Ref. 1 for a detailed description of the NVIC and the NVIC register description.

UM10601

Chapter 3: LPC800 Nested Vectored Interrupt Controller

(NVIC)

Rev. 1.0 — 7 November 2012 Preliminary user manual

Table 3. Connection of interrupt sources to the NVIC

Interrupt

number Name Description Flags

0 SPI0_IRQ SPI0 interrupt See Table 192 “SPI Interrupt Enable read and Set register

(INTENSET, addresses 0x4005 800C (SPI0) , 0x4005 C00C

(SPI1)) bit description”.

1 SPI1_IRQ SPI1 interrupt Same as SPI0_IRQ

2 - Reserved -

Tabla de contenidos

Otros manuales de Microcontrolador de NXP Semiconductors

NXP Semiconductors

NXP Semiconductors S32R372141EVB Manual de usuario

NXP Semiconductors

NXP Semiconductors LPC546 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors Freescale Freedom Manual de usuario

NXP Semiconductors

NXP Semiconductors S12ZVML-MINIKIT Manual de usuario

NXP Semiconductors

NXP Semiconductors S32K324 Manual de usuario

NXP Semiconductors

NXP Semiconductors KL25 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors NTAG I2C plus Manual de usuario

NXP Semiconductors

NXP Semiconductors i.MX 8M Manual de usuario

NXP Semiconductors

NXP Semiconductors S12ZVMAEVB Manual de usuario

NXP Semiconductors

NXP Semiconductors FRDM-KL28Z Manual de usuario

NXP Semiconductors

NXP Semiconductors ADC1610S Series Manual de usuario

NXP Semiconductors

NXP Semiconductors SE050 Instrucciones de instalación y funcionamiento

NXP Semiconductors

NXP Semiconductors LPC1549 Manual de usuario

NXP Semiconductors

NXP Semiconductors EasyEVSE EV Manual de usuario

NXP Semiconductors

NXP Semiconductors LPC29 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors P89LPC952 Manual de usuario

NXP Semiconductors

NXP Semiconductors LPC11U3x Manual de usuario

NXP Semiconductors

NXP Semiconductors S32G-VNP-GLDBOX Manual de usuario

NXP Semiconductors

NXP Semiconductors FRDM-K32L2B3 Manual de usuario

NXP Semiconductors

NXP Semiconductors MPC574 P Series Manual de usuario

NXP Semiconductors

NXP Semiconductors NTAG I2C plus Manual de uso y cuidado

NXP Semiconductors

NXP Semiconductors LPC21 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors K53 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors MC9S12G Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
