NuWaves NUPOWER XTENDER C10RX03 Manual de usuario



USERMANUAL

NUPOWERXTENDERC10RX03

BIDIRECTIONALC-BANDAMPLIFIER

PART NUMBER:

NW-BA-C-10-RX03



NuWavesEngineering

132EdisonDrive

Middletown,Ohio45044

PH:513‐360‐0800

FAX:513‐539‐8782

www.nuwaves.com

[email protected]

NuPowerXtender™C10RX03UserManual



Rev‐

1



1NUPOWER XTENDER™ PRODUCT LINE OVERVIEW

TheNuPowerXtenderfamilyofsolidstatebidirectionalRFamplifiermodules,or“T/Rmodules,”is

designedtomeetthedemandingneedsoftheAerospace&Defense,Industrial,andCommercialmarkets.

BasedonthelatestGalliumNitride(GaN)technology,NuPowerXtender’spowerefficiencyandminiature

formfactormakeitidealforsize,weight,andpower‐constrainedbroadbandRFtelemetryandtactical

communicationssystems.

1.1 NUPOWER XTENDER™ PRODUCT LINE HIGHLIGHTS



HighPerformance:Uniquecombinationofbroadbandcoverage,miniatureformfactors,andhigh

efficiency.



Enclosures:TheNuPowerXtenderfamilyofbidirectionalamplifiersishousedinanaluminum

enclosurewithmountingholesincorporatedintothechassis.



CompletelyCharacterized:TheNuPowerXtenderfamilyofsolidstatebidirectionalamplifiershas

beencompletelycharacterizedovertemperature,voltage,andfrequency.Thesehigh‐

performancemodulesoffersignificantvaluefortheOEMuserortheSystemsIntegrator.



UserFriendly:Over‐voltageprotectionandregulatorthermalshutdownprovidedefensesagainst

userinterfaceissues.



HighReliability:NuWaves’selectionofconservativelyratedcomponentsprovideshighreliability.

EachNuPowerisinspectedtoIPC‐A‐610ClassIIqualitystandards.NuWaves’QualityManagement

SystemisAS9100:2016RevDandISO9001:2015certified.



Applications:UnmannedAircraftSystems(UAS)•UnmannedGroundVehicles(UGV)•Unmanned

SurfaceVehicles(USV)•BroadbandRFTelemetry•RFCommunicationSystems•SoftwareDefined

Radios• TestLabs



AvailableOptions:



oFan‐cooledheatsinkwithNorthAmericanAC/DCwallplugadapter

oLabeledinterfacecablewithbananajackplugs



NuPowerXtender™C10RX03UserManual



Rev‐

2



2NUPOWER XTENDER C10RX03 OVERVIEW

TheNuPowerXtender™C10RX03BidirectionalC‐BandAmplifiermoduleisasmall,lightweight,and

power‐efficientbidirectionalamplifier(BDA)idealforextendingthecommunicationrangeofhalf‐duplex

transceiversusingcontinuouswave(CW)andnear‐constantenvelopewaveforms.Thebidirectional

amplifiergenerates10watts(Psat)from4400to5100MHzintransmitmodeandtheintegratedlow‐

noiseamplifierprovides10dBofgaininreceivemode.

BasedonthelatestGalliumNitride(GaN)technology,NuPower’shigh‐efficiencyand4.6in.

formfactor

makeitidealforSWaP‐constrainedapplications.Inaddition,NuPower’sbroadbandfrequencycoverage

supportsoperationalflexibility.

NuPowerXtenderbidirectionalamplifiersaredesignedwitharuggedizedchassisforhigh‐reliabilityin

harshenvironments.



Figure 1: NuPower Xtender C10RX03 Functional Diagram



NuPowerXtender™C10RX03UserManual



Rev‐

3



2.1 PRELIMINARY SPECIFICATIONS

ThesubsequenttablesinthissectionoutlinetheNuPowerXtenderC10RX03’sperformancespecifications.



Table 1: NuPower Xtender C10RX03 Electrical Specifications

Parameter Specification

FrequencyRange4400to5100MHz

RFOutputPower,Psat10Watts(typ)

TransmitRFGain10dB(typ)

NominalInputDriveLevel +30dBm

MaximumInputDriveLevel+33dBm

ReceiveRFGain10dB(typ)

ReceiveNoiseFigure3.0dB(typ)

T/RModeAutomaticSensing

T/RSwitchTime2µS

SupplyVoltage28VDC

TransmitCurrentConsumption1.75A@+28VDC(typ)@Pout=10W

ReceiveCurrentConsumption45mA@+28VDC(typ)



Table 2: NuPower Xtender C10RX03 Environmental Specifications

Operating Conditions Specification

OperatingTemperature

(100%transmitdutycycle)

‐40to+85

C(baseplate)

StorageTemperature‐60to+100

C





NuPowerXtender™C10RX03UserManual



Rev‐

4



2.1.1 MECHANICAL SPECIFICATIONS

Figure 2: NuPower Xtender C10RX03 Mechanical Outline



Table 3: NuPower Xtender C10RX03 Mechanical Specifications

Parameter Specification

RFConnectorsSMA(female),rightangle

Control/PowerInterfaceConnector9PinMicro‐D(socket)

Dimensions(LxWxH)3.57”x2.57”x0.5”

Weight5.0oz.



NuPowerXtender™C10RX03UserManual



Rev‐

5



2.2 HEAT SINKING

TheNuPowerXtenderC10RX03isofferedasastand‐alonemodule,oraspartofakit,whichalsoincludes

afan‐cooledheatsinkwithanAC/DCadapterandaninterfacecablewithbananajackplugterminations.

Thefan‐cooledheatsinkprovidessufficientcoolingforoperatingtheNuPowerXtenderatroom

temperature(25°C),howeverhigherambienttemperaturesmayrequireadditionalheat‐sinkingto

maintainabaseplatetemperaturebelow60°Cat100%transmitdutycycle.



Figure 3: The NuPower PA Kit offers “out‐of‐the‐box” operation for the user. The fan‐cooled heatsink

is shown with an example PA (NuPower Xtender not shown).



Caution:Theuseofexternalheat‐sinkingisrequiredespeciallyforthoseapplications

requiringhighdutycycleoperation(e.g.continuouswave)orforextendedon‐time

testing.Operationwithoutaproperheatsinkundertheseconditionswillcause

permanentdamagetotheproductandwillvoidtheproductwarranty.





NuPowerXtender™C10RX03UserManual



Rev‐

6



3SETUP AND OPERATION

ThissectionprovidesspecificdetailsforproperoperationoftheNuPowerXtendermodule.Following

theseguidelineswillpreventdamagetothebidirectionalamplifierorexternalequipment.

3.1 POWER SUPPLY REQUIREMENTS

TooperatetheNuPowerXtenderC10RX03,ensurethatthepowersupplyhasadequateoverheadto

sourcethecurrentdemandoftheRFamplifier.Thepowersupplysourcemustprovideavoltageof

+28VDCwithgreaterthan5ampscapability.

3.2 CONNECTING A PROPER LOAD TO THE ANTENNA TERMINAL

Topreventdamagetotheamplifiermodule,theantennaterminalmustbeterminatedintoa50Ωload.

Examplesofaproperloadinclude:

Directlyconnectingtoanantennaspecifiedforthefrequencyrange(4400to5100MHz).

Connectingtoaninappropriateantennamayresultindamagetotheamplifiermodule.

Connectingtoaproperantennathrougha50Ωtransmissionlineorcoaxialcable.Avoidusing

damagedcablesorcorrodedconnectorswhileattachingtheunittoanantenna.

Terminatingtheantennaterminalintoa50Ωpowerattenuatorwithminimum20dBattenuation.

Connectingtoa50ΩloadcapableofdissipatingtheRFpowerfromtheamplifiermodule.Loads

capableofhandling30Watts(min)arerecommended.

3.3 POWERING‐UP THE NUPOWER XTENDER

TheNuPowerXtenderC10RX03mustbeterminatedintoaproperloadbeforepowerisapplied.Referto

Section3.2forthespecificationsoftheproperload.Aftertheamplifierisproperlyterminated,the

interfacecablecanbeconnectedtotheunitandpowercanbeapplied.Theamplifierisnowreadyfor

operation.





NuPowerXtender™C10RX03UserManual



Rev‐

7



4HARDWARE INTERFACE

Thetransceiverinterfaceconnector,“XCVR,”isSMA(female).

Theantennaconnector,“ANT,”isSMA(female).

Thepin‐outdefinitionsforthe9pinMicro‐Dsocketconnector,“CTRL/PWR,”areprovidedinTable

4.Inatypicalinstallation,theamplifiermoduleismatedtoahostcontrollerboardviaacable

harness.



TheANTSMAconnectoristheantennaconnection.Thisconnectionshouldalways

beloadedinto50Ω,otherwisetheamplifiercouldbedamaged.



4.1 INTERFACE CONNECTOR

TheNuPowerXtenderC10RX03featuresa9pinMicro‐Dinterfaceconnectorforcontrol,power,and

groundconnections.

Table 4: NuPower Xtender Interface Pin‐Out Definitions

Socket No. Name I/0 Description

3,4,5VSupplyIPrimaryPower(+28VDC)

1,2,6,8GNDISignalandPowerGround

7TempOOverTemperatureFlag

9TR_ENOTransmit/ReceiveControl



Thestandardinterfacecableharnessiscomprisedof9wires,includesaMicro‐Dconnectorwithpins,and

matesdirectlytotheNuPowerXtenderinterfaceconnector.

4.2 DC POWER

ThenominalsupplyvoltagefortheNuPowerXtenderC10RX03is+28VDC.

4.3 GROUND

Thesignalandpowergroundsaretiedtogetherintheamplifiermodule.



NuPowerXtender™C10RX03UserManual



Rev‐

8



4.4 OVER TEMPERATURE FLAG

Thissignalisanoutputtoindicateanover‐temperatureconditionintheNuPowerXtenderC10RX03.A

logichigh(+3.3VDCor+5VDC,factoryset)indicatesnormaloperation,whilealogiclow(0VDC)indicates

anover‐temperaturecondition.TheXtenderC10RX03incorporatesinternallogiccircuitrythatturnsoff

theDCbiastotheRFtransistors.Thisunitalsoincorporatesatemperaturebackofffeature,whereitwill

reducepowerinitiallytogeneratelessheatandreducetheriskofdamagebeforeitfinallyreachesthe

trippoint.



Caution:Theamplifiershouldbeshutdownandallowedtocooloffwhentheover‐

temperatureflagissetlowtoavoiddamagetothemodule.



4.5 TRANSMIT/RECEIVE (T/R) CONTROL

TheXtenderC10RX03isconfiguredforautosensetransmit/receive(T/R)switching.Themoduleswitches

totransmitwithanRFinputgreaterthan~+15dBm,andswitchestoreceivewhentheRFinputisbelow

~0dBm.TheT/Rstatuscanbemonitoredonthisline:logiclow(0VDC)=Transmit,logichigh(+3.3VDC

or+5VDC,factoryset)=Receive.



NuPowerXtender™C10RX03UserManual



Rev‐

9



5PRODUCT DISPOSAL – END‐OF‐LIFE

SafetyisaguidingprincipleofNuWavesEngineering.Weensuresafeproductionandoperationofour

products,aswellasend‐of‐lifedisposal.Improperdisposalcanadverselyaffecttheenvironment,wildlife

andhumanhealth.PleasefollowtheseguidelineswhendisposingofaNuWavesproduct:



Donotremovethecoveroranyhardware

Donotremovecomponentsfromthecircuitcardassembly

Donotincinerate

Donotcrushorshred

Donotdisposeofasunsortedmunicipalwaste

Donotexporte‐wasteoutsideoftheoriginaldestinationcountryforrecycling

Utilizeane‐StewardorISO14001certifiede‐wasterecycler

Considerexportcontrolsduringrecyclerselection

IfaNuWavesproductisincorporatedintoalargersystemorsub‐system,ensurethatthese

guidelinesarefollowedatsystemend‐of‐life






