NXP Semiconductors UM11733 Manual de usuario

UM11733

Hardware user manual for FRDM665CANFDEVB

Rev. 1 — 25 July 2022 User manual

Document information

Information Content

Keywords MC33665A, CAN FD, BMS gateway IC

Abstract Hardware user manual for FRDM665CANFDEVB, which can support both

CAN and CAN FD communication to microcontroller on battery control unit

(BCU).

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

Rev Date Description

1 20220725 initial version

Revision history

User manual Rev. 1 — 25 July 2022

2 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

IMPORTANT NOTICE

For engineering development or evaluation purposes only

NXP provides the product under the following conditions:

This evaluation kit is for use of ENGINEERING DEVELOPMENT OR

EVALUATION PURPOSES ONLY. It is provided as a sample IC pre-soldere

d to a printed-circuit board to make it easier to access inputs, outputs

and supply terminals. This evaluation board may be used with any

development system or other source of I/O signals by connecting it to the

host MCU computer board via off-the-shelf cables. This evaluation board

is not a Reference Design and is not intended to represent a final design

recommendation for any particular application. Final device in an application

heavily depends on proper printed-circuit board layout and heat sinking

design as well as attention to supply filtering, transient suppression, and I/O

signal quality.

The product provided may not be complete in terms of required design,

marketing, and or manufacturing related protective considerations, including

product safety measures typically found in the end device incorporating the

product. Due to the open construction of the product, it is the responsibility of

the user to take all appropriate precautions for electric discharge. In order to

minimize risks associated with the customers’ applications, adequate design

and operating safeguards must be provided by the customer to minimize

inherent or procedural hazards. For any safety concerns, contact NXP sales

and technical support services.

User manual Rev. 1 — 25 July 2022

3 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

1 Introduction

The NXP analog product development boards provide an easy-to-use platform for

evaluating NXP products. The boards support a range of analog, mixed-signal, and

power solutions. They incorporate monolithic integrated circuits and system-in-package

devices that use proven high-volume technology. NXP products offer longer battery life, a

smaller form factor, reduced component counts, lower cost, and improved performance in

powering state-of-the-art systems.

2 Finding kit resources and information on the NXP web site

NXP Semiconductors provides online resources for this evaluation board and its

supported device(s) on http://www.nxp.com.

The information page for the FRDM665CANFDEVB evaluation board is at http://

www.nxp.com/FRDM665CANFDEVB. The information page provides overview

information, documentation, software and tools, parametrics, ordering information and

a Getting Started tab. The Getting Started tab provides quick-reference information

applicable to using the FRDM665CANFDEVB evaluation board, including the

downloadable assets referenced in this document.

3 Getting ready

Working with the FRDM665CANFDEVB evaluation board requires the kit contents,

additional hardware, and a Windows PC workstation with installed software.

3.1 Kit contents

The FRDM665CANFDEVB kit includes:

•MC33665A CAN FD EVB, CAN or CAN FD to four transformer physical layer (TPL)

interface EVB

•One TPL daisy chain cable; two-wire twisted-pair daisy chain interface cable

•One power cable, 4-pin socket

•Quick start guide

3.2 Additional hardware

In addition to the kit contents, the following hardware is necessary or beneficial:

•External dual power supply 8 V to 16 V/2 A (optional)

•EVBs of battery cell controller (BCC) devices from NXP

•14-cell battery pack or a battery emulator, such as BATT-14CEMULATOR

4 Getting to know the hardware

4.1 Kit overview

The FRDM665CANFDEVB serves as a hardware evaluation tool in support of the

MC33665A device of NXP. The MC33665A is a gateway router that can route TPL

messages from the microcontroller to four different TPL ports. It is designed for use in

both automotive and industrial applications. The device can route both TPL2 and TPL3

User manual Rev. 1 — 25 July 2022

4 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

messages. FRDM665CANFDEVB is an ideal board for rapid prototyping of MC33665A

for CAN FD interface to MCU.

FRDM665CANFDEVB supports both classical CAN or CAN FD. Differential

communication to daisy chain devices can be established with four different ports.

4.2 Board features

The main features of FRDM665CANFDEVB are:

•CAN and CAN FD

•Onboard transformer isolation for TPL communication to BCC devices

•Configurable VIO voltage

•Configurable VDD5V from internal and external supply

•DIP switch for configuring the arbitration baud rate and CAN ID of MC33665A

•Reset switch for the device and board

•LED display for the status of power

•Connectors for external interface to general-purpose input/output (GPIO) and I2C-bus

4.3 Block diagram

aaa-044810

CAN TX

REQUEST

CAN

TRANSCEIVER

VIO(VDDIO)

CFG0, CFG1

ID0_STB_OD, ID1, ID2, ID3

DIP switch

3V3LDO

J13 J8

SW1

D12

CAN RX

RESPONSE

TPL

PORT 0

LDO

MC33665A

POWER MANAGEMENT

GPIO, CONFIG AND

STATUS PINS

POR

CAN

TPL

PORT 1

TPL

PORT 2

TPL

PORT 3

reset

switch

PORT 3

VBAT

KL30/

12 V/T30

VDD5V VREG

VDDC/VDDD

VDD5V

VREG

EXT5V

external interface

for GPIO and

status signals

Figure 1. FRDM665CANFDEVB block diagram

User manual Rev. 1 — 25 July 2022

5 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

4.4 Board description

The FRDM665CANFDEVB allows the user to prototype and test all functions of the

MC33665A gateway router with CAN or CAN FD communication.

CAN or CAN FD communication can be established with MC33665A via sub-D9

connector. In addition to sub-D9 CAN connector, same signals of CANH and CANL are

available in both power and CAN connector J6 and CANEVB interface J10. TJA1443 is

the CAN transceiver used for FRDM665CANFDEVB.

12 V (> 5 W) DC power supply can be connected to J6. VDD5V selection and VIO

selection have no influence in FRDM665CANFDEVB as there is a constant 12 V power

supply and there is no direct microcontroller to select VIO. CAN ID can be selected by

setting the position in DIP switch SW2. Take care to set the position of DIP switches

(SW2) appropriately to configure ID and CAN arbitration baud rates to MC33665A.

External 5 V can be connected to bypass the VREG circuit of MC33665A. Take care in

selecting the appropriate jumper J8 to power the VDD5V.

Connector J1 gives the option to access the GPIO and I2C pins of MC33665A.

Contact the NXP engineering team for using TPL autowake function in

FRDM665CANFDEVB.

Figure 2. CAN FD EVB description

Power configuration of the board can be reflected by LEDs populated on board. LEDs

glowing on board reflect the right power interface connected to FRDM665CANFDEVB.

LED VBAT 12 V External 5 V

D13 - red X -

D14 - green X X

D15 - green X X

Table 1. Power status LEDs

User manual Rev. 1 — 25 July 2022

6 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

LED VBAT 12 V External 5 V

D16 - red X -

Table 1. Power status LEDs...continued

4.5 Connectors

FRDM665CANFDEVB has multiple connectors for interfacing to MCU, internal GPIO,

and external BCC devices.

Figure 3. FRDM665CANFDEVB connectors

Pin configuration of connectors is shown in Table 2 to Table 8.

Pin number Connection Description

1 VBAT connection to 12 V

2 CANH CANH interface for TJA1443

3 CANL CANL interface for TJA1443

4 GND ground connection for MC33665A and interface boards

Table 2. Power and CAN connector - J6

Pin number Connection Description

1 CANH CANH interface for TJA1443

2 CANL CANL interface for TJA1443

3 GND ground connection for MC33665A and interface boards

4 - no connection

Table 3. CANEVB connector - J10

User manual Rev. 1 — 25 July 2022

7 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

Pin number Connection Description

1 GPIO0 interface to GPIO0 or INT0 for MC33665A

2 GPIO1 interface to GPIO1 or INT1 for MC33665A

3 GPIO2 interface to GPIO2 or INT2 for MC33665A

4 GPIO3 interface to GPIO3 or INT3 for MC33665A

5 GPIO4 interface to GPIO4 or I2C-bus in MC33665A

6 GPIO5 interface to GPIO5 or I2C-bus in MC33665A

7 GPIO6 interface to GPIO6 or SYNC in MC33665A

8 GPIO7 interface to GPIO7 or HOLD in MC33665A

9 VSS/GND ground

10 VDD5V 5 V supply line

11 VSS/GND ground

12 VIO VIO interface for MC33665A

13 - not connected

14 - not connected

15 NC-CAN_TXD populate R6 to connect CAN_TXD

16 NC-CAN_RXD populate R7 to connect CAN_RXD

17 STB_N_OUT inverted standby signal from MC33665A

18 STB_OUT standby signal from MC33665A

19 RESET reset signal for MC33665A

20 VDD5V 5 V supply line

Table 4. GPIO and interface - J1

Pin number Connection Description

1 EXT5V external 5 V supply

2 VSS/GND ground

Table 5. External 5 V - J11

Pin number Connection Description

1-2 VREG-VDD5V Connection from VREG generated by internal low dropout (LDO) connection to

VDD5V for MC33665A and interface circuits. Note: Default connection.

2-3 EXT5V-VDD5V External 5 V supply can be connected to VDD5V to MC33665A and interface circuits.

Table 6. VDD5V jumper - J8

Pin number Connection Description

1-2 VREG-VIO connect VREG (5 V) generated by internal LDO of MC33665A to VDDIO/VIO of

MC33665A and interface circuit. Note: Default connection.

Table 7. VIO jumper - J13

User manual Rev. 1 — 25 July 2022

8 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

Pin number Connection Description

2-3 3V3LDO-VIO connect constant 3.3 V generated by external LDO to VIO

Table 7. VIO jumper - J13...continued

Pin number Connection Description

2 CANL CANL interface for TJA1443

3 VSS ground connection for MC33665A and interface boards

7 CANH CANH interface for TJA1443

Others - not connected

Table 8. Sub-D9 CAN connector - J15

4.6 Schematic, board layout and bill of materials

The schematic, board layout and bill of materials for the FRDM665CANFDEVB

evaluation board are available at http://www.nxp.com/FRDM665CANFDEVB

5 Configuring the hardware

FRDM665CANFDEVB can be configured as stacked board to S32K344EVB.

5.1 CAN FD interface

FRDM665CANFDEVB can be connected to a PC/laptop or other ECUs with

power and CAN cable or connector. 12 V supply line can be used to power the

FRDM665CANFDEVB, female sub-D9 connector can be interfaced to relevant CAN tool

or ECU. SW2 can be used to configure the CAN ID for MC33665A. CFG pins can also be

configured to set the arbitration speed for MC33665A. Press SW1 button (RST switch)

after changing any settings on SW2 (ID and CFG). Ensure the settings on J8 for VDD5V

and J13 for VIO selection are appropriate for power supplied to the board. CANEVB

interface J10 can be used for direct interface with S32K344EVB for CAN or CAN FD.

Figure 4. CAN FD EVB interface

User manual Rev. 1 — 25 July 2022

9 / 13

NXP Semiconductors UM11733

Hardware user manual for FRDM665CANFDEVB

6 Available accessories

Part number Description

FRDM33772CSPEVB evaluation board for MC33772C with SPI communication

RD33771CDSTEVB evaluation board for MC33771C BCC with isolated daisy chain communication

BATT-14EXTENDER battery emulator extender

BATT-14CEMULATOR 14-cell battery pack to supply MC33771C EVBs

BATT-TPLCABLE20 TPL, two-wire, twisted, 20 cm long cable

BATT-TPLCABLE50 TPL, two-wire, twisted, 50 cm long cable

BATT-14CTCABLE25 cell terminal (CT) cable, 14 cells, 25 cm long

Table 9. Accessories

User manual Rev. 1 — 25 July 2022

10 / 13

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de NXP Semiconductors

NXP Semiconductors

NXP Semiconductors LPC1102 Manual de usuario

NXP Semiconductors

NXP Semiconductors Freescale 56800TDC Manual de usuario

NXP Semiconductors

NXP Semiconductors JN517x-DK005 Manual de usuario

NXP Semiconductors

NXP Semiconductors S32R27 Guía

NXP Semiconductors

NXP Semiconductors PN7462 series Manual de usuario

NXP Semiconductors

NXP Semiconductors EdgeLock A5000 Instrucciones de instalación y funcionamiento

NXP Semiconductors

NXP Semiconductors MC68HC16Z1 Manual de usuario

NXP Semiconductors

NXP Semiconductors P89LPC952 Manual de usuario

NXP Semiconductors

NXP Semiconductors OM-SE051ARD Manual de usuario

NXP Semiconductors

NXP Semiconductors PN7462AU Manual de usuario

NXP Semiconductors

NXP Semiconductors Freescale Semiconductor MPC8569E-MDS-PB Manual de usuario

NXP Semiconductors

NXP Semiconductors FRDM665SPIEVB Manual de usuario

NXP Semiconductors

NXP Semiconductors MC9S12ZVMB-Family Manual de usuario

NXP Semiconductors

NXP Semiconductors LPC5410x Manual de usuario

NXP Semiconductors

NXP Semiconductors ARM Cortex M0+ Manual de usuario

NXP Semiconductors

NXP Semiconductors freescale Kinetics TWR-K60N512-KEIL Manual de usuario

NXP Semiconductors

NXP Semiconductors QN9020 mini DK Manual de usuario

NXP Semiconductors

NXP Semiconductors Harpoon Manual de usuario

NXP Semiconductors

NXP Semiconductors freescale KV4 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors ASUG Manual de usuario

NXP Semiconductors

NXP Semiconductors FRDM-KL28Z Manual de usuario

NXP Semiconductors

NXP Semiconductors AN11524 Instrucciones de instalación y funcionamiento

NXP Semiconductors

NXP Semiconductors UM108 Series Manual de usuario

NXP Semiconductors

NXP Semiconductors LPC21 Series Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
